The thermistor information is used by the software to inhibit charging at temperature extremes and to set charging strategy for different battery chemistries. , LTC and LT are registered trademarks of Linear Technology Corporation. CONDITIONS Hardware Limited Software Limited...
CUI-PJ-002A JPR1 3801S-12-G1 CTX20-4 Q1,Q2, Q3 2N7002LT MMBT3904LT1 R1, R4, R16 CR32-3321F-T CR32-3010F-T R3, R18 CR32-1001F-T DEMO MANUAL DC101 SMART BATTERY CHARGER TOP VIEW BOOST PROG COMP2 COMP1 SENSE SPIN SW PACKAGE 24-LEAD PLASTIC SO WIDE DESCRIPTION 0.1 F 50V Chip Capacitor 10 F 10V Tantalum Capacitor 0.33 F 25V Chip Capacitor...
Page 4
DEMO MANUAL DC101 SMART BATTERY CHARGER PARTS LIST REFERENCE DESIGNATOR QUANTITY PART NUMBER R5, R6, R14 CR32-331J-T BCR1/8-3322F-T LR2010-01-R033-J CR32-104J-T LR2010-01-R050-J CR32-511J-T W1206R-03-1003-B W1206R-03-1433-B W1206R-03-2152-B CR32-1051F-T R19, R20 CR32-2000F-T R21, R22, R25 CR32-223J-T CR32-220J-T R24, R26 CR1206-103J MJTP1230 TP1 to TP5, E1 to E7...
Page 5
The latest version of “C” language source code, header file, code file and hex dump file is provided on a 3.5" disk. Figure 1. SMBus Waveforms Indicating Battery Address DEMO MANUAL DC101 SMART BATTERY CHARGER 0 = WRITE 1 = 1ST NIBBLE...
Page 6
DEMO MANUAL DC101 SMART BATTERY CHARGER OPERATIO INIT VARIABLES START TURN RED LED ON 12C DATA RECEIVED FOR 2 SEC RESET 12C POINTER A/D COUNTER = 0 MEASURE THERMISTOR SET ERROR FLAG ALARM WARNING SHUT DOWN CHARGER ON STACK ERASE COMMAND...
Page 7
Information furnished by Linear Technology Corporation is believed to be accurate and reliable. However, no responsibility is assumed for its use. Linear Technology Corporation makes no represen- tation that the interconnection of circuits as described herein will not infringe on existing patent rights.
Page 8
DEMO MANUAL DC101 SMART BATTERY CHARGER PCB LAYOUT A D FIL Solder Side PC FAB DRAWI G 0.150" 3.019" 0.150" 0.219" 0.150" Linear Technology Corporation 1630 McCarthy Blvd., Milpitas, CA 95035-7417 (408) 432-1900 : (408) 434-0507 TELEX 0.150" 2.744" 3.900"...
