- Page 1 OWNER’S MANUAL BLAKESLEE Division of The Legacy Companies UNDERCOUNTER DISHWASHER UC20 Blakeslee – Division of The Legacy Companies 1228 Capitol Drive Addison, IL 60101 Phone (630) 532-5021 Fax (630) 532-5020 www.blakesleeinc.com service@blakesleeinc.com...
-
Page 2: Limited Warranty
On the island of Oahu, repair labor, travel time and expenses are provided free of charge. This is the entire and only warranty of Blakeslee. We neither assume nor authorize anyone else to assume for us any other obligation or liability in connection with Blakeslee Machines. - Page 3 INDEX Page Warranty Index & Specifications Section 1 Installation Instructions Section II Operating Instructions Section III Cleaning Instructions Section IV Troubleshooting Section V Illustrated Parts List SPECIFICATIONS Construction: MACHINE INSTALLATION DATA: Body of stainless steel construction. Electrical: Wash System: Top and bottom counter rotating spray arms. Volts Phase Amp Draw...
-
Page 4: Section I Installation
SECTION I INSTALLATION The Model UC20 is suitable for both under the counter and free standing installations. Access is required to the front and rear of the machine for service and maintenance. Therefore, all connections should be made with flexible hoses and conduit to ensure that access can be achieved. -
Page 5: Section Ii Operation
SECTION II OPERATION 1. Ensure that all spray arms spin freely and that scrap strainer is properly installed. 2. Close dishwasher door. 3. Turn on main water supply to dishwasher. 4. Turn on main power supply to dishwasher. 5. Depress dishwasher Power On/Off switch to fill dishwasher. Blue indicator light will appear. 6. - Page 6 11. When proper temperatures are reached, a green indicator light appears and the dishwasher is ready for a washing cycle. To start the washing cycle, depress the Start/Enter switch. 12. At the beginning of the wash cycle, a detergent pump will systematically add detergent into the wash tank.
- Page 7 Observe the following instructions to obtain maximum performance from the dishwashing machine. 1. Whenever possible, instruct staff to stack the soiled dishes according to sizes as they are brought to the dish room 2. Remove by hand, rubber scraper, or pre-washing as much food particles left on the dishes as possible.
-
Page 8: Section Iii Maintenance & Cleaning
SECTION III MAINTENANCE & CLEANING MAINTENANCE: Wash Arms: a. Wash arms, upper and lower, should turn freely and continue turning for a few seconds after being whirled by hand. b. If the scrap screen is not properly in place, obstructions may clog the wash arm nozzles. The wash arms are easily removed for cleaning. -
Page 9: Section Iv Troubleshooting
SECTION IV TROUBLESHOOTING Problem Possible Cause Corrective Action Dishwasher does not Main power off Check breaker panel Dishwasher does not fill Main water off Open supply valve Rinse nozzles clogged Clean rinse nozzles Solenoid filter clogged Clean filter Lime build-up De-Lime rinse line Defective pressure switch Replace pressure switch Indicator light flashing... -
Page 10: Error Codes
ERROR CODES Resetting an error code An error code can be reset by pressing the Power On/Off switch three consecutive times. If the error code fails to reset, refer to the below chart before contacting factory. ERROR CODES Check power connection to B1 heat alarm booster element Check incoming water... -
Page 11: Section V Parts
SECTION V PARTS MADE IN USA PROTECT YOUR EQUIPMENT USE GENUINE BLAKESLEE PARTS...
