Important Safety Instructions IMPORTANT - Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. • Batteries (battery pack or batteries installed) Warnings shall not be exposed to excessive heat such as sunshine, fi...
Important Safety Instructions IMPORTANT - Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Important Information - Regarding Use of How do I dispose of this product? Video Games, Computers, Captions or Other Fixed Image Displays UK: Waste electrical products should not be disposed of with household waste.
Contents Manufacturers Guarantee Information Important Safety Instructions What is included in the box Attaching the stand Detaching the stand and securing the TV to a wall Wall mounting Getting Started - Initial Set Up TV Buttons and Input Source Menu Remote Control Connections 15-17...
What Is Included In The Box Accessories Included with this TV are the following accessories: 1 x Remote Control 1 x User Guide User Guide 1 x Quick Start Guide 2 x AAA Batteries 1 x TV 1 x Stand Installation Pack 3 x M(4x12) 4 x ST(4x12) 1 x RF Cable...
Attaching The Stand To complete the stand installation you will require a cross head screw driver. The Stand Installation pack comes with 2 sets of screws. 3 x M(4x12) 4 x ST(4x12) fi g 1) Attach the stand neck to the rear of the TV set. fi...
Detaching The Stand And Securing The TV To A Wall Detaching the Stand To detach the stand please remove the 3 screws highlighted then remove the stand neck and base from the rear of the TV set. M (4x12) Securing the TV to a Wall For maximum security in the home when using a TV with its stand anti-tip straps should be fi...
Wall Mounting IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there could be any electric wires, water or gas pipes. 1) Remove the four screws highlighted below. 2) The wall mount can now be easily attached to the mounting holes on the rear of the TV. These holes are indicated in the picture below.
Getting Started - Intial Set Up 1) Using the RF cable supplied, connect the TV to the Fig B TV Aerial wall socket (Fig A). Connect the power cable to the Electrical outlet (Fig B). Fig A 2) Switch on the television using the power on/off switch located on the side/underside of the TV.
TV Buttons & Source Menu For TV models with built in DVD player 1. Volume up and menu right 1. Stop/Eject DVD 2. Volume down and menu left 2. Play/Pause DVD 3. Programme/Channel up and menu up 3. Volume up and menu right 4.
Remote Control Viewing remote control - TV 1. STANDBY 2. MUTE 3. DTV 4. RADIO 5. DVD 6. USB 7. NUMBER BUTTONS 8. TV GUIDE - To return to the previous channel viewed 10. P.MODE - Scrolls through picture mode options 11.
Connections SCART SCART input HDMI 1 HDMI input Video Video Input R/L Audio in Component Audio input COMPONENT (HD) Component input (YPbPr) RF IN RF / TV Aerial Input USB Input HDMI 2 HDMI input CI CARD IN Common Interface module EARPHONE Earphone Socket V IDE O...
Page 13
Connections Connecting a Camcorder, Camera or Games Console Source should be set to Video L (white) L (white) R (red) R (red) Video Video (Yellow) (Yellow) Connecting a DVD Player/Recorder, Video Recorder or Cable/Satellite Box TVs Source should be set to SCART SCART SCART Connecting a High Defi...
Connections Connecting a High Defi nition (HD) Device Option 2 - via Component cable If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors you must connect via Component (for picture) and by phono cable (for sound). TV Source should be set to Component.
Channel Menu To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] Auto Tuning If you wish to make changes to any of the default Allows you to retune the television for all digital settings, use the scroll buttons.
Picture Menu To access this menu, press [MENU] button on the remote control and scroll right. To enter a menu press [OK] Picture Mode • Dynamic - Recommended settings for fast If you wish to make changes to any of the default moving pictures settings, use the scroll buttons.
Picture Menu Aspect Ratio • 14:9 - Displays the 14:9 picture in the correct proportion. As a result side bars are shown on Within the UK the picture format varies depending the screen on the channel/broadcast. There are a number of different options to best meet your needs •...
Sound Menu Sound Mode Digital Output • Off - Off • Standard - Default settings • Auto - Selects the best settings automatically • Music - Emphasises music over voices • PCM - Select this option if you are connecting •...
Time Menu To access this menu, press [MENU] button on the remote control and scroll right. Clock To enter a menu press [OK] Shows the date and time If you wish to make changes to any of the default Off Time settings, use the scroll buttons.
System/Hotel Lock Menu To access this menu, press [MENU] button on the remote control and scroll right. System/Hotel Lock To enter a menu press [OK] Allows you to lock or unlock the menu. You will be asked to enter a 4 digit password use the button to If you wish to make changes to any of the default quit the password input.
Setup Menu Language HDMI CEC (Consumer Electronic Control) Allows you to change the language of the menu Allows HDMI devices to control each other and allows the user to operate multiple devices with one remote Audio language control. (only available with compatible devices) Allows the user to change the audio language LED Status Subtitle Language...
DVD Setup Applies to models with built in DVD players TV Display - Choose from the following options 4:3 Pan Scan PS Traditional picture format, often used on old fi lm 4:3 Letter Box LB Traditional picture which has been adapted for widescreen Wide 16:9 Widescreen picture format Speaker Setup - Choose from the following options...
7 Day TV Guide TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported by the freeview channel). You can view the start and end time of all programmes and on all channels for the next 7 days and set reminders. 1) Press [TV GUIDE].
USB Record - Digital / Freeview Mode USB Record – Digital/Freeview Mode Built into this television is a USB record facility. This function is available in Digital/Freeview mode when used in conjunction with a compatible USB memory stick or USB hard drive. The benefi ts of this are as follows: •...
USB Mode / Media Player USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. On switching to USB source the above menu screen will appear. The content will be divided into Photo, Music, Movie and Text based on fi...
Using Your TV With a Sky Digital Set Top Box Option 1) Connecting your TV to your Sky box (when both the TV and Sky Box are located in the same room) Depending on your Sky Box & TV model, connect either by SCART or HDMI cables (available separately) If connecting by SCART, select the ‘Input source’...
Frequently Asked Questions General I would like to have Subject to the TV model and connections, it is possible to connect the TV louder sound by to an external amplifi er or surround sound (subject to connections/inputs connecting additional on the device) as follows:- speakers.
Frequently Asked Questions Game I have connected Component cables only provide HD Pictures. For the sound you will need Consoles my Xbox 360 to the to connect the Red & White audio cables on the Xbox to the Red & White TV via Component phono inputs on the rear of the TV.
Technical Specification Model 22/207F 22/207FDVD 24/207F 24/207FDVD 24/207FDVD-P 24/207FDVD-W 24/207FDVD-S Screen size (diagonal) 21.5”/55cm 21.5”/55cm 23.6”/60cm 23.6”/60cm Resolution 1920 x 1080 75 ohm Antenna / Analog / DVB Video Inputs 2 x HDMI, 1 x SCART, 1 x USB, 1 x Composite/Video, 1 x Component/YPbPr Sound Inputs 1 x shared audio for Composite/Video &...
