Summary of Contents for Pacific Living PL8430SSBG070

Page 1 1. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. MODEL # PL8430SSBG070 with cart included 2. An LP tank not connected for use should not be stored in the vicinity of this or any other appliance.
Page 2: Oven Operation
ATTACH YOUR RECEIPT HERE Serial Number____________________ Purchase Date____________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-866-410-0408, Monday - Friday, 8 a.m. - 5 p.m., PST. Oven Operation 1-2-3 Before Cooking: Step 1 Keep your oven a safe distance away from your property.* Step 2 Always perform a leak test.*...
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Information…………………………………….………...….………….………….…………. 4 Package Contents…..………………..…..….……...…....………………………………. 6 Hardware Contents……………………………………………………………….………………….. 7 Assembly Instructions………………..……………….……………………………………………..8 LP Gas Assembly……………………………………………………..........15 Natural Gas Conversion ……………………………………………………………………………. 21 Operating Instructions..………………………….……...……………………………....29 Care and Maintenance……………………………….……………………………………………… 31 Troubleshooting …………………………………………………………………..….……………... 40 Warranty……………………………………………………………………………………………….. 42 Explored Diagram……………….……………………………………………………………….….. 43 Replacement Parts List…….………………………………………………………………………..44...
Page 4: Safety Information
Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 1-866-410-0408 Monday to Friday from 8 a.m. to 5 p.m. PST. 1.
Page 5 Safety Information 15. Use only the gas pressure regulator supplied with this appliance. This regulator is set for an outlet pressure of 11.0 WC. 16. The cylinder used must include a collar to protect the cylinder valve 17. Do not store a spare LP-gas cylinder under or near the appliance 18.
Page 6 PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Main Body Fat Cup Cooking Grill Smoker Box Pizza Stone Flame Tamer Bottom Grill...
Page 7 HARDWARE CONTENTS The following list is included inside the outdoor oven carton: Battery 1 pc The following list is not included inside the outdoor oven carton, but needed when the user is assembling the outdoor oven. Phillips Head Screwdriver 1 pc The following list is NOT included inside the outdoor oven carton but is included inside the NG Conversion Kit.
Page 8: Package Contents
ASSEMBLY INSTRUCTIONS Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Assembly tip! (Please lightly tighten the screws during assembly of the cart. When the cart is completed THEN TIGHTEN ALL THE screws.
Page 9 3. Use screw M6*12×2 pcs to fix the left side panel onto the base panel of the stand. (Note: The panel should have the “small holes at the top” to the front of the cart assembly) 4. Use screw M3*12×2 pcs and nut M3×2 pcs to attach the door magnet onto the right side panel.
Page 10 6. Use screw M4*10×4 pcs and nut M4×4 pcs to attach the transformer assembly onto the outside of the back panel of the stand. (Note: These screws can be tightened at this time) 7. Use screw M6*12×5 pcs to attach the stand base panel onto the base panel, between the two side panels.
Page 11 8. Use screw M4*10×4 pcs to fix the stand door horizontal beam between the two side panels. (Note: Please fasten the upper two screws first, and then the lower two screws.) 9. Use screw M4*10×4 pcs to fix the stand top panel on the top of the two side panels and back panel.
Page 12 11. First, insert the door lower axis into the hole in the base panel. Next, push down the door upper spring axis and let go of the spring when it is pointed to the hole in the horizontal beam. (Note: You may need to add 1 or 2 washers 18*6.4*1 on the bottom pin so the door will close evenly)
Page 13 13. Use screw M5*10×16 pcs to attach side shelf bracket×4 pcs onto the drawer side panels. (Note: Arrows face UP) 14. Using one of the screw M5*10 to fix the match holder onto the front bracket of right side shelf. (This step may be skipped if you do not want or need a “match holder”...
Page 14 16. Use screw M4*8×3 pcs to fix the chimney assembly onto the top of the oven exterior. (Note: These screws can be tightened at this time) 17. Use screw M5*35×4 pcs to fix the back heat shield onto the back panel of the oven.
Page 15 19. Insert the fat cup into the back of the oven. 20. Insert the battery into the electronic ignition. Unscrew the button and place battery positive (+) tip facing OUT. Screw button back on. Your complete outdoor oven is now assembled.
Page 16 5. Make sure all burner knobs are in the OFF position. 6. Connect the hose and regulator assembly to the tank valve (See Fig. 6). Hand-tighten the quick coupling nut clockwise to a full stop. Fig. 6 DO NOT use a wrench to tighten because it could damage the quick coupling nut and result in a hazardous condition.
