(108-125) Detailed Timing / Descriptor Block 4:
Monitor Name:
VX2025wm
(126) No Extension EDID Block(s)
(127) CheckSum OK
5.2. Digital EDID: Digital EDID is stored in IC4.
Appendix F : Digital EDID
______________________________________________________________________
EDID Block 0, Bytes 0-127
128 BYTES OF EDID CODE:
0 1 2
________________________________________
0 | 00 FF FF FF FF FF FF 00 5A 63
10 | 1D E5 01 01 01 01 01 0F 01 03
20 | 80 2B 1B 78 2E CF E5 A3 5A 49
30 | A0 24 13 50 54 BF EF 80 B3 0F
40 | 81 80 81 40 71 4F 31 0A 01 01
50 | 01 01 01 01 21 39 90 30 62 1A
60 | 27 40 68 B0 36 00 B1 0F 11 00
70 | 00 1C 00 00 00 FF 00 51 36 59
80 | 30 35 30 31 30 30 30 30 31 0A
90 | 00 00 00 FD 00 32 4B 1E 52 11
100 | 00 0A 20 20 20 20 20 20 00 00
110 | 00 FC 00 56 58 32 30 32 35 77
120 | 0A 20 20 20 20 20 00 6A
______________________________________________________________________
(08-09) ID Manufacturer Name ________________ = VSC
(11-10) Product ID Code _____________________ = E51D
(12-15) Last 5 Digits of Serial Number ______ = Not Used
(16) Week of Manufacture _________________ = 01
(17) Year of Manufacture _________________ = 2005
(10-17) Complete Serial Number ______________ = See Descriptor Block
(18) EDID Version Number _________________ = 1
(19) EDID Revision Number ________________ = 3
(20) VIDEO INPUT DEFINITION:
Digital Signal
Non - VESA DFP 1.x Compatible
