Blue Rhino GAD15002T Assembly Information

Round lp outdoor fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Threshold
27 in. Round LP
Gas Outdoor
Fireplace
dpci # 009-07-0772
stock # GAD15002T
>> assembly instructions
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only (outside any enclosure)
Do Not Use For Cooking.
DANGER
• This appliance can produce carbon
monoxide which has no odor.
• Using it in an enclosed space can kill you.
• Never use this appliance in an enclosed
space such as a camper, tent, car or home.
™
CARBON MONOXIDE HAZARD
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
If you are assembling this unit for someone else,
give this manual to him or her to read and save
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GAD15002T and is the answer not in the manual?

Questions and answers

Related Manuals for Blue Rhino GAD15002T

Summary of Contents for Blue Rhino GAD15002T

  • Page 1 Threshold ™ 27 in. Round LP Gas Outdoor Fireplace dpci # 009-07-0772 stock # GAD15002T >> assembly instructions WARNING FOR YOUR SAFETY: For Outdoor Use Only (outside any enclosure) Do Not Use For Cooking. CARBON MONOXIDE HAZARD DANGER • This appliance can produce carbon THIS INSTRUCTION BOOKLET CONTAINS monoxide which has no odor.
  • Page 2 WARNING WARNING FOR YOUR SAFETY: FOR YOUR SAFETY: Improper installation, adjustment, alteration, W If the information in this manual is not followed service or maintenance can cause injury or exactly, a fire or explosion may result causing property damage. property damage, personal injury or loss of life. Read the installation, operation and maintenance W WHAT TO DO IF YOU SMELL GAS: instructions thoroughly before installing or...

  • Page 3: Table Of Contents

    Congratulations on your latest Target purchase. Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you. All you need to do is follow our simple instructions and you’ll be on your way to transforming your backyard in no time. Good luck—though we’re confident you won’t need it.

  • Page 4: Important Safeguards

    important safeguards W DANGER: Failure to follow the dangers, warnings and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. W WARNINGS: W This appliance is for outdoor use only, and should NOT be used in a building, garage or any other enclosed area.
  • Page 5 important safeguards W LP gas tank needed to operate. Only tanks marked “propane” may be used. a. The LP gas cylinder must be constructed and marked in accordance with the U.S. Department of Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods and Commission, CAN/CSA-B339 as applicable.
  • Page 6 important safeguards W Do NOT operate if a gas leak is present. Gas leaks may cause a fire or explosion. W You must follow all instructions in the “Checking for Leaks” section before operating. To prevent a fire or explosion when testing for a leak: a.
  • Page 7 important safeguards W Do NOT burn solid fuels such as: wood, charcoal briquettes, lump charcoal, manufactured logs, driftwood, trash, leaves, paper, cardboard, plywood, or painted/stained/pressure treated wood in this outdoor fireplace. W It is essential to keep the outdoor fireplace’s valve compartment, burners, and circulating air passages clean. Inspect outdoor fireplace before each use.
  • Page 8 W Use only the regulator and hose assembly provided. Use only the replacement regulator and hose assembly specified by Blue Rhino Global Sourcing, Inc. W Use only Blue Rhino Global Sourcing, Inc. factory-authorized parts. The use of any part that is not factory- authorized can be dangerous and will void your warranty.
  • Page 9 important safeguards W The pressure regulator is set for 11 inches of water column. W Before pressure testing, close LP gas tank valve and disconnect gas regulator. The gas supply piping system must test at pressures equal to or less than 1/2 psi (3.5 kPa). W Do NOT sit or stand on the mantle or any part of this appliance.

  • Page 10: Before You Begin

    before you begin 1. Check for damaged or missing parts. Call 800.762.1142 to order missing parts. 2. Use the carton as a working surface to prevent product damage during assembly. 3. Gather all tools prior to assembly. tools required QUESTIONS? Just call 800.762.1142 for parts and service.

  • Page 11: Parts

    parts Re-order Item Description Number Wind Guard 00-00-000 Lava Rock 58-23-322 Burner* 58-23-368 Bowl Assembly* 58-23-369 Control Knob* 58-23-370 Door Manget* 58-23-456 Foot 58-23-457 Door 58-23-372 LP Gas Extension Hose 58-23-328 LP Gas Extension Hose 58-23-329 Bracket LP Gas Tank Stand 58-23-330 LP Gas Tank Retainer 58-23-331...

