INSTALLATION MANUAL & OWNER'S GUIDE
®
ULTRAVIOLET WATER TREATMENT SYSTEMS
UVB SERIES
UV20 SERIES
UVBB SERIES
RACK SYSTEM
UV1 SERIES
ADDON SERIES
36103017 Rev. 5/10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UVB SERIES and is the answer not in the manual?

Questions and answers

Summary of Contents for Pura UVB SERIES

  • Page 1 INSTALLATION MANUAL & OWNER’S GUIDE ® ULTRAVIOLET WATER TREATMENT SYSTEMS UVB SERIES UV20 SERIES UVBB SERIES RACK SYSTEM UV1 SERIES ADDON SERIES 36103017 Rev. 5/10...
  • Page 2: Introduction - Descriptions And Definitions

    You have purchased one of the most technologically advanced Ultraviolet Water Treatment System available anywhere in the world. It ® has been designed with you, the consumer, in mind. PURA products are lightweight, easy to use, and simple to maintain. PURA products will provide you with healthy, clean drinking water for years to come. WHAT IS ULTRAVIOLET?
  • Page 3: Routine Maintenance

    Refer to Mounting Bracket and System Plumbing Installation Instructions on Page 1, and the appropriate System Assembly and Activation Procedures for detailed information to install your specific PURA system. Cleaning: The inside of the system and the quartz sleeve Filter Replacement: Filters will normally last should be cleaned each time the filters are changed.
  • Page 4: Install Mounting Bracket

    This Guide covers installation and maintenance of a basic “generic” system. Installer determines configuration of each system and must adapt these instructions to meet the specific requirements for that configuration. Specific component and assembly information is provided only for components that are unique to PURA systems. All inter-component connections use standard plumbing components and tools.
  • Page 5 UVBB SERIES - SYSTEM ASSEMBLY AND ACTIVATION PROCEDURES Remove Quartz Sleeve (Item 17) from packing tube. PREPARATION – INSPECT ALL PARTS While holding middle of quartz sleeve with one hand, slide NOTE: Read Mounting Bracket and System Plumbing protective bag with other hand to expose open end. Installation instructions on Page 1 and all instructions on this page before installing system.
  • Page 6: Activate System

    Turn on water supply and check for leaks. Flush system, connectors, and water lines for several minutes to remove carbon fines. ACTIVATE SYSTEM NOTE: When an ultraviolet water treatment system is unused CAUTION: Verify that inlet and outlet ports are connected to for several hours, water within system could become appropriate inlet/outlet pipes (see Figure 3).
  • Page 7: Cleaning Procedure

    CLEANING, DISINFECTING, AND ROUTINE MAINTENANCE PROCEDURE RECOMMENDATIONS HAVE ALL COMPONENTS ON HAND AND READY BEFORE BEGINNING PROCEDURE A CLEAN WORK AREA AND EQUIPMENT ARE ESSENTIAL TO PROPERLY CLEAN AND/OR DISINFECT THE SYSTEM (i.e., CLEAN HANDS, TOOLS, WORK SURFACE, AND CONTAINERS) EQUIPMENT NEEDED Safety Glasses Liquid Dish Soap...
  • Page 8 4. Slowly open the feed water supply valve. CAUTION: Do not attempt to remove sumps until water flow stops. This reduces pressure inside the 5. Open all downstream faucets. Keep faucets open until a system so sumps may be safely removed. chlorine smell is detected at each faucet, then close faucets.
  • Page 9 INSTALL QUARTZ SLEEVE Insert quartz sleeve into the UV head. As quartz sleeve passes “O” Rings, resistance will be felt. Remove CAUTION: QUARTZ SLEEVE IS VERY FRAGILE! protective bag from quartz sleeve. For safety, wear a protective glove when handling quartz sleeve. Do not touch quartz sleeve or UV lamp with bare hands.
  • Page 10: Limited Warranty

    PURA specifications. If the drinking water system is modified by anyone other than an authorized PURA dealer, the warranty shall be void.
