Link electronics IEC-751 Specification Sheet

LINK ELECTRONICS, INC.
Y/C VIDEO DISTRIBUTION AMPLIFIER
MODEL IEC-751
MADE IN THE USA
FEATURES
Y/C DA
1 input, 4 output
Differential Input
Uses 4 Pin DIN Conn
The IEC-751 Y/C video distribution amplifier
reflects the latest in the state of the art engineering
techniques. The IEC-751 is the most versatile
video amplifier yet conceived, offering outstanding
performance. The input is terminated internally into
75 ohms. The unit provides four outputs using four
pin mini-DIN connectors.
The input "Y" and "C" signals are differential. The
IEC-751 is professional quality and carries the
standard ten year warranty.
LINK
ELECTRONICS, INC. 2137 Rust Avenue
Phone 573 334 4433
Portable
Ten Year Warranty
Mount 3 in 1RU Frame
Low Power Consumption
Two gain controls on the front panel adjust the
video level to +/-3dB for each the "Y" signal and
the "C" signal.
The IEC-751 has a video bandwidth of 20 MHz,
making it a very useful device for any Y/C
application. A fuse on the front panel provides
easy replacement. The IEC-751 is a self contained
Y/C video DA with an on board power supply that
draws only 4 watts. Three units can be mounted in
a 1 RU frame.
Cape Girardeau, MO 63703-7668
FAX 573 334 9255
700 SERIES
