  • Page 1 OWNER’S MANUAL BLAKESLEE Division of Blako Inc. UNDERCOUNTER DISHWASHER UC-21 I.R.S. INTEGRATED RECIRCULATING SYSTEM DESIGN 1844 South Laramie Avenue www.blakesleeinc.com 1149 Bellamy Road North Unit 19 Chicago, IL 60804 Scarborough, Ontario Canada M1H1H7 Phone (708) 656-0660 service@blakesleeinc.com Phone (416) 751-2625...

  • Page 2: Limited Warranty

    On the island of Oahu, repair labor, travel time and expenses are provided free of charge. This is the entire and only warranty of Blakeslee. We neither assume nor authorize anyone else to assume for us any other obligation or liability in connection with Blakeslee Machines.
  • Page 3 INDEX Page Section 1 Installation Instructions * Section II Operating Instructions Section III Cleaning Instructions Section IV Troubleshooting Section V Optional Equipment Section VI Illustrated Parts List SPECIFICATIONS Construction: MACHINE INSTALLATON DATA: Body of stainless steel construction throughout. Electrical: Wash System: Volts Phase Load Amps...

  • Page 4: Section I Installation

    SECTION I INSTALLATION The Model UC21 is suitable for both under the counter and free standing installations. Access is required to both the sides and rear of the machine for service and maintenance. Therefore, all connections should be made with flexible hoses and conduit to ensure that access can be achieved. SHIPMENT CHECKOUT &...
  • Page 5 ELECTRICAL: Check machine data plate before making any electrical connections. All supply connections must correspond with data plate information. Check pumps rotation, pump turns clockwise when viewed from rear of motor; if not reverse leads. MODEL UC-21 33 ¼” 37 ¼” 12”...

  • Page 6: Section Ii Operation

    SECTION II OPERATION DO NOT ATTEMPT TO OPERATE WITHOUT WASH TANK BEING PROPERLY FILLED, DRY ROTATION WILL DAMAGE PUMP SEALS AND VOID WARRANTY 1. Ensure that all spray arms spin freely and that scrap tray and standpipe are properly installed. NOTE: There is no stand pipe on machines equipped with an optional drain pump.
  • Page 7 Observe the following instructions to obtain maximum performance from the dishwashing machine. 1. Whenever possible, instruct bus boys or wait staff to stack the soiled dishes according to sizes as they are brought to the soiled dish table. 2. Remove by hand, rubber scraper, or pre-washing as much food particles left on the dishes as possible.

  • Page 8: Section Iii Maintenance & Cleaning

    SECTION III MAINTENANCE & CLEANING Maintenance: Motor: No lubrication required Pump: No lubrication required Wash Arms: a. Wash arms, upper and lower, should turn freely and continue turning for a few seconds after being whirled by hand. b. If the scrap screen is not properly in place, obstructions may clog the wash arm nozzles. The wash arms are easily removed for cleaning.
  • Page 9 After each meal period and at the end of the day, pull out the stand pipe to drain the machine and clean out the scrap tray. Daily cleaning instructions: 1. Turn off main switch to dish machine*. 2. Open door and pull out stand pipe*. 3.

  • Page 11: Section Iv Parts

    SECTION IV PARTS PROTECT YOUR EQUIPMENT BLAKESLEE USE GENUINE PARTS...
  • Page 12 FIGURE 1. RECIRCULATING SYSTEM...
  • Page 13 FIGURE 1. RECIRCULATING SYSTEM -10-...
  • Page 14 FIGURE 2. SPRAY ARMS & MANIFOLDS -11-...
  • Page 15 FIGURE 2. SPRAY ARMS & MANIFOLDS -12-...
  • Page 16 FIGURE 3. ELECTRICAL ASSEMBLY -13-...
  • Page 17 FIGURE 3. ELECTRICAL ASSEMBLY -14-...
  • Page 18 FIGURE 4. BODY ASSEMBLY -15-...
  • Page 19 FIGURE 4. BODY ASSEMBLY -16-...
  • Page 20 FIGURE 4. BODY ASSEMBLY -17-...
  • Page 21 -18-...
  • Page 22 BLAKESLEE BLAKESLEE...
