Model #OLV-PC Olivia
Corn / Pellet Stove
INSTALLATION MANUAL
Please read this entire manual before installation and use of the corn / pellet fuel burning room heater.
Failure to follow these instructions could result in property damage, bodily injury or even death.
This stove must only be installed with factory approved and tested components. Use of components not
tested and approved for use with this stove or using another manufacturer's components may
result in a fire or safety hazard and voids all warranty.
Contact local building or fire officials about restrictions and
installation inspection requirements in your area.
SAVE THESE INSTRUCTIONS
June 2006 (2)
Advertisement
Table of Contents
Related Manuals for kozy heat OLV-PC OLIVIA
Summary of Contents for kozy heat OLV-PC OLIVIA
- Page 1 Model #OLV-PC Olivia Corn / Pellet Stove INSTALLATION MANUAL Please read this entire manual before installation and use of the corn / pellet fuel burning room heater. Failure to follow these instructions could result in property damage, bodily injury or even death.
-
Page 2: Table Of Contents
INDEX Safety Testing ............1-2 Approved Venting Components . -
Page 3: Safety Testing
SAFETY TESTING The corn/pellet stove, Model #OLV-PC ‘Olivia’, has been tested and certified by OMNI-Test Laboratories, Inc., Beaverton, Oregon, to comply with ASTM E1509-04, ULC-C1482, ULC-S627 ‘Tested & Certified Room Heater, Pellet Fuel-Burning Type’. Also for use in Mobile Homes. Installation must conform with applicable requirements of NFPA 211, and applicable building &... -
Page 4: Approved Venting Components
‚ All joints for connector pipe shall be required to be fastened with at least (3) screws. If vented horizontally, joints shall be made gas tight using high temp sealant, RTV, or metal tape at each joint. ‚ A clean out ‘tee’ must be installed directly to the stove and at the bottom of each vertical run of the vent (exhaust) system. - Page 5 Straight Pipe Length - Available in 6", 1', 2', 3, and 5' lengths. Adjustable Length Pipe - Provides 3" - 10" of adjustment when used with rigid sections of pipe. Wall Thimble Elbow Elbow Ceiling Support Firestop Spacer Square Horizontal Cap Round Horizontal Cap Attic Insulation Shield - Used for installations that pass through an...
- Page 6 Selkirk Metalbestos Direct Temp vent system components: Pellet Stove Adaptor - Allows pellet stove to connect to Direct-Temp vent system. Pellet Stove Termination Adapter - Used in conjunction with horizontal Tee with Tee cap exit cap, decorative cap, or vertical cap. Decorative Cone Cap Exit Cap Horizontal Termination Elbow -...
-
Page 7: Mobile Home Installations
Wall Thimble Combustion Air Kit Pipe Section Adjustable pipe section IMPORTANT: Installation must comply with the vent pipe manufacturer’s installation instructions, the requirements / restrictions as outlined in this installation manual and local building codes. MOBILE HOME INSTALLATIONS The stove may be installed in a permanently located, manufactured or mobile home where not prohibited by local codes. -
Page 8: Specifications
SPECIFICATIONS: Height : 35" Width: 23" Depth: 26 1/2" Base width: 20" Base depth: 23 5/8" Center of intake collar from right side: 12 1/2" Center of intake collar from left side: 9 1/2" Center of intake collar from floor: 7 3/8"... -
Page 9: Clearance To Combustibles
CLEARANCE TO COMBUSTIBLE MATERIALS: The installation of this free-standing stove must meet the following minimum clearance requirements: Sides of stove: ......3" Back of Stove . -
Page 10: Venting Illustrations
VENTING ILLUSTRATIONS: Horizontal Termination #1 Horizontal Termination #2 Typical Corner Installation Floor protection extends 6" in front of stove and extends to wall at back. Vertical Installation #1 Vertical Installation #2 Note: Not recommended for cold climate installations. Page 8... -
Page 11: Venting Termination Requirements
VENTING TERMINATION REQUIREMENTS: MAXIMUM HORIZONTAL RUN: 9 FT. MAXIMUM VERTICAL RUN: 36 FT. Determine the best location for the vent termination cap. Items to consider: ‚ Distances from air inlets - Installation must comply with the requirements in this installation manual, the requirements of the vent system you are using and local building codes. -
Page 12: Minimum Clearance Locations From Exhaust Terminations
MINIMUM CLEARANCE LOCATION FROM EXHAUST TERMINATION: 1. Above ground level: 12" (305 mm) 2. From a public walkway: 7' (2.1 m) 3. From the wall penetration point: 12" (305 mm) 4. From any adjacent combustibles - i.e.: fences, adjacent buildings, protruding parts of the structure, roof eaves or overhangs, plants, shrubs: 24"... -
Page 13: Combustion Air Requirements
COMBUSTION AIR REQUIREMENTS This stove requires the use of outside air for combustion. A 2" diameter aluminum flex pipe 4 ft. long is included with this stove to connect to the 2" collar located at the back. WARNING: THE COMBUSTION AIR PIPE MUST BE PROPERLY CONNECTED AND TERMINATED TO THE OUTDOORS FOR PROPER PERFORMANCE. -
Page 14: Electrical Components & Wiring Schematic
ELECTRICAL COMPONENTS This stove includes a combustion fan and room air fan with a 3-prong (grounding) plug. The fan must be plugged into a properly ground 3-prong outlet. The current required is approximately 3 amps (5 amps with the igniter is in operation). Run the power cord to the nearest outlet. -
Page 15: Thermostat Installation (Optional)
THERMOSTAT INSTALLATION (Optional) An optional thermostat is available for use on this stove. A thermostat will maintain a constant level of heat, resulting in optimal fuel consumption, ultimately lowering heat costs. This stove is pre-wired and capable of operating on a thermostat. A feature has been built into the circuit control board which delays the time between each heat setting to allow for the stove to react at each subsequent level. -
Page 16: Completing The Installation: Negative Pressure Check
COMPLETING THE INSTALLATION Negative Pressure check: A negative pressure check must be completed to verify proper operating conditions have been met. This reading must be written on the warranty card to validate the warranty. Procedure: 1. Open the right side and panel to access the vacuum switch and connections. -
Page 17: Warranty Policy
30 days of installation. Failure to do so may result in delayed warranty coverage. Hussong Manufacturing Co., Inc. warranties to the original purchaser of the Kozy Heat Model #OLV-PC ‘Olivia’ Corn/Pellet Stove, that it is free of defects in materials and workmanship at the time of manufacture.
