- Page 1 LCD-KIT IEI Te c h n o lo g y Co rp . MODEL: LCD-KIT S e rie s 15" ~ 17" Op e n Fra m e LCD Mo n ito r VGA, DVI-D, Ro HS Us e r Ma n u a l P a g e i Re v.
- Page 2 LCD-KIT Re vis io n Date Version Changes 25 June, 2013 3.00 Initial release P a g e ii...
- Page 3 LCD-KIT Co p yrig h t COP YRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 4: Table Of Contents
2.3.1 Available Connectors ..................9 2.4 P .................... 10 HYSICAL IMENSIONS 2.4.1 General Physical Dimensions ................10 2.4.2 LCD-KIT150G Physical Dimensions ..............11 2.4.3 LCD-KIT170G Physical Dimensions ............... 12 2.5 M ....................13 OUNTING PTIONS 3 LCD SPECIFICATIONS .................... 14 3.1 LCD S... - Page 5 LCD-KIT 4.1 AD B ..................... 19 OARD VERVIEW 4.2 AV-6600 AD B ................19 OARD VERVIEW 4.2.1 AV-6600 Peripheral Interface Connectors ............20 4.2.2 AV-6600 Rear Panel Connectors ..............20 5 INSTALLATION ......................21 5.1 I ................... 22 NSTALLATION RECAUTIONS 5.2 U ......................
- Page 6 LCD-KIT A CERTIFICATIONS ....................42 A.1 R HS C ....................43 OMPLIANT B SAFETY PRECAUTIONS ..................44 B.1 S ..................... 45 AFETY RECAUTIONS B.1.1 General Safety Precautions ................45 B.1.2 Anti-static Precautions ..................46 B.2 M ............46 AINTENANCE AND LEANING RECAUTIONS B.2.1 Maintenance and Cleaning ................
- Page 7 Figure 1-4: Typical LCD-KIT Connectors ..................5 Figure 1-5: AV-6600 AD Board ...................... 6 Figure 2-1: Rear Panel ........................9 Figure 2-2: LCD-KIT150G Physical Dimensions (millimeters) ..........11 Figure 2-3: LCD-KIT170G Physical Dimensions (millimeters) ..........12 Figure 4-1: AV-6600 AD Board Overview ...................19 Figure 5-1: VGA Connector ......................25...
- Page 8 LCD-KIT Figure C-3: smartOSD Folder Select Screen ................51 Figure C-4: smartOSD Confirm Installation ................52 Figure C-5: smartOSD Installation Progress ................52 Figure C-6: smartOSD Installation Complete ................53 Figure C-7: smartOSD Desktop Icon ..................53 Figure C-8: Manage Page ......................56 Figure C-9: EDID Page........................57 Figure C-10: Image Page ......................58 Figure C-11: Display Page ......................59 Figure C-12: Color Page .......................60...
- Page 9 Table 1-1: LCD-KIT Series Model Variations ................3 Table 2-1: General Physical Dimensions ...................10 Table 2-2: Mounting Holes ......................13 Table 3-1: LCD-KIT150G LCD Specifications ................16 Table 3-2: LCD-KIT170G LCD Specifications ................16 Table 3-3: Power Adapter Specifications ...................17 Table 4-1: AV-6600 Peripheral Interface Connectors ..............20 Table 4-2: AV-6600 Rear Panel Connectors ................20...
