AKX-CH(RS)-CH5-[AKX-CH5]-EN

AKX-CH5/AKX-CH5-1BAM/AKX-CH5-2WSS

DIRECTED SMARTSTART & ADS-HRN(RS)-SM01 (OPTIONAL)

notice

The manufacturer will accept no responsability for any electrical

damage resulting from improper installation of this product, be that either

damage to the vehicle itself or to the installed device. This device must be in-

stalled by a certified technician. Please review the Installation Guide carefully

before beginning any work.

instaLL guiDe

Document numbeR

15975

Revision Date

20140807

FiRmwaRe

AKX-CH(RS)-CH5-[AKX-CH5]

haRDwaRe

accessoRies

ADS-USB (REQUIRED)

COMPATIBLE RF-KIT (OPTIONAL)

beFoRe instaLLation

1- Connect module to computer

2- Login to Weblink account

3- Flash firmware to module (module is not preloaded with firmware)

4- Use accessories accordingly (accessories are sold separately)

www.autokinetix.com

Need help?

Do you have a question about the AKX-CH5 and is the answer not in the manual?

Questions and answers

Summary of Contents for AKX AKX-CH5

Page 1 AKX-CH(RS)-CH5-[AKX-CH5]-EN Document numbeR 15975 Revision Date 20140807 FiRmwaRe AKX-CH(RS)-CH5-[AKX-CH5] haRDwaRe AKX-CH5/AKX-CH5-1BAM/AKX-CH5-2WSS accessoRies ADS-USB (REQUIRED) COMPATIBLE RF-KIT (OPTIONAL) DIRECTED SMARTSTART & ADS-HRN(RS)-SM01 (OPTIONAL) notice beFoRe instaLLation The manufacturer will accept no responsability for any electrical damage resulting from improper installation of this product, be that either 1- Connect module to computer damage to the vehicle itself or to the installed device.
Page 2 • • • • • • • • • • 5500 chassis cab AT • • • • • • • • • • • • • * May require additional parts. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 3 BLUE BLACK TELEMATIC PORT AFTERMARKET HOOD SWITCH AND CABLE BLACK BLACK WHITE WARNING STICKER WEBLINK CABLE (required accessory sold separately) WEBLINK CABLE MODULE COMPUTER WEBLINK PORT USB PORT 4 PIN BLACK CABLE Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 4 BEFORE INSTALLATION (NC) RED (NC) BLACK BLUE MODULE BLACK RF PORT BLUE CABLE RF DECODER BLACK CABLE ANTENNA TELEMATIC KIT (accessories sold separately) ADS-HRN(RS)-SM01 DIRECTED SMARTSTART (NC) MODULE TELEMATIC PORT (NC) (NC) Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 5 Ignition switch Starter Black 5 pin Pink/Orange Ignition switch Parking Light* White/Purple Driver kick panel Grand Cherokee 05-07 Driver Door Pin Purple/Blue Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 6 CONNECT IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (+) WITHOUT OEM HOOD SWITCH: INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH PARKING LIGHT (+) DRIVER DOOR PIN (-) OPTIONAL HORN (-) AFTERMARKET HOOD SWITCH (-) Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 7 FAULTY CONNECTIONS AND PRODUCT MALFUNCTION STEP 3: STEP 3: -INSERT THE WIRE IN PIN 6 OF THE CONNECTOR, RIGHT NEXT TO WHERE IT USED TO BE. -INSULATE THE CONNECTIONS WITH ELECTRICAL TAPE. WHITE/RED WHITE/GREEN Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 8 Driver door module Hood Status Purple/LtBlue Switch Starter Parking Light* White/Purple + White/Green Driver kick panel Nitro 07-11 Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 9 Purple/Blue Driver kick panel Hood Status Purple/Blue Switch Starter Parking Light* White/Purple Driver kick panel Liberty 08-12 Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 10 Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch Starter 5500 Parking Light White/Green (MUX) Switch Driver Door Pin Purple Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 11 PARKING LIGHT (+) DRIVER DOOR PIN (-) 04 GRAY/WHITE - HOOD STATUS (-) INPUT OPTIONAL HORN (-) WITHOUT OEM HOOD SWITCH: INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH AFTERMARKET HOOD SWITCH (-) Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 12 Ignition switch Starter Black 5 pin Pink/Orange Ignition switch Parking Light* White/Purple Driver kick panel Grand Cherokee 05-07 Driver Door Pin Purple/Blue Driver kick panel Hood Status Purple/LtBlue Switch * Requires additional parts. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 13 CONNECT IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (+) WITHOUT OEM HOOD SWITCH: INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH PARKING LIGHT (+) DRIVER DOOR PIN (-) OPTIONAL HORN (-) AFTERMARKET HOOD SWITCH (-) Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 14 Turn key to ON position. Wait, LED will turn solid GREEN for 2 seconds. START LED will turn solid RED. Module Programming Procedure completed. Within 5 seconds, LED will ﬂ ash GREEN rapidly. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 15 Turn key to OFF position then to ON position fi ve times [5x] rapidly. START Wait, LED 1 will turn solid RED for 2 seconds. Turn key to OFF position. START Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 16 8 using each additional remote. START LED 1 will turn solid RED. Wait, LED 1 will turn OFF. Time restriction. Complete next step within 2 Turn key to OFF position. seconds from previous step. START Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 17 Failure to exit the Module Navigation will drain button as many times as the menu number Navigation and redo the Module Navigation vehicle battery. indicates. LED 1 will ﬂ ash GREEN an equal Procedure. amount of times continuously. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 18 35 MIN 15 min 02 sec 05 SEC 08 SEC 10 SEC WAIT TO START DELAY 15 SEC 20 SEC 25 SEC 30 SEC *Vehicle will shutdown when a door is opened. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 19 HORN EVENT TRIGGER LOCK + UNLOCK + START CONFIGURATION DOUBLE LOCK + START 30 msec HORN CHIRPS WIDTH 15 mSec 60 mSec 02-07 Technical Support only *Vehicle will shutdown when a door is opened. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 20 The parking lights will ﬂ ash four [4x] times, then will ﬂ ash Check engine warning light is ON. [Y] number times to indicate an error code. See table. Low fuel warning light is ON. CAN communication failure during RS sequence. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 21 Module not programmed. Waiting for more vehicle information. Flashing GREEN False ground when running status from remote starter. WITH IGNITION OFF Solid GREEN then OFF Reset in progress. Module at rest and ready for a remote start sequence. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 22 BLACK 20-PIN connector. DTC or a CHECK ENGINE error message. Wait, LED 1 will ﬂash RED. RELEASE programming button. LED 1 will turn RED for 2 seconds. Module RESET completed. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 23 Press unlock on OEM or aftermarket remote. Insert key into ignition. START Turn key to ON position. START Press and release BRAKE pedal. Take over procedure completed. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
Page 24 YES: Go to next step. ¨ NO: Verify the remote programming, the RF connections and check the remote start error ¨ codes. Repeat the test and call technical support, if the problem persists. Automotive Data Solutions Inc. © 2014 AKX-CH(RS)-CH5-[AKX-CH5]-EN www.autokinetix.com...
