AKX -CH4 Installation Manual

Hide thumbs Also See for AKX-CH4:

Owner's manual (4 pages)

page of 20

/ 20
Bookmarks

Quick Links

Download this manual See also: Owner's Manual

AKX-CH(RS)-CH4-[AKX-CH4]-EN

AKX-CH4/AKX-CH4-1BAM/AKX-CH4-2WSS

DIRECTED SMARTSTART & ADS-HRN(RS)-SM01 (OPTIONAL)

notice

The manufacturer will accept no responsability for any electrical

damage resulting from improper installation of this product, be that either

damage to the vehicle itself or to the installed device. This device must be in-

stalled by a certified technician. Please review the Installation Guide carefully

before beginning any work.

U.S. Patent No. 8,856,780

instaLL guiDe

Document numbeR

20290

Revision Date

20150123

FiRmwaRe

AKX-CH(RS)-CH4-[AKX-CH4]

haRDwaRe

accessoRies

ADS-USB (REQUIRED)

COMPATIBLE RF-KIT (OPTIONAL)

beFoRe instaLLation

1- Connect module to computer

2- Login to Weblink account

3- Flash firmware to module (module is not preloaded with firmware)

4- Use accessories accordingly (accessories are sold separately)

www.autokinetix.com

Need help?

Do you have a question about the AKX-CH4 and is the answer not in the manual?

Questions and answers

Summary of Contents for AKX AKX-CH4

Page 1 AKX-CH(RS)-CH4-[AKX-CH4]-EN Document numbeR 20290 Revision Date 20150123 FiRmwaRe AKX-CH(RS)-CH4-[AKX-CH4] haRDwaRe AKX-CH4/AKX-CH4-1BAM/AKX-CH4-2WSS accessoRies ADS-USB (REQUIRED) COMPATIBLE RF-KIT (OPTIONAL) DIRECTED SMARTSTART & ADS-HRN(RS)-SM01 (OPTIONAL) notice beFoRe instaLLation The manufacturer will accept no responsability for any electrical damage resulting from improper installation of this product, be that either 1- Connect module to computer damage to the vehicle itself or to the installed device.
Page 2 • Routan AT 09-12 1 • • • • • • • • • • • • • • • • • • * May require additional parts. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 3 AFTERMARKET HOOD SWITCH AND CABLE BLACK BLACK WHITE WARNING STICKER WEBLINK CABLE (required accessory sold separately) WEBLINK CABLE MODULE COMPUTER WEBLINK PORT USB PORT 4 PIN BLACK CABLE U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 4 (NC) BLACK BLUE MODULE BLACK RF PORT BLUE CABLE RF DECODER BLACK CABLE ANTENNA TELEMATIC KIT (accessories sold separately) ADS-HRN(RS)-SM01 DIRECTED SMARTSTART (NC) MODULE TELEMATIC PORT (NC) (NC) U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 5 Driver kick panel Journey 09-10 Driver Door Pin Purple Driver kick panel Parking Light D2242 Black 10 pin White/Brown (MUX) Switch Magnum Driver Door Pin Purple Driver kick panel U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 6 5500 11-12 Driver Door Pin Purple Driver kick panel Parking Light D2242 Black 10 pin 01 White/Brown (MUX) Switch Routan 09-12 Driver Door Pin Purple Driver kick panel U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 7 04 GRAY/WHITE - HOOD STATUS (-) INPUT DRIVER DOOR PIN (-) WITHOUT OEM HOOD SWITCH: OPTIONAL HORN (-) INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH AFTERMARKET HOOD SWITCH (-) U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 8 Wait, LED will turn solid GREEN for 2 seconds. START LED will turn solid RED. Module Programming Procedure completed. Within 5 seconds, LED will ﬂ ash GREEN rapidly. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 9 Within 5 seconds, LED will ﬂ ash GREEN rapidly. DO NOT PRESS BRAKE PEDAL. Push start button once [1x] to OFF position. STOP ACC STOP ON START ENGINE START STOP U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 10 ENGINE START STOP Wait, LED 1 will turn solid RED for 2 seconds. Set ignition to OFF position. ON START ENGINE START STOP Valet Mode Programming Procedure completed. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 11 Set ignition to OFF position. seconds from previous step. ON START ENGINE START STOP Press once [1x] on LOCK button of aftermarket Aftermarket Remote Programming Procedure remote. completed. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 12 Navigation and redo the Module Navigation vehicle battery. indicates. LED 1 will ﬂ ash GREEN an equal Procedure. amount of times continuously. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 13 02 sec 05 SEC 08 SEC 10 SEC WAIT TO START DELAY 15 SEC 20 SEC 25 SEC 30 SEC *Vehicle will shutdown when a door is opened. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 14 LOCK + UNLOCK + START CONFIGURATION DOUBLE LOCK + START 30 msec HORN CHIRPS WIDTH 15 mSec 60 mSec 02-07 Technical Support only *Vehicle will shutdown when a door is opened. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 15 Check engine warning light is ON. [Y] number times to indicate an error code. See table. Low fuel warning light is ON. CAN communication failure during RS sequence. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 16 False ground when running status from remote starter. WITH IGNITION OFF Solid GREEN then OFF Reset in progress. Module at rest and ready for a remote start sequence. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 17 BLACK 20-PIN connector. DTC or a CHECK ENGINE error message. Wait, LED 1 will ﬂash RED. RELEASE programming button. LED 1 will turn RED for 2 seconds. Module RESET completed. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 18 Press unlock on OEM or aftermarket remote. Insert key into ignition. START Turn key to ON position. START Press and release BRAKE pedal. Take over procedure completed. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 19 ON START seconds for key validation. ENGINE START STOP Press and release BRAKE pedal. Take over procedure completed. >> Failure to follow procedure will result in vehicle engine shutdown. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
Page 20 ¨ NO: Verify the remote programming, the RF connections and check the remote start error ¨ codes. Repeat the test and call technical support, if the problem persists. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2015 AKX-CH(RS)-CH4-[AKX-CH4]-EN www.autokinetix.com...
