CONNECTING TO MONITORS*

Use the diagram below to connect to a Monitor or CRT Monitor properly.
12VDC/24VAC
Monitor
Power Connection - 12VDC/24VAC Dual Voltage (Auto Polarity Detection and Protection)
All cameras are equipped with a second video output for on-site configuration.
Second Video Output
CCTV Monitor
Up
Left
Right
Down
9