-
Page 10: Introduction
LCD-KIT Ch a p te r In tro d u c tio n P a g e 1... -
Page 11: Lcd-Kit Series Lcd Monitor Overview
LCD-KIT 1.1 LCD-KIT S e rie s LCD Mo n ito r Ove rview Figure 1 1: LCD-KIT Series The LCD-KIT series LCD monitor is the latest member of IEI’s line of sophisticated LCD designs, and it has been improved to be RoHS compliant. It is designed to fit industrial automation, or any other applications that require minimum installation space and flexible configuration. -
Page 12: Model Variations
LCD-KIT 1.3 Mo d e l Va ria tio n s The LCD-KIT series offers the following model variations. 9~36V Power Model Number Input LCD-KIT150G-R30 15” LCD-KIT150GM-R30 LCD-KIT170G-R30 17” LCD-KIT170GM-R30 Table 1-1: LCD-KIT Series Model Variations 1.4 Ap p lic a tio n s IEI’s series of LCD monitors are designed for system manufacturers, integrators, or... -
Page 13: Rear View
LCD-KIT Figure 1-2: Typical LCD-KIT Front View 1.5.2 Re a r Vie w The rear of the LCD-KIT series LCD monitor is a metal chassis. An on screen display (OSD) control button panel, if present, is located vertically on the left side of the chassis with the following control buttons: ... -
Page 14: Connectors
LCD-KIT Figure 1-3: Typical LCD-KIT Rear View 1.5.3 Co n n e c to rs Each LCD-KIT series LCD monitor has a number of interface connectors on either the top or right panel of the chassis (when viewing the rear panel). Figure 1-4 shows a typical LCD-KIT connector panel. -
Page 15: Ad Board
LCD-KIT 1.5.4 AD Bo a rd The LCD-KIT series LCD monitor AD boards provide a wide variety of control interfaces, receiving and managing signals from a CPU card through cabling. Figure 1-5 shows the AV-6600 AD board as a sample of a typical AD board for the LCD-KIT series LCD monitor. Refer to Chapter 4 for a complete description of AD boards and their connectors. -
Page 16: Series Specifications
LCD-KIT 1.6 S e rie s Sp e c ific a tio n s The table below shows the LCD-KIT Series specifications. LCD-KIT LCD-KIT150G LCD-KIT150GM LCD-KIT170G LCD-KIT170GM LCD Type 15" TFT 15" TFT 17" TFT 17" TFT Resolution 1024 x 768... -
Page 17: Mechanical Overview
LCD-KIT Ch a p te r Me c h a n ic a l Ove rvie w P a g e 8... -
Page 18: Introduction
2.2 Re a r P a n e l The following models of the LCD-KIT series LCD monitor have an OSD control panel located vertically along the left side of the rear panel: LCD-KIT150G LCD-KIT170G Figure 2-1 shows the location of the rear panel OSD controls. -
Page 19: Physical Dimensions
General physical dimensions for the LCD-KIT series LCD monitors are shown in Table 2-1. Mo d e l Wid th (m m ) He ig h t (m m ) De p th (m m ) LCD-KIT150G 364.1 262.5 41.9 LCD-KIT170G 390.4 46.9... -
Page 20: Lcd-Kit150G Physical Dimensions
LCD-KIT 2.4.2 LCD-KIT150G P h ys ic a l Dim e ns io n s The physical dimensions of the LCD-KIT150G are shown in Figure 2-2. Figure 2-2: LCD-KIT150G Physical Dimensions (millimeters) P a g e 11... -
Page 21: Lcd-Kit170G Physical Dimensions
LCD-KIT 2.4.3 LCD-KIT170G P h ys ic a l Dim e ns io n s The physical dimensions of the LCD-KIT170GS are shown in Figure 2-3. Figure 2-3: LCD-KIT170G Physical Dimensions (millimeters) P a g e 12... -
Page 22: Mounting Options
No . o f Ro u n d Ho le s - S ize No . o f S lo tte d Ho le s LCD-KIT170G 6 – 4.5 mm diameter LCD-KIT150G 6 – 4.5 mm diameter Table 2-2: Mounting Holes P a g e 13... -
Page 23: Lcd Specifications
LCD-KIT Ch a p te r LCD S p e c ific a tio n s P a g e 14... -
Page 24: Lcd Specifications
