MODEL: PL8304SS / PL8BLK - Outdoor Pizza Oven without cart
ASSEMBLY AND OPERATING INSTRUCTIONS
1. This is instruction manual contains important information necessary for the proper
assembly and safe use of the appliance.
2. Read and follow all warnings and instructions before assembling and using the appliance.
3. Follow all warnings and instructions when using the appliance.
4. Keep this manual for future reference.
Note to installer: Leave this Owner's Manual with the consumer after delivery and\or installation.
Note to customer: Leave this Owner's Manual in a convenient place for future reference.
△ ! DANGER
1. Do not store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use should
not be stored in the vicinity of this or any other
appliance.
△ ! DANGER
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3.05m) of any other gas cylinder.
3. Never operate this appliance with 25 feet (7.5m) of any flammable liquid.
4. If a fire should occur, keep away from the appliance and immediately call your fire
department. Do not attempt to extinguish an oil or grease fire with water.
5. Heated liquids remain at scalding temperatures long after the cooking process. Never touch
cooking appliance until liquids have cooled to 115oF (45oC) or less.
Failure to follow these instructions could result in fire, explosion or burn hazard, which could
cause property damage, personal injury or death.
△ ! WARNING: FOR OUTDOOR USE ONLY
△ ! DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open oven door.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Failure to follow these instructions could
result in fire, explosion or burn hazard, which
could cause property damage, personal
injury or death.
1
