EXPLODED PARTS LIST (VX2025wm-1)
ViewSonic Model Number: VS10859
Rev: 1b
Serial No. Prefix: Q6Y
Item ViewSonic P/N
1 M-MS-0808-9243
2 M-MS-0808-9402
3 N/A
4 N/A
5 M-SCW-0824-6802
6 E-00005213
7 N/A
8 M-MS-0808-9401
9 N/A
10 N/A
11 N/A
12 N/A
13 N/A
14 N/A
15 M-SCW-0824-0813
16 N/A
17 M-SCW-0824-6799
18 N/A
19 B-00005205
20 N/A
21 CB-00002525
22 N/A
23 B-00006115
24 CB-00005210
25 M-MS-0808-8986
26 CB-00004151
27 N/A
28 N/A
29 M-MS-0808-9248
30 N/A
31 M-MS-0808-9411
32 M-SCW-0824-6895
33 N/A
34 N/A
35 M-SCW-0824-6859
36 M-MS-0808-9253
37 M-MS-0808-9815
38 N/A
39 M-CV-0830-2593
40 M-LB-0813-0745
41 C-BS-0303-0553
42 M-MS-0808-9812
43 PL-00008022
44 N/A
45 M-MS-0808-9811
46 M-SCW-0824-0813
47 N/A
48 M-SCW-0824-0795
49 N/A
50 N/A
51 M-SCW-0824-6894
52 M-MS-0808-9404
53 C-00001778
ViewSonic Corporation
Ref. P/N
FEL7V003019 LOGO FRONT-VSC-38MM L7VC(REV3A)GP
FEL7V007014 BIRD LOGO L7VD(FEL7V007,REW3A)GP
EAW0VX01017 LCD MARK WOVX(EAW0VX01,REV3A)GP
EAW0VX02013 LCD BEZEL W0VX(EAW0VX02,REV3A) GP
MM30040IBJ9 SCREW M3.0*4.0-I(NI) GP
DN0TE230F06 SPEAKER ASSY L9VDQ FG-TE230 GP
EBL9V004018 CONTROL BUTTON L9VDQ-4(EBL9V004,R3A) GP
EBL7V028019 LENS L7VD(EBL7V028,REV3A)GP
23L7VDBB001 L7VD BUTTON/B ASSY GP
FBL9V011014 LCD PANEL LOCK METAL L9VDQ(R3A)GP
MF30080IBJ0 SCREW F3.0*8-I(NI)GP
MM30030IBJ4 SCREW M3*3-I-NI GP
FAW0VX02013 LCD BKT-R W0VX(FAW0VX02,REV3A) GP
AAM201EW066 LCD 20" M201EW01 V.3 FOR VSC CON GP
MF30060BBJ6 SCREW F3.0*6-B(NI)GP
FAW0VX03010 LCD BKT-LW0VX(FAW0VX03,REV3A) GP
MM35080BBW2 SCREW M3.5*8-B(NI,WASHER)GP
FCW0VA03012 INVETER MYLAR-DOWN W0VA GP
AS023360D18 INV MODULE(SEL)W0E(20V,I=6MA) GP
21W0VAMB029 W0VA-A M/B ASSY (NOVATEK 68563H) GP
DD0L9VLC015 CABLE MB-LCD(30P,140MM)L9V-5 GP
FCW0VX01019 POWER MYLAR W0VX(FCW0VX01,REV3A) GP
AS08B532017 PWR MODULE(DTA)EADP-64CF BA,90~264V GP
DDW0VXBU006 CABLE MB-BUTTON(8P/11P,240MM)W0VX GP
MBLI1004018 IO NUT LI1(MBLI1004,REV3A)GP
DD0W0EIV008 CABLE MB-INV(7P/8P,320MM)W0E GP
FBL5T009018 AL-FOIL(40-47) L5TD(FB5T009,REV3A) GP
FAW0VX01017 PCB SHIELDING W0VX(FAW0VX01,REV3A) GP
FCL7A001014 AL FOIL L7A(FCL7A001,REV3A) GP
FCL7G001016 AL FOIL L7G(FCL7G001,REV3A)HAN GP
FBL70008014 LOCK METAL L70B(FBL70008,REV3A) GP
MF40080IBJ1 SCREW F4.0*8-I(NI)GP
FAL9V003011 HINGE BKT L9VDQ-4(FAL9V003,REV3A) GP
EAW0VX03010 LCD COVER W0VX(EAW0VX03,REV3A) GP
MM40060IL69 SCREW M4*6-I(BNI)(NYLOK) GP
FEL7V005011 LOGO PLATE ELLIPSE L7VC(REV3A)GP
GAL9V002014 RUBBER PLUG VESA L9V(GAL9V002,REV3A)GP
HCW0VX02015 ID LABEL W0VX-A(HCW0VX02,REV3A) GP
EBL9V003011 I/O COVER L9V(EBL9V003,REV3B)GP
HCL7V002011 SERIAL LEBAL L7V(HCL7V002,REV3A) GP
EAL9V004017 STAND BASE L9V(EAL9V004,REV3A) GP
EBL9V001019 STAND COVER F L9V(EBL9V001,REV3A)GP
FAL9V006010 STAND BASE L9VDQ-4(FAL9V006,REV3A) GP
EAL9V005013 STAND BKT COVER L9V(EAL9V005,REV3A)GP
GAL5M002011 RUBBER FOOT L5M(GAL5M002,REV3B)GP
MF30060BBJ6 SCREW F3.0*6-B(NI)GP
FAW0VX04016 HINGE ASSY W0VX(FAW0VX04,REV3A) GP
MM40080BCI5 SCREW M4.0*8-B(NI,NYLOK)GP
MM40060BCI6 SCREW M4.0*6-B(NI,NYLOK) GP
EBL9V005014 HINGE COVER L9VDQ-4(EBL9V005,R3A) GP
MF30060BJ28 SCREW F3.0*6-B(BNI)GP
EBL7V029015 WIRE CLAMP L7VD(EBL7V029,REV3A)GP
EBL9V002015 STAND COVER R L9V(EBL9V002,REV3A)GP
