Please read this entire manual before installation and use of this wood pellet fuel burning room heater.
Failure to follow these instructions could result in property damage, bodily injury or even death.
This stove must only be installed with factory approved and tested components. Use of components not tested and approved for
use with this stove or using another manufacturer's components my result in a fire or safety hazard and voids all warranty.
INSTALLATION MANUAL
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE
July-2008
WLD-P-Rev-01
Advertisement
Table of Contents
Related Manuals for kozy heat WLD-P Woodland
Summary of Contents for kozy heat WLD-P Woodland
- Page 1 INSTALLATION MANUAL INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE Quality Fireplaces for Life Contact local building or fire officials about restrictions and installation inspection requirements in your area. Please read this entire manual before installation and use of this wood pellet fuel burning room heater. Failure to follow these instructions could result in property damage, bodily injury or even death.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION VENT SYSTEM REQUIREMENTS APPROVED VENTING COMPONENTS MOBILE HOME INSTALLATIONS SPECIFICATIONS CLEARANCES VENTING ILLUSTRATIONS VENTING TERMINATION REQUIREMENTS MINIMUM EXHAUST TERMINATION CLEARANCES COMBUSTION AIR REQUIREMENTS SEPARATE EXHAUST & COMBUSTION VENT PIPE TERMINATIONS #WLD-WPT WALL PASS THRU INSTALLATION INSTRUCTIONS ELECTRICAL COMPONENTS THERMOSTAT INSTALLATION (optional) WARRANTY... -
Page 5: Safety Information
SAFETY INFORMATION This wood pellet stove, Woodland model #WLD-P, has been tested and certified by OMNI-Test Laboratories, Inc., Portland, Ore- gon, to comply with ASTM E1509-04, ‘Tested & Certified Room Heater, Pellet Fuel-Burning Type’. Also for use in Mobile Homes. Installation must comform with applicable requirements of NFPA 211, and applicable building & mechanical codes. •... -
Page 6: Approved Venting Components
APPROVED VENTING COMPONENTS • Kozy Heat Wall Pass-Thru (#WLD-WPT). • Simpson Dura-Vent type ‘L’ Vent System. • Selkirk-Metalbestos Direct-Temp direct vent system. • Alternate brands may be used provided they are approved by a certified testing agency as a Type ‘L’ system. -
Page 7: Clearances
CLEARANCES The installation of this freestanding stove must meet the following minimum requirements Sides of stove………………………………………………...3” (76 mm) Back of stove………………………………………….……..3” (76 mm) Corner of stove……………………………………….……...3” (76 mm) From Dura-Vent Pellet vent pipe…………………………….1” (25 mm) From Selkirk-Metalbestos vent pipe……………………..….1” (25mm) NOTE: Follow vent manufacturer’s clearance requirements. -
Page 8: Venting Illustrations
VENTING ILLUSTRATIONS Horizontal Termination #1 Horizontal Termination #2 Typical Corner Installation Vertical Termination #1 Vertical Termination #2 (Not recommended for cold climate installation). PAGE 5... -
Page 9: Venting Termination Requirements
VENTING TERMINATION REQUIREMENTS MAXIMUM HORIZONTAL RUN: 9 ft (2.74 m) MAXIMUM VERTICAL RUN: 36 ft. (10.97 m) Items to consider when determining the best location for vent termination cap: Distance from air inlets - Installation must comply with the requirements in this installation manual, the requirements of the vent system being used and local building codes. -
Page 10: Minimum Exhaust Termination Clearances
MINIMUM EXHAUST TERMINATION CLEARANCES Above ground level: 12” (305 mm) Above ground level when located adjacent to public walkways: 7’ (2.1 m) From wall penetration point: 12” (305 mm) From any adjacent combustibles - i.e.: fences, adjacent buildings, protruding parts of the structure, roof eaves or overhangs, plants, shrubs: 24”... -
Page 11: Combustion Air Requirements
COMBUSTION AIR REQUIREMENTS This stove requires the use of outside air for combustion. A 2” (51 mm) diameter aluminum flex pipe 4 ft. (1.2 m) long is included with this stove to connect to the 2” (51 mm) intake collar located at the back of stove. WARNING: THE COMBUSTION AIR PIPE MUST BE PROPERLY CONNECTED TO THE OUTDOORS FOR PROPER PERFORMANCE. -
Page 12: Wld-Wpt Wall Pass Thru Installation Instructions
#WLD-WPT WALL PASS THRU INSTALLATION INSTRUCTIONS (cont.) Center and secure the interior wall pass-thru to the square opening. NOTE: Orientation of 2” (51 mm) collar must be either on right side as shown throughout these instructions or in the down position to properly connect the 2”... -
Page 13: Electrical Components
ELECTRICAL COMPONENTS This stove includes a combustion fan and room fan with a 3-prong (grounding ) plug. The fans must be plugged into a properly grounded 3-prong outlet. The current required is approx. 3 amps (5 amps when ignitor is in operation). Run power cord to nearest outlet. -
Page 14: Thermostat Installation (Optional)
THERMOSTAT INSTALLATION (optional) An optional thermostat is available for use on this stove. A thermostat will maintain a constant level of heat, resulting in optimal fuel consumption, ultimately lowering heat costs. This stove is pre-wired and capable of operating on a thermostat. A feature has been built into the circuit control board which delays the time be- tween each heat setting to allowing the stove to react at each subsequent level. -
Page 15: Warranty
30 days of installation. Failure to do so may result in delayed warranty coverage. Hussong Manufacturing Co., Inc. warranties to the original purchaser of the Kozy Heat Model #WLD-P Woodland Pellet Stove, that it is free of defects in materials and workmanship at the time of manufacture.