LCD-KIT170G: AUO G170EG01 V1 Detailed specifications for the LCD screens are listed in the following sections. 3.1.2 LCD-KIT150G LCD Sp e c ific a tio n s The table below lists the LCD-KIT150G LCD specifications. Ite m s LCD-KIT150G 15”... -
Page 25: Lcd-Kit170G Lcd Specifications
LCD-KIT S u p p ly Vo lta g e (V) Table 3-1: LCD-KIT150G LCD Specifications 3.1.3 LCD-KIT170G LCD Sp e c ific a tio n s The table below lists the LCD-KIT170G LCD specifications. Ite m s LCD-KIT170G 17”... -
Page 26: Table 3-3: Power Adapter Specifications
LCD-KIT LCD-KIT 150G, 170G Power 60W power adapter Input Voltage Range 90-264VAC Input Frequency 47-63 Hz Input AC Current 1.5A max @ 90vac input & full load Hold Time 8mS minimum. Tested 115 Vac input and max load at output 20mS minimum. -
Page 27: Ad Board
LCD-KIT Ch a p te r AD Bo a rd P a g e 18... -
Page 28: Ad Board Overview
LCD-KIT 4.1 AD Bo a rd Ove rvie w The LCD-KIT series industrial LCD monitor AD board provides a wide variety of control interfaces, receiving and managing interface signals from a CPU card through cabling. The following sections describe the AD board in detail. 4.2 AV-6600 AD Bo a rd Ove rview The AV-6600 AD board provides a wide variety of control interfaces, receiving and managing interface signals from a CPU card through cabling. -
Page 29: Av-6600 Peripheral Interface Connectors
LCD-KIT 4.2.1 AV-6600 P e rip he ra l Inte rfa c e Co n n e c to rs Table 4-1 shows a list of the peripheral interface connectors on the AV-6600 AD board. Co n n e c to r Typ e La b e l Audio input connector... -
Page 30: Installation
LCD-KIT Ch a p te r In s ta lla tio n P a g e 21... -
Page 31: Installation Precautions
LCD-KIT 5.1 In s ta lla tio n P re c a u tio n s When installing the LCD-KIT series LCD monitor, please follow the precautions listed below: Read the user manual: The user manual provides a complete description of the LCD-KIT series LCD monitor, installation instructions and configuration options. -
Page 32: Unpacking
LCD-KIT 5.2 Un pa c kin g 5.2.1 P a c ka g in g When shipped, the LCD-KIT series LCD monitor is wrapped in a plastic bag. Two polystyrene ends are placed on either side of the monitor. The monitor is then placed into a first (internal) cardboard box. -
Page 33: Packing List
LCD-KIT 5.2.3 P a c kin g Lis t All the monitors in the LCD-KIT series are shipped with the following components: 1 x LCD-KIT series LCD monitor. 1 x AC Power cable 1 x VGA Cable ... -
Page 34: Connectors
LCD-KIT 5.4 Co n n e c to rs Table 5-1 lists the rear panel connectors for the LCD-KIT series LCD monitors. LCD-KIT 150G 150GM 170G 170GM DVI-D Power (12V Jack) Power (9~36V Terminal Block) (Optional for M model) Table 5-1: Rear Panel Connectors 5.4.1 VGA Co n n e c to r Use the rear panel standard 15-pin female VGA connector to connect the LCD monitor to the system graphics interface. -
Page 35: Power Connector
LCD-KIT Description Description Description TMDS Data2- TMDS Data1- TMDS Data0- TMDS Data2+ TMDS Data1+ TMDSData0+ TMDS Data2/4 Shield TMDS Data1/3 Shield TMDS Data0/5 Shield TMDS Data4- TMDS Data3- TMDS Data5- TMDS Data4+ TMDS Data3+ TMDS Data5+ DDC Clock [SCL] +5 V Power TMDS Clock Shield DDC Data [SDA] Ground (for +5 V) -
Page 36: Mounting The Lcd-Kit Series Lcd Monitor
LCD-KIT Figure 5-4: Terminal Block 5.5 Mo u n tin g th e LCD-KIT S e rie s LCD Mo n ito r Each LCD-KIT series LCD monitor comes with a preinstalled mounting bracket with a number of holes available for mounting purposes that system integrators will find especially useful. -
Page 37: Osd Controls