  • Page 12: Hardware

    hardware (A) x 2 Screw M5x12 Nickel Plated Phillips Truss Head QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when when calling.

  • Page 13: Assembly Instructions

    step 1 DO NOT RETURN TO PLACE OF PURCHASE. For assistance, call 1.800.762.1142 toll-free. Please have your owner’s manual and DPCI number available for reference. Note: The model number is printed on a label which can be found on the inside door, back or side of the base assembly. Assembly Tips: 1.
  • Page 14 step 2 QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when when calling.
  • Page 15 step 3 W CAUTION: Do NOT dump lava rocks out of package. Carefully place lava rocks by hand so dust does not clog burner. Note: Approx. 6 lbs. (2.7 kg) of lava rocks are needed. QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when when calling.

  • Page 16: Installing Lp Gas Tank

    installing 16.4 oz. propane gas tank Connecting 16.4 oz. Propane Gas Tank Figure 1 Figure 2 This outdoor fireplace is designed to operate with a 1 lb. 7.75 in. OFF / APAGADO high disposable / 16.4 oz. propane gas tank (DOT 39 Cylinder) (Figure 1).

  • Page 17: Installing Standard Lp Gas Tank

    installing standard LP gas tank Standard LP Gas Tank Figure 5 Figure 6 To operate, you will need one precision-filled standard LP grill gas tank with external valve threads. W Caution: LP gas tank must be properly disconnected and 20 lb removed prior to moving this outdoor fireplace.
  • Page 18 Getting More Propane Figure 12 Need a tank of gas? One option is to try propane exchange, such as Blue Rhino ® It’s easy, fast, safe, and available at tens of thousands of conveniently located retail outlets nationwide, which are typically open nights and weekends.

  • Page 19: Operating Instructions

    operating instructions Checking for Leaks Figure 13 1. Make 2-3 oz. of leak detection solution by mixing one part liquid dishwashing soap with three parts water. 2. Make sure regulator/control knob is in the “ OFF” position (Figure 2). 3. Spoon the leak detection check solution on all “X” locations (Figure 13, 14 & 15). a.

  • Page 20: Turning Off

    operating instructions 4. Clear small area of lava rock away from the burner (Figure 16). Figure 16 5. Connect LP gas tank per “Installing LP Gas Tank” section. 6. Wearing heat-resistant gloves, position a long lit match or long lit butane lighter near the pilot housing (Figure 16).

  • Page 21: Cleaning And Care

    cleaning and care W CAUTION: 1. All cleaning and maintenance should be done when outdoor fireplace is cool and with the fuel supply disconnected. 2. Do NOT clean any outdoor fireplace part in a self-cleaning oven. The extreme heat will damage the finish. 3.

  • Page 22: Cleaning

    operating instructions Cleaning Surfaces 1. Wipe surfaces clean with mild dishwashing detergent or baking soda mixed with water. 2. For stubborn stains, use a citrus-based cleaner and a nylon scrubbing brush. 3. Rinse clean with water. 4. Allow to air dry. Before Storing 1.

  • Page 23: Product Registration

    product registration For faster warranty service, register your product immediately at BlueRhino.com/warranty or by calling 1.800.762.1142. replacement parts Replacement parts can be found at parts.BlueRhino.com or by calling 1.800.762.1142. QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when when calling.

  • Page 24: Limited Warranty

    (1) year from the date of purchase, all parts in such product shall be free from defects in material and workmanship. Blue Rhino may require reasonable proof of your date of purchase.

  • Page 25: Troubleshooting

    troubleshooting Problem Possible Cause Prevention/Cure LP gas tank is low or empty Replace LP gas tank 1. Turn control knob to “ OFF” 2. Disconnect LP gas tank per “Disonnecting LP Gas Tank” section No gas flow 3. Clear any debris from valve 4.
  • Page 26 troubleshooting Problem Possible Cause Prevention/Cure High or gusting winds Do NOT use outdoor fireplace in high winds Low on LP gas Replace LP gas tank Flame goes out Refer to “Sudden drop in gas flow or reduced flame Excess flow valve tripped height”...
  • Page 27 troubleshooting QUESTIONS? Just call 800.762.1142 for parts and service. For faster service, have the DPCI number ready when when calling.
  • Page 28 © Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved. GAD15002T-OM-100...
