SI-3 is delivered as single pole 16A version and dual pole 10A version. This manual
applies to both versions. The connections are the same.
Technical specifications
Manufacturer:
Type/Model:
Compatible with:
Operating voltage:
Max load:
Regulation:
Measurement range:
Regulation range:
Operating temp.:
Color:
Radio Frequency:
Sealing:
Complies with the European R&TTE directive.
Designed for indoor use only.
Package contents
Wireless thermostat
•
Front cover and frame.
•
Temperature sensor with 3m cable. Called "sensor" in the following.
•
Do not expose the sensor cable to the sun or UV lighting.
NB:
This thermostat does not offer galvanic separation between high and low
voltages. The sensor must therefore be regarded as a high voltage cable.
64 000 13 Monteringsanvisning Termostat SI-3 Eng Rev1.0.docx.0
Please leave this guide to the end user
Wireless thermostat SI-3
Installation and user guide
Sikom AS, Norway
Wireless thermostat SI-3 300-8063V10/300-8064V10
Comfort and ECO system
230VAC
Single pole version 16A. Dual pole version 10A.
P-Regulator. 0-100%
0°C to +45°C ±2°C
5°C to +40°C
0°C to +45°C
White (polar white, similar to RAL 9010)
433.9 MHz
IP20
www.sikom.no
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SiKom SI-3
Summary of Contents for SiKom SI-3
-
Page 1: Technical Specifications
Please leave this guide to the end user Wireless thermostat SI-3 Installation and user guide SI-3 is delivered as single pole 16A version and dual pole 10A version. This manual applies to both versions. The connections are the same. Technical specifications... - Page 2 Please leave this guide to the end user Installation Sensor: The standard sensor on the thermostat is a floor sensor from Sikom. A room sensor and/or floor sensor can be used. The room sensor is integrated in the thermostat. To activate this sensor, see the programming instructions.
- Page 3 Element on/off: Lights when the heating element receives current. • Comfort: Comfort mode active. • Eco: Eco mode active. • On/Off switch: On mode or standby mode. • Programming: Programming switch. • 64 000 13 Monteringsanvisning Termostat SI-3 Eng Rev1.0.docx.0 www.sikom.no...
- Page 4 When you have reached the desired menu, wait until the setting for that menu is displayed. Adjust the setting with the up and down buttons. When settings are adjusted, press the «on/off» button to exit the advanced menu. 64 000 13 Monteringsanvisning Termostat SI-3 Eng Rev1.0.docx.0 www.sikom.no...
- Page 5 P1: Floor sensor type: 6 temperature sensors are supported. Choose the correct one according to the sensor type used. The default value is the Sikom sensor. Note: If room sensor is chosen in P5, this menu has no effect. 1. Microsafe 2.
- Page 6 If, after several attempts, Sikom A.S. is unable to correct the problem, and the product does not work as described in the manual, Sikom may elect to refund the purchase price or to replace the product with a functionally equivalent one.
