- Page 1 PORTABLE SOUND SYSTEM FREEPOLE 100 Mini USER’S MANUAL...
-
Page 3: Table Of Contents
INDEX 1 - INTRODUCTION …………………….……….…….……………………………………………….… 2 – MAIN FEATURES ………………………………..…….……….……………………..………………. 3 - CONTROLS ………………….………….. ……………….……..…………………….…………….. 4 - AUDIO MODULE ……………….…………………………………..………………………………….. 5 - HF MICROPHONE ……………….……………………………...……..……………………………... 6 - BATTERY ………………………………………………..………..…………………………………….. 7 - TECHNICAL SPECIFICATIONS …………..…………………..…………..………………………… 8 - WARRANTY ……………………………………….……………..………………………………………... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing the Audiopole FREEPOLE 100 mini. This all in one system is an ideal tool for indoors and outdoors PA applications without using wiring. The built-in lithium battery and the wireless microphone system offer freedom of use and an optimal sound quality for the music and the voice. -
Page 5: Controls
CONTROLS FRONT PANEL BACK PANEL... -
Page 6: Audio Module
Volume up Volume up Bluetooth Connection When using a Bluetooth connection between the FREEPOLE 100 Mini and other devices like smartphones, search the RTL-29 matching name and valid the connection. Remote control The remote control operates with the audio module only. -
Page 7: Battery
BATTERY The FREEPOLE 100 Mini can be powered either by 100 to 240 V AC, or by the internal lithium battery. The battery starts the charging sequence as soon as the device is connected to the mains. The Led indicator lights up during the charging time and switches off when the charge is over. -
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS Amplification Power 100 W (RMS), Class-D Speakers 1 x 20 cm (8“) 1 x 2,5 cm (1“) ≤ 1% 100 dB SPL max. 65Hz – 20KHz Frequency response (-6 dB) MIC : >70 dB // LINE : >75 dB S/N ratio Wireless system Frequency band...
