Summary of Contents for Globalmediapro fv789
-
Page 1: User Manual
Multi-Channel with Seamless Switch Pro-Broadcast HD LCD Monitor User Manual... -
Page 2: Table Of Contents
CONTENTS User Instructions ---------------------------- 2 Cautions ---------------------------------- 2～3 Product Features ---------------------------- 4 Product Description 7″ ------------------------------------- 5～9 10.1″ -------------------------------- 9～13 Manu Instruction --------------------- 13～19 Power Supply -------------------------- 20～21 Parameters -------------------------------21～23 Trouble Shooting ----------------------- 24 ~ 25 ... -
Page 3: User Instructions
User Instruction: Dear Customer： Thanks for using our field monitor. Our monitor adopt special digital signal processing circuit and TFT LCD screen, with high brightness, low consumption, Non-radiation and stable performance. Product advanced features with color temperature adjust, screen marker, 5II camera mode, zoom-in, image flip and check field, etc. - Page 4 ●The screen of this product is made of glass. Please do not display the screen towards the ground. Keep away from injury if the screen is broken. ●Keep the product away from the heat source, such as radiator, water heater, stoves or other heating products.
-
Page 5: Product Features
Product Features： 1、 IPS Panel，178° 2、 Check field（R、G、B、gray） 3、 False Color 4、 Peaking Focus Assist 5、 Screen Marker 6、 Squared Segmentation 7、 Histogram 8、 Vector Scope/ RGB Histogram/Waveform 9、 Embedded Audio 10、 5II Camera Mode(No black screen when recording) 11、 Scan Mode( Over scan &Standard) 12、... - Page 6 Description & Function ●7″ Front Panel View： ：earphone jack Power indicator Volume/ ：Rotate it to control the Volume，Press it directly to enter the Camera mode / FOCUS：Rotate it to adjust the contrast，Press it to enter the peaking filter function / ESC：Rotate it to adjust the brightness Press it to confirm if OSD need exit ...
- Page 7 / MENU：Press it to open OSD main menu, Press again to enter the secondary menu, select menu item or adjustment when it’s rotate, Press it again to confirm the setting SDI 2：SDI.2 signal input selected F5：Shortcuts buttons. User-definable function buttons, enter the Manu of shortcuts defined item to use the function SDI 1：SDI.1 signal input selected F4：Shortcuts buttons.
- Page 8 ●7″ Rear Panel view： 1. Signal input port 2. Battery plate 3. DC Power Input 4. 4-PIN（XLR）DC 12V Power input 5. TALLY Input Power switch. ▬ ; Power on （ON） ，O ： Power off （OFF） ...
- Page 9 7″ Rear Signal Port： ● 1、 HDMI OUT Multimedia signal output 2、 HDMI IN Multimedia signal input 3、 VIDEO IN Composite video signal input（Y signal output in Ypbpr） 4、 VIDEO OUT Composite video signal output 5、 Pb IN Component video Pb signal input in Ypbpr 6、...
- Page 10 11、SDI.1 IN SDI 1 signal input 12、SDI.1 OUT SDI 1 signal loop output 13、SDI.2 IN SDI 2 signal input 14、SDI.2 OUTSDI 2 signal loop output ●10.1″ Front Panel View： Power indicator Volume/ ：Rotate it to control the Volume，Press it directly to enter the Camera mode / FOCUS：Rotate it to adjust the contrast，Press it to enter the peaking filter function...
- Page 11 4、 / ESC：Rotate it to adjust the brightness，Press it to confirm if OSD need exit 5、 / MENU：Press it to open OSD main manu, Press again to enter the secondary manu, select manu item or adjustment when it’s rotate, Press it again to confirm the setting 6、...
- Page 12 ●10.1″ Rear Panel View： 1. Signal input port 2. Battery plate 3. DC Power Input 4. 4-PIN（XLR）DC 12V Power input 5. TALLY Input 6. Power switch : ▬ Power on（ON），O Power off（OFF） ...
- Page 13 10.1″ Rear Signal Port： ● 9、 HDMI OUT Multimedia signal output 10、 HDMI IN Multimedia signal input 11、 VIDEO IN Composite video signal input（Y signal output in Ypbpr） 12、 VIDEO OUT Composite video signal output 13、 Pb IN Component video Pb signal input in Ypbpr 14、...