LCD-KIT Ch a p te r OS D Co n tro ls P a g e 28... -
Page 38: User Mode Osd Structure
LCD-KIT 6.1 Us e r Mo d e OS D Stru c tu re 6.1.1 OS D Bu tto n s There are several on-screen-display (OSD) control buttons oriented vertically along the left side of the monitor rear panel. Figure 6-1 shows a typical arrangement of OSD controls of the LCD-KIT series LCD monitor. -
Page 39: Using The Osd
LCD-KIT Clock 0 to 100 Phase 0 to 100 H. Position 0 to 100 V. Position 0 to 100 Sharpness 1 to 5 Color Menu 6500K - Preset NTSC value 7500K - Preset NTSC value 9300K - Preset NTSC value RGB values from 0 to 100 Green RGB values from 0 to 100... -
Page 40: Color
LCD-KIT Figure 6-2: Main Display Features The brightness option adjusts the brightness of screen. This function adjusts the offset value of ADC. Setting this value too high or too low Brightness will affect the quality of image. When the auto- dimming function is turned on, the brightness control is not effective. -
Page 41: Figure 6-3: Color Options
LCD-KIT Figure 6-3: Color Options The Color menu fine-tunes the palette of color hues for the LCD. 6500k NTSC standard Kelvin NTSC standard Kelvin 7500k 9300k NTSC standard Kelvin This item allows fine-tuning the balance among Red, Green, and Blue color User hues if images look garish or unrealistic. -
Page 42: Osd Configurations
LCD-KIT 6.2.3 OS D Co n fig u ra tio n s The OSD configurations are shown in Figure 6-4. Figure 6-4: OSD Configurations Menu OSD Configurations are described below. Determines how many seconds the OSD screen stays on screen OSD Time Out before it disappears when OSD is left unattended. -
Page 43: Software Driver
LCD-KIT Ch a p te r S o ftwa re Drive r P a g e 34... -
Page 44: Introduction
LCD-KIT 7.1 In tro d u c tio n The touch panel controller enables analog resistive touch panels for four-wire, five-wire & eight-wire models. The controller directly communicates with the PC system through the touch panel communications interface. The controller design is superior in sensitivity, accuracy, and friendly operation. -
Page 45: Touch Panel Driver Installation
LCD-KIT USB Interface: If the touch screen interface connection is a USB connection, connect the USB connector on the single board computer to the external USB port connector of the LCD-KIT monitor. 7.3 To u c h P a n e l Drive r In s ta lla tio n WARNING: Before the touch screen driver is installed, make sure the system is connected to the monitor with a USB cable or an RS-232 null cable. -
Page 46: Figure 7-2: Welcome Screen
LCD-KIT Double click the setup icon in Figure 7-1. S te p 4: The Welcome screen in Figure 7-2 appears. S te p 5: Figure 7-2: Welcome Screen Click Next to continue. S te p 6: The license agreement in Figure 7-3 appears. Accept the terms of the S te p 7: agreement by clicking I Agree. -
Page 47: Figure 7-4: Initiate Install
LCD-KIT The installation destination screen appears. See Figure 7-4. Click Install. S te p 8: Figure 7-4: Initiate Install The installation of the program begins. See Figure 7-5. S te p 9: Figure 7-5: Installation Starts When the installation is complete, the complete screen appears. See Figure 7-6. S te p 10: To complete the installation process click Finish. -
Page 48: Change The Touch Screen Interface
LCD-KIT Figure 7-6: Finish Installation 7.4 Ch a n g e th e To u c h S c re e n In te rfa c e If the touch screen interface must be changed from an RS-232 interface to a USB interface or, from a USB interface to an RS-232 interface, the following steps must be followed. -
