Installation with PRO-VAQ E)
1
• Follow the steps below for installing the Scale Control with a Quooker
• The 'Q' on top of the tank is the on/off switch.
1
3
PRO3-VAQ, PRO7-VAQ, PRO3-VAQ E or PRO7-VAQ E tank.
2
4
1 Disconnecting
Switch off the tank. Leave the plug in
the socket. Open the boiling-water
tap and let the water run cold. Close
the stop valve on the inlet combina-
tion. Close the tap. Disconnect the tank
inlet hose from the inlet combination.
2 Connecting
Disconnect the head by unscrewing
the grooved knob on top of the Scale
Control. Connect the reducing coupler
to the inlet combination with the fibre
washer. Connect the Scale Control inlet
hose long) to the reducing coupler.
Connect the Scale Control outlet hose
short) to the tank inlet hose with the
fibre washer.
3 Placing
Place the Scale Control into the
kitchen cupboard. Ensure that the
grips of the lid and the container are
aligned. Screw the head firmly into
the lid of the Scale Control.
4 Flushing
Open the inlet combination stop valve
and the boiling-water tap and leave the
water running until it is clear. Switch on
the tank. The Quooker is ready for use
as soon as the water has heated up.