Page 17 WARNING: The Type I connective coupling (see Fig. 7) supplied with your oven must not be replaced with a different type of oven/tank connection system. Removal will result in loss of warranty, gas leakage, fire and severe bodily harm. Thermally Propane Sensitive Nut Regulator...
Page 18 L.P. TANK INFORMATION Never use a dented or rusted L.P. tank or cylinder with a damaged valve. L.P. cylinders are equipped with an O.P.D. (Overfilling Prevention Device). The device shuts off the flow of gas to a cylinder after 80% capacity is reached. This limits the potential for release of gas when the cylinder is heated, averting a fire or possible injury.
Page 19 PRE-OPERATION LEAK TESTING Although all gas connections on the oven are leak tested prior to shipment, a complete gas tightness check must be performed at the installation site due to possible shifting during shipment, installation or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks and immediately check the system if the smell of gas is detected.
Page 20 WARNING Do not use the oven in garages, breezeways, sheds or any enclosed area. Never operate the oven in enclosed areas as this could lead to a carbon monoxide buildup, which could result in injury or death. Place the oven on a level surface. Avoid moving the oven while it is in operation.
Page 21 WARNING: Place the oven on a flat, level surface. Before the conversion, make sure all control knobs are in the OFF position, LP tank valve is closed, and tank is disconnected from regulator and removed from oven. NG CONVERSION INSTRUCTION: Before the conversion, make sure all control knobs are in the OFF position, LP tank valve is closed, and tank is disconnected from regulator and removed from oven.
Page 22 Use a screwdriver to loosen the screw that is used to fasten the burner cover. Turn the burner cover until the hole marked “NG” overlaps with the fixing hole on the burner. Put the screw back into the holes and tighten again. Use orifice removal tool to remove theφ1.2 LP orifice from the pizza oven.
Page 23 Put the burner back into the oven and insert the ignition wire into the original position. Use the 10x12 mm spanner to fix the thermocouple back into the oven again. Finally, fasten the burner with the original screws. Put back the two cooking grills, smoker box, pizza stone and base grill into the right position.
Page 24 Use the screw driver to put the conversion screw into the knob. When converting to natural gas, please be aware that the low heat setting of the main burners and searing burner is “NG LOW,” as shown on the control panel. “LP LOW”...
Page 25 IMPORTANT: After your outdoor kitchen is converted to natural gas, the working pressure for natural gas is 7-inche water column (WC). Gas pressure is affected by gas line size and the length of gas line run from house. Follow the recommendations in the chart below. From House to Oven Distance Tubing Size...
Page 26 Never attach an unregulated gas line to the appliance. Connection to an unregulated gas line can cause excessive heat or fire. Verify the type of gas supply to be used, either Natural Gas (N.G.) or Liquid Propane (L.P.), and make sure the serial plate agrees with that of the supply. Conversion kits are available separately for an additional cost, which will enable you to convert your oven from L.P.
Page 27 Clearance to combustible construction: A minimum of 61 cm (24 inches) from the sides and back must be maintained from the gas oven above and below the cooking surface to adjacent vertical combustible construction. Clearance to non-combustible construction: A minimum of 61 cm (24 inches) clearance from the back of the oven to non-combustible construction is required for the lid to fully open.
Page 28 WARNING Heat and smoke exhaust out of the chimney and the ventilation holes on the bottom of two oven side panels (See Fig. 8). Make sure to keep anything that could be damaged by heat or smoke away from the heat and smoke exhaust holes.
Page 29: Operating Instructions
Turn the control knobs to the OFF position when not in use. Keep any electrical supply cords and the fuel supply away from any heated surfaces. ** SEE DETAILED LIGHTING INSTRUCTIONS ON INSIDE DOOR OF CART PANEL (for PL8430SSBG070) and on rear heat shield panel (for PL8430SS & PL8304SS). **...
Page 30 USING THE OVEN LIGHT Light Operation Instruction 1. Make sure the light’s power switch on the control panel is in the “OFF” position. 2. Connect power plug to properly grounded outlet. 3. Turn the light’s power switch to “ON.” WARNING Keep any electrical supply cord away from any heated surface.
Page 31: Care And Maintenance
Care & Maintenance GENERAL MAINTENANCE - Keep outdoor cooking gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. - Do not obstruct the flow of combustion and ventilation air. - Keep the ventilation openings of the cylinder enclosure free and clear from debris. - Visually check the burners.
Page 32 The drip tray should be cleaned periodically according to the using situation. NOTE: Allow the drip tray to cool before attempting to clean. OVEN RACKS The oven racks can be cleaned immediately after cooking is completed and after turning off the oven.