Page 49: Figure 7-7: Penmount Monitor Icon
LCD-KIT S te p 3: Locate the PenMount Monitor icon in the bottom left corner of the screen. Figure 7-7: PenMount Monitor Icon S te p 4: Click the icon. A pop up menu appears. See Figure 7-8. Figure 7-8: PenMount Monitor Popup Menu Click Control Panel in the pop up menu shown in Figure 7-8. -
Page 50: Figure 7-10: Calibration Initiation Screen
LCD-KIT Double click the PenMount 6000 icon as shown in Figure 7-9. S te p 7: The calibration initiation screen in Figure 7-10 appears. S te p 8: Select the Standard Calibration button as shown in Figure 7-10. S te p 9: Figure 7-10: Calibration Initiation Screen S te p 10: The calibration screen in is shown. -
Page 51: A Certifications
LCD-KIT Ap p e n d ix Ce rtific a tio n s P a g e 42... -
Page 52: R Ohs Compliant
LCD-KIT A.1 Ro HS Co m p lia n t All models in the LCD-KIT series comply with the Restriction of Hazardous Materials (RoHS) Directive. This means that all components used to build the industrial workstations and the workstation itself are RoHS compliant. The RoHS Directive bans the placing on the EU market of new electrical and electronic equipment containing more than agreed levels of lead, cadmium, mercury, hexavalent chromium, polybrominated biphenyl (PBB) and polybrominated diphenyl ether (PBDE) -
Page 53: B Safety Precautions
LCD-KIT Ap p e n d ix S a fe ty P re c a u tio n s P a g e 44... -
Page 54: Safety Precautions
LCD-KIT WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the LCD-KIT Series. B.1 S a fe ty P re c a u tio n s Please follow the safety precautions outlined in the sections that follow: B.1.1 Ge n e ra l S a fe ty P re c a u tio n s Please ensure the following safety precautions are adhered to at all times. -
Page 55: Anti-Static Precautions
LCD-KIT B.1.2 An ti-s ta tic P re c a u tio n s WARNING: Failure to take ESD precautions during the installation of the LCD-KIT Series may result in permanent damage to the LCD-KIT Series and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the LCD-KIT Series. -
Page 56: Cleaning Tools
LCD-KIT Except for the LCD panel, never spray or squirt liquids directly onto any other components. To clean the LCD panel, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth. The interior of the LCD-KIT Series does not require cleaning. Keep fluids away from the LCD-KIT Series interior. -
Page 57: C Smartosd
LCD-KIT Ap p e n d ix s m a rtOS D P a g e 48... -
Page 58: Iei Smart Osd Quick Installation Guide
LCD-KIT C.1 IEI s m a rtOS D Qu ic k In s ta lla tio n Gu id e IEI smartOSD is a proprietary On-Screen-Display (OSD) software solution from IEI that enables easy, remote monitor setting adjustments in a Windows environment. IEI smartOSD delivers excellent performance and provides more flexibility than the typical OSD hardware solutions when adjusting a monitor. -
Page 59: Smart Osd Install
LCD-KIT C.3 s m a rtOS D In s ta ll Connect the LCD-KIT to a host computer. Insert the CD that came with the system and follow the instructions below. When the CD installs the screen shown in Figure C-1 appears. S te p 1: Figure C-1: smartOSD Installer Click “Smart OSD”... -
Page 60: Figure C-2: Smartosd Welcome Screen
LCD-KIT Figure C-2: smartOSD Welcome Screen S te p 4: Click Next to continue. S te p 5: The Folder Select screen in Figure C-3 appears. Figure C-3: smartOSD Folder Select Screen Select the installation folder in Figure C-3 shown above. S te p 6: Click Next to continue. -
