OPERATING
&
MAINTENANCE MANUAL
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE
Quality Fireplaces for Life
Contact local building or fire officials about restrictions
and installation inspection requirements in your area.
USE ONLY HIGH QUALITY FUEL IN THIS STOVE TO AVOID EXCESSIVE BUILD UP OF DUST IN
THE HOPPER AND AUGER SYSTEM WHICH CAN CREATE A DANGEROUS FIRE RISK.
Please read this entire manual before installation and use
of the pellet fuel burning room heater.
Failure to follow these instructions could result in property
damage, bodily injury or even death.
MAINTENANCE INSTRUCTIONS MUST BE FOLLOWED
TO OBTAIN OPTIMUM PERFORMANCE AND TO AVOID
POTENTIAL FIRE RISK.
WOODLAND OPERATING JULY 08-REV01
Advertisement
Related Manuals for kozy heat Woodland WLD-P
Summary of Contents for kozy heat Woodland WLD-P
- Page 1 OPERATING & MAINTENANCE MANUAL INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE Quality Fireplaces for Life Contact local building or fire officials about restrictions and installation inspection requirements in your area. USE ONLY HIGH QUALITY FUEL IN THIS STOVE TO AVOID EXCESSIVE BUILD UP OF DUST IN THE HOPPER AND AUGER SYSTEM WHICH CAN CREATE A DANGEROUS FIRE RISK.
-
Page 3: Table Of Contents
Diagnostic Features……………………………………………...10 Maintenance Instructions…………………………………………………………………..….8-10 Daily Maintenance………………………………………………...8 Weekly Maintenance…………………………………………...…9 2-Month Maintenance…………………………………………9-10 Annual Maintenance…………………………………………….10 Troubleshooting…………………………………………………………………………………..11 Control Board Diagnostics Troubleshooting…………………………………………………...11 Replacement Parts…………………..………………………………………………………..12-13 Description……………………………………………………….12 Illustration………………………………………………………..13 Complete warranty information and return to: Kozy Heat Fireplaces Attention: Warranty Registration P.O. Box 577 Lakefield, MN. 56150 Page 1... -
Page 5: Features
#WLD-P WOODLAND PELLET STOVE Figure shown with optional decorative grill. Circuit Control Board Hopper Capacity: 80 lbs Heat Exchange Tube Cleaner Hearth Extension Ash Dump Handle Ash Drawer with easy access Electronic Ignition - Standard Thermostatic Control - Optional (recommended) Page 2... -
Page 6: Safety Information
SAFETY INFORMATION INSTALLATION: This stove must be installed by a qualified installer in accordance with the installation manual provided. Improper installation and /or maintenance may create a fire hazard, resulting in an unsafe condition, poor performance, and may void your warranty. Please read this entire manual before operating this stove. -
Page 7: Safety Devices
SAFETY DEVICES High Limit Switch - The high limit switch is an ‘overheat’ safety switch which shuts off fuel feed if the stove exceeds temperatures above the normal operating temperature. This switch is a manual reset type. Proof of Fire Switch - (P.O.F). Responds to temperature rise in the exhaust system. The stove will stop operating if temperatures above 120°F are not met during startup or drops below 90°... -
Page 8: Circuit Control Board
CIRCUIT CONTROL BOARD FUNCTIONS A. ON/OFF: Turns the circuit control board ‘ON’ and ‘OFF’. It is also used to ‘reset’ the board after switching to Diagnostic mode. The ON/OFF LED light will blink for the first 10 minutes. When successful start-up is achieved, the light will remain steady. -
Page 9: Operating Instructions
OPERATING INSTRUCTIONS FOR USE WITH WOOD PELLETS ONLY Contact your dealer for information on where to purchase high quality wood pellets. STORAGE: To prevent moisture absorption, wood pellets should be left in their original sealed bag until using. Pellets with excessive mois- ture may swell and plug auger. -
Page 10: Prior To Each Burn
PRIOR TO EACH BURN Check ash drawer capacity. (Located under the hearth extension). Turn handle counter-clockwise to unlatch ash door. Ash drawer is located directly behind ash door. Slide drawer out, check capacity, empty if necessary. DISPOSAL OF ASHES: Ashes should be placed in a metal container with a tight fitting lid. The closed container of ashes should be placed on a noncombustible floor or on the ground, well away from all combustible materials, pending final disposal. -
Page 11: Diagnostic Features
DIAGNOSTIC FEATURES The following diagnostic information is being provided in the event the stove is not functioning properly. It will guide you through possible problems and solutions. POWER RESET: When all lights on control board are simultaneously lit and the circuit control board is not responding: Unplug stove. -
Page 12: Weekly Maintenance
WEEKLY MAINTENANCE addition to daily maintenance, the following procedures should be performed on a weekly basis during heating season. This will ensure proper performance and maximize efficiency. CAUTION: Turn the stove ‘OFF’ and allow time to cool before handling any components. CLEANING TOOLS NEEDED: Whisk broom or soft bristled paintbrush, 1”... -
Page 13: Diagnostic Features
♦ Re-install center panel at back of firebox, aligning tube around igniter probe. Igniter must extend to end of tube. ♦ Re-install left & right combustion passageway panels. Secure with wing nuts previously removed. Do not overt tighten. ♦ Angle burn pot into firebox, inserting ash dump rod through hole in firebox side. Insert tabs on back side of burn pot into slots in center panel. -
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM REASON SOLUTION Loss of fire. Intake air damper open too far. Close intake air damper until fire is established. Weather and venting will affect intake setting. Auger empty at start up. Press ‘Auger’ button to feed fuel to burn pot. High wind directed toward Block wind from termination cap. -
Page 15: Replacement Parts
REPLACEMENT PARTS Replacement parts are available through your local dealer. Contact them for availability and pricing. PART NUMBER DESCRIPTION WLD-BRD CONTROL BOARD WLD-POT BURN POT ASSEMBLY (5 PC.) WLD-BPH BURN POT HOUSING WLD-ADP ASH DUMP PANEL WLD-ADR 1/4” ASH DUMP ROD WLD-ADH ASH DUMP HANDLE 500114 HANDLE SPRING WLD-606 ASH DRAWER... -
Page 16: Illustration
Page 13...