Page 33 Definitions: (+) Guard – Guard is a portion of portable luminaries unit that prevents inadvertent contact with the bulb. It may be integrated with the UV filter or lamp containment barrier or as part of an enclosure or shade. (+) Lamp containment barrier – lamp containment barrier is a portion of a portable luminaries unit that encloses the bulb.
Page 34 3. Use screw driver to loosen the screw that fix the light assy. 4. Use one hand to hold the metal back part of the light and one handle to hold the front glass cover and then take them apart. Then you can replace the bulb.
Page 35 6. Use M4*10 screw to fix the light assy. on to the back panel of the oven. 7. Use screw M5*35×4 pcs to fix the back heat shield onto the back panel of the oven. The order is: screw→back heat shield→heat insulation washer→flat washer→...
Page 36 8. Finally, put back the two cooking grills, smoker box, pizza stone, base grill and flame tamer into the oven. Now you have finished replacing the bulb. Cleaning Method Follow Steps below for glass cover removal. Use a damp towel to clean the surface of glass cover.
Page 37 Replacing Battery for Electrical Igniter: 1. Remove the igniter cap by turning clockwise; 2. Replace the battery; 3. When installing new battery, ensure it is installed with the proper polarity; 4. Put on the igniter cap back by turning counterclockwise. WARNING: 1.
Page 38 2. Loosen the M4*10 screw * 7 pcs that fix the door exterior and interior, and then loosen the M4*10 screw * 4 pcs that fix the door hinge. Then loosen the shoulder screw that attaches the door handle. 3. Use spanner 19# to loosen the nut that fix the temperature gauge.
Page 39 5. Use spanner or hand directly to tighten the nut that fix the temperature gauge on the glass. You can set the torque of the spanner at 4.0kgf*cm. 6. Use M4*10 screw * 4 pcs to fix the door onto the oven. Now you have finished cleaning the oven door.
Page 40: Troubleshooting
TROUBLESHOOTING Many solutions given here can make your cooking experience safer and more enjoyable. You can also call the customer service department at 1-866-410-0408, 8 a.m. – 5 p.m., PST, Monday to Friday. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Oven will not 1.
Page 41 TROUBLESHOOTING Burner Orifice Size Φ1.8 mm Main Burner 2. Clear ports of any obstructions. 3. Refill the LP tank. Low heat, LP The propane regulator assembly Please follow these instructions: 1. Make sure all burners are “OFF.” gas. incorporates an excess flow device designed to supply the oven with 2.
Page 42: Warranty
Pacific Living Outdoor Ovens are covered under manufacturer warranty for one full year from the date of purchase. The warranty is for parts and labor and at the discretion of Pacific Living the unit will be repaired or replaced under the terms of this warranty.
Page 43 Exploded Diagram For replacement parts, call our customer service department at 1-866-410-0408, 8 a.m. – 5 p.m., PST, Monday to Friday.
Page 44 Exploded Diagram Part Name Part Name Heat spacer Grease tray left bracket Back heat-shield Oven back support Light assy. Grease tray right bracket Light bracket Oven right supporting assy. Handle latch Light transformer Gas pipe Match holder Chimney assy. Camp stove superior girder Cooking grill Right side shelf bracket Smoker box assy.
Page 45: Replacement Parts List
Replacement Parts List 1 、 BG070-01 2. BG070-02-00B Oven BG070-24 Burner 4. BG070B-03-01 Oven Oven Interior * 1 pc Bracket Beam * 1 pc Back Panel * 1 pc Exterior * 1 pc BG070-03A Oven 6. BG070-10-00B Burner BG070-18 Cooking BG070-17B Base Back Heat Shield * 1 pc...
Page 46: Flame Tamer
Replacement Parts List BG070B-38 Oven BG070-30 Temp. 27. BG070-12-00 Oven BG070-76-00 Door Glass * 2 pc Gauge * 1 pc Door Handle Assy. * 1 pc Sideshelf * 2 pcs 29. BG070B-30-01 Left 30. BG070B-30-02 Right 31. BG070B-57-00 Oven 32. BG070B-58-00 Oven Sideshelf Bracket * 2 Sideshelf Bracket * 2 Left Holder Panel * 1 pc...
Page 47 Replacement Parts List 49. BG070B-53 Trolley 50. BG070B-54 Trolley BG070B-50-00 BG070B-51-00 Top Panel * 1 pc Door Horizontal Beam * Trolley Left Sidepanel Trolley Right Sidepanel 1 pc Assy. * 1 pc Assy. * 1 pc 53. BG070B-52 Trolley 54. BG070B-55 Trolley 55.