Page 61: Figure C-4: Smartosd Confirm Installation
LCD-KIT Figure C-4: smartOSD Confirm Installation S te p 9: Confirm the installation by clicking Next in the screen above. S te p 10: The program starts to install and the progress bar shown in Figure C-5 appears. Figure C-5: smartOSD Installation Progress S te p 11: When the installation is complete the “Complete Installation”... -
Page 62: Figure C-6: Smartosd Installation Complete
LCD-KIT Figure C-6: smartOSD Installation Complete S te p 12: Click Close in the screen above. S te p 13: After quick setup is complete, the IEI smartOSD wizard logo appears on the desktop as shown in the screen below. S te p 14: To access the smartOSD, click the smartOSD wizard logo.S te p 0:... -
Page 63: Software Illustration
LCD-KIT C.4 S o ftwa re Illu s tra tio n The table below shows the smartOSD menu structure for all IEI LCD monitors. NOTE: To update the display setting status immediately, push the refresh button on every page To turn the system on, press ALT + P. Ite m Ele m e n ts Ma n a g e m e n t... -
Page 64: Table C-1: Smartosd Menu Structure
LCD-KIT Ite m Ele m e n ts PIP Source Input (disabled in the LCD-KIT Series) PIP Size (disabled in the LCD-KIT Series) Monitor Power Control S ys te m Auto Brightness (disabled in the LCD-KIT Series) Main Source Input (S-Video and CVBS disabled) Volume (disabled in the LCD-KIT Series) Factory Presets/OSD Lock/OSD Unlock Mute (disabled in the LCD-KIT Series) -
Page 65: Manage Page
LCD-KIT C.4.1 Ma n a g e P a g e Figure C-8: Manage Page P a g e 56... -
Page 66: Edid Page
LCD-KIT C.4.2 EDID P a g e Figure C-9: EDID Page P a g e 57... -
Page 67: Image Page
LCD-KIT C.4.3 Im a g e P a g e Figure C-10: Image Page P a g e 58... -
Page 68: Display Page (For Analog Signal)
LCD-KIT C.4.4 Dis p la y P a g e (fo r a n a lo g s ig n a l) Figure C-11: Display Page P a g e 59... -
Page 69: Color Page
LCD-KIT C.4.5 Co lo r P a g e Figure C-12: Color Page P a g e 60... -
Page 70: Pip Page
LCD-KIT C.4.6 P IP P a ge NOTE: The functions in the PIP page are only available in the MLCD-KIT Series and AFOLUX Series monitors. Figure C-13: PIP Page P a g e 61... -
Page 71: System Page
LCD-KIT C.4.7 S ys te m P a g e Figure C-14: System Page P a g e 62... - Page 72 LCD-KIT NOTE: Some of the functions in the System Page are only available to some of the IEI LCD series as following: Auto Brightness: SRM, MLCD-KIT and AFOLUX series only Main Source Input: MLCD-KIT and AFOLUX series only ...
-
Page 73: About Page
LCD-KIT C.4.8 Ab o u t P a g e Figure C-15: About Page P a g e 64... -
Page 74: Smart Osd Faq
LCD-KIT C.5 s m a rtOS D FAQ For troubleshooting, please see the steps below: C.5.1 Win d ows 2000 In s ta lla tio n Fa ilu re Installation fails under Windows 2000 and shows the following image: Figure C-16: DLL Missing Solution: Download and install service pack Windows Installer 3.1 P a g e 65... -
Page 75: Vista Installation Failure
LCD-KIT C.5.2 Vis ta In s ta lla tio n Fa ilu re Installation fails under Vista while showing following image: Figure C-17: Windows Vista Error Solution: Install SmartOSD.exe with administrator authority Figure C-18: Install as Administrator P a g e 66... -
Page 76: Model Failure
LCD-KIT C.5.3 Mo d e l Fa ilu re The Model Fail error message shown below appears. Figure C-19: Firmware Incompatibility Solution: SmartOSD only supports firmware version 2.0 and following versions. C.5.4 DDC P o rt Fa ilu re The DDC port fail error message shown below appears. Figure C-20: DCC Port Failure Solutions: ...
