Covert ECO ESRM-N540-OSD Operation Manual

Covert room mirror osd camera security camera hidden behind the mirror
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
ESRM-N540-OSD
ESRM-N540-OSDP
Covert Room Mirror OSD Camera
1/3" Sony Super HAD CCD
540 TV Lines
4.3mm Lens
0.1 Lux
Built-in Audio
Day & Night Switching via Remote Controller and OSD Display
12V~18V DC, 100mA
P = PAL Version
Copyright © 2009. All Rights Reserved.
Please read the Operational Manual
before attempting to use this product.
Security Camera Hidden Behind the Mirror
Camera
1
REV090109

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECO ESRM-N540-OSD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Covert ECO ESRM-N540-OSD

Summary of Contents for Covert ECO ESRM-N540-OSD

  • Page 1 Please read the Operational Manual before attempting to use this product. ESRM-N540-OSD ESRM-N540-OSDP Covert Room Mirror OSD Camera Security Camera Hidden Behind the Mirror Camera 1/3” Sony Super HAD CCD 540 TV Lines 4.3mm Lens 0.1 Lux Built-in Audio Day & Night Switching via Remote Controller and OSD Display...
  • Page 2 OSD Hierarchy Copyright © 2009. All Rights Reserved. REV090109...

  • Page 3: Osd Setup

    OSD Setup Press "ENTER" to see OSD Setup Main Menu 1. LENS： Setup Lens 2. SHUTTER： Adjust Shutter Speed Back Light Compensation On / Off 3. BLC： 4. AGC： Auto Gain Control 5. WHITE BAL： White Balance 6. MIRROR： Mirrow Function On／Off 7.
  • Page 4 3. BLC Back Light Compensation: On / Off a. Off : Turn off Back Light Compensation.     b. On: Press "ENTER" to adjust Back Light Compensation. BLC AREA: Setup back light compensation area. BLC RATIO: Setup BL area brightness. (Number goes bigger, screen becomes brighter).

  • Page 5: White Bal

    5. WHITE BAL Setup Camera White Balance and the Range of Color Temperature. There are 4 WHITE BAL modes: ATW, AWB, FIXED, and MANUAL.     a. AWB：AWB is performed within the range of color temperature created by Camera default value. b.
  • Page 6 b. DAY NIGHT：While in low illumination, screen will trun to Black/White. There are 3 modes: Auto, Color, B/W i. AUTO: Press "ENTER" to adjust the sensitivity of changing color to B/W. - DELAY: Setup the speed of changing color. - START LEVELL: Setup the starting color performance. - END LEVEL: Setup the ending color performance.

  • Page 7: Specifications

    10. CAMERA ID Setup camera ID and location. Off: Turn off Camera ID. On: Press "ENTER" to see Sub-Menu. Then use "← or →" button to select characters. Finally move cursor to " ", then press "ENTER" to confirm. To erase camera ID, move cursor to "C". Then press "ENTER" to erase. SPECIFICATIONS Model ESRM-N540-OSD...

  • Page 8: Package Contents

    PACKAGE CONTENTS One (1) ESRM-N540-OSD/ESRM-N540-OSDP with video/power/audio cable One (1) Remote Control One (1) Operational Manual * For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be accepted if any component is missing/damaged. CAUTION 1.
