ViewSonic VX2025wm-1 Service Manual page 11

nd
2 Source Panel
Model number
Type
Active Size
Pixel Arrangement
Pixel Pitch
GLASS TREATMENT
# OF BACKLIGHTS
BACKLIGHT LIFE
Luminance (5-point) –
Condition:
CT = 6500K, Contrast = Max, Brightness = Max
Brightness Uniformity
Contrast Ratio
Color Depth
Viewing Angle (Horizontal)
Viewing Angle (Vertical)
Response Time
10%-90% @ Ta=25°C
Panel Defects
MECHANICAL
Dimension (Desktop)
Width
Height
Depth
Monitor Weight
Dimension (Head Only / Wall Mount)
Width
Height
Depth
Monitor Weight
Ergonomics
Tilt Up
Tilt Down
ViewSonic Corporation
AUO M201EW01 V3
AMVA type with LVDS interface
433.44 (H) x 270.9(V)
RGB Vertical Stripe
0.258 mm
Anti Glare (Hard coating 3H)
6 CCFL
40,000 Hours (Min)
300 cd/m2 (Typ after 30 minute warm up)
240 cd/m2 (Min after 30 minute warm up)
≧80% (Typ), 75% (Min),
1000:1 (typ), 750:1 (min)
16.7 million colors (8 bits)
@ CR>10
Typical: 178º
Minimum: 150º
@ CR>5
Typical: T.B.D
Minimum: T.B.D
@ CR>10
Typical: 178º
Minimum: 150º
@ CR>5
Typical: T.B.D
Minimum: T.B.D
Tr = 25 ms,Tf = 15 ms Total = 40ms (max)
Tr =11 ms,Tf = 5ms Total =16ms(typ)
Without OD Board (gray –gray)
(Average of Tr and Tf) = 8 ms (typ)
Please see Panel Quality Specifications.
484.6 mm (19 inch)
441.3 mm (17.3inch)
201 mm (7.9 inch)
6.3 Kg (13.89 lbs)
484.6 mm (19 inch)
340.1 mm (13.4 inch)
67.1 mm (2.6 inch)
5 Kg (11.02 lbs)
≧
From 0º up to 20º
From 0º down to -3º ~ -5 º
Confidential - Do Not Copy
8
VX2025wm-1