-
Page 14: Manu Instruction
10、AUDIO IN Analog stereo audio R channel input 11、SDI.1 IN SDI 1 signal input 12、SDI.1 OUT SDI 1 signal loop output 13、SDI.2 IN SDI 2 signal input 14、SDI.2 OUTSDI 2 signal loop output Manu Instruction 1、Press “Menu” to OSD main menu, Rotate the button to select the item what you need. - Page 15 ● Assistant functions Check Field： Under the Red/Blue/Green/Gray only mode, only the ★ Red/Blue/Green/Gray pixels are used to generate the image, because hue and saturation can be adjusted quickly and accurately Pseudo Colors False color can be intuitive observation and calculation ★...
- Page 16 Auxiliary Line ● Center Marker：screen center mark (cross mark) display settings ★ Marker Type：Can select 16:9；4:3；2.35:1；1.85:1 or exit. ★ Safety Area：Picture framing marker selection frame (off,；95％； ★ 93％；90％；85％；80％.)Center Marker, Marker Type and Safety Area can be display at the same time Marker Color：White, black, grey, red, blue, green can be optional.
- Page 17 Waveform ● Histogram The Brightness Histogram is a quantitative tool to check the ★ ： picture brightness. The feature shows the distribution of brightness in an image as graph of brightness along the horizontalaxis (Left: Dark, Right: Bright)and a stack of the number of pixels at each level of brightness along the vertical axis Audio Column When in SDI&HDMI mode,2 channels mar with...
-
Page 18: Picture Setting
Picture Setting ● Scan Mode：Auto, Full screen and scan mode。 ★ DSLR Camera：On/Off ★ Flip：The U/D,L/R of the image around flip ★ Freeze：The current picture still(capture function) ★ Pixel to Pixel : The display mode that make the resolution of the image ★... - Page 19 of the image Hue：Under the NTSC format, adjust the hue to make a perfect image ★ display Chroma：Rotate“ to adjust it / MENU” ★ Sharpness：Rotate“ to adjust it / MENU” ★ Color Temp: 3200K, 5600K ,6500K or 9300K(Standard:6500K) ★ Shortcuts ●...
-
Page 20: Osd Setting
●OSD Setting Language：Chinese and English are optional ★ OSD Time：OSD Menu will disappear without operation after 5s ★ 10s、15s、20s、25s or 30s. OSD Trans ：Display the menu on the screen translucently ★ Volume: Control the volume of Speaker or earphone ★ Mute: Close the volume of speaker or earphone ★... -
Page 21: Power Supply
Power Supply This monitor can be powered with these three ways： DC Power Supply： ★ 4-pin XLR DC power input ★ Powered by Battery: The product back including a battery slot is ★ available five types of batteries as below: Standard accessory is F970 Battery Plate ★... -
Page 22: Parameters
F970 can be adapted with： ★ SONY F970 F960 F950 T930 F770 T750 F730 F570 F550 F530 QM91D OM91 QM90D QM90 QM71D QM71 QM70D QM70 QM51D QM51 FM71 FM70. LP-E6 can be adapted with： ★ Canon LP-E6 D28 can be adapted with： ★... -
Page 23: Video Format
SDI ×2 3G/HD/SD 2 × BNG HDMI × 1 Input YPbPr 3 × BNG CVBS VIDEO 1× BNG AUDIO AUDIO L/R 2 × BNG SDI × 2 3G/HD/SD 2 × BNG Output HDMI × 1 YPbPr 3 × BNG CVBS VIDEO 1×... - Page 24 720p (60/59.94/50/30/29/25/24/23.98） HDMI 1080p（60/59.94/5030/29.97/25/24/24fps/23.98/23.98fps） YPbPr 480i / 576i / 576p Input 1080i (60/50） 720p (60/50) CVBS NTSC 480i PAL 576i （video） Parameters 7 ″ TFT LCD 10.1″ TFT LCD Input Voltage DC 7～24V DC 7～24V Power Consumption 13 W ≤ 16W ≤...
-
Page 25: Trouble Shooting
Trouble Shooting If there is any problem using the unit. You can try follow ways to inspect and solve. Without image display Trouble shooting ● Video cable off or connect incorrectly Check the quality of the cable, make sure the correct input interface Without video signal input Check the signal source and output interface... - Page 26 ●Speaker without sound Trouble Shooting Volume adjustment was closed Reset the volume control is adjusted to a proper position HDMI cable poor connected Check the quality of cable, or change cable have a Video without sound output A normal phenomenon. Because in the recording process, in order to avoid the sound field monitor and a voice of harassing together was also recorded in, so the camera itself is no sound output.
