Page 1: User Manual
On-camera field HD LCD Monitor User Manual... -
Page 2: Key Features
Dear users: Thank you for purchasing our On-Camera Field HD LCD Monitor Kit. It employs advanced integrate circuits and high quality TFT LCD modules, low comsumption, steady function, and low radiation emission. This monitor designed small-sized, easily operated and safety, with HDMI, VGA, Video and Audio Inputs, this monitor can be easily be installed on Digital Camera DSLR or HDV, the best partner for photography. -
Page 3: Table Of Contents
Contents 1. Product description.……………………………………….3 1.a. Front veiw.……………………………………………..3 1.b. Rear view and side view.……………………………..4 2. Power input way.……………………………………...5 3. Operation instruction………………………………………7 3.a. No menu display state………………………………..8 3.b. Press " " button on the unit, then enter into OSD menu operation………………………………...8 4. Technical parameters …………………………………….13 5. -
Page 4: Product Description
1. Product description 1.a. Front view 1. Infrared receiving window 2. Indicator light: Red light is power on/standby state, green light is in working state 3. Power：Power on/off button 4. MODE：Signal source switch button, cycle switch HDMI, VGA, Video 1, Video 2 model : Item selection button or single press can realize on/off peaking focus assist mode : Item selection button or NO menu state single press to realize... -
Page 5: Rear View And Side View
function value setting : Volume down or switch screen marker or menu setting, decrease function value setting 10. Panel 1.b. Rear view and side view 1．DC power input... -
Page 6: Power Input Way
2．HDMI HD signal input interface 3．VGA signal input interface 4．Battery plate 5．AV signal input interface 6．Battery plate power output jack 2．Power input way Please use the adapter attached in the accessories. If necessary to use other specifications adapter, please note to provide the qualified adapter which power supply should be not less than 10W (DC6V-24V) 2.a. - Page 7 types, customers can select for their needs. 2.d. Different types battery plates as below: F970 LP-E6 Sony F970 battery slot for battery of Sony DV: Sony F970 F960 F950 T930 F770 T750 F730 F570 F550 F530 QM91D OM91 QM90D QM90 QM71D QM71 QM70D QM70 QM51D QM51 FM71 FM70 serials Canon LP-E6 battery slot for battery of Canon DV: Canon LP-06...
-
Page 8: Operation Instruction
2.e. Battery install way Suggestion: Better remove the battery for long-term NO use this product. Different specifications of the batteries, capability is different. The working time for the monitor will be different. Higher capability (working time) will be longer. Without design charging circuit for the monitor, please remove the battery to the battery charger for charge. -
Page 9: No Menu Display State
3.a. No menu display state: Click “ ” to direct on/off peaking focus assist mode Click “ ” to realize image monochrome switch(Red,Green,Blue,Black & White and Color), under overscan state long press the button to realize underscan function, to make sure that the signal in the 1080i image without distortion. - Page 10 3.b.1. （Color） Enter into "Color" OSD, press “ ”or“ ”button to confirm, then enter to adjust the color parameters, use ““ ”or“ ”to select adjustment item, then use“ ”or“ ” adjust the parameters. ※ Brightness: To adjust the image's brightness. ※...
- Page 11 “ ”or“ ” to select color temperature such as: 9300 K, 7500K, 6500K or USER. When select "USER", use “ ”or“ ” to select color R、 G、 B, then use “ ”or“ ” to adjust the value of Analog Data, to make sure the color of picture meets need.
- Page 12 ※ Language： Languages for OSD as below: English Italians Francois 简体中文 Deutsch Español Japanese 繁体中文 Korean Pycc ※ H Position：To adjust the OSD position in horizontal. ※ V Position：To adjust the OSD position in vertical. ※ OSD Timeout：To adjust the clock. ※...
- Page 13 ※ Screen Marker:（80%, 85%, 90%, 93%, 95%） ※ Center Marker ※ Flip L/R ※ Flip U/D 3.b.4. （Sound） ※ Volume: To adjust the volume.
-
Page 14: Technical Parameters
4. Parameters LCD panel TFT LCD 7.0inch 1152000 Pixels Resolution 800×480 Resolution up to 1920×1440 Brightness 300 cd/㎡ Contrast ratio 500:1 Viewing angle 70°/70（L/R）,50°/60° (U/D) Video signal input range 0.7～1.4Vp-p/75Ω Supported input frequency H:30～60kHz V:50～75Hz 480i, 480p, 576i, 576p, 720p, HDMI supported formats 1080/ 50i/ 60i/ 50p/ 60p；... -
Page 15: Optional
HDMI Cable Power adapter Sun shade User manual 5.b、Optional Hot shoe moun AV cable Battery Battery plate (optional) (optional) (optional) (optional) Trouble shootings 6.a. Only black and white picture. Please check saturation、brightness & contrast adjustment. 6.b. NO picture after put on the power. Check signal cable connecting, make sure use the standard adapter connect the monitor.
