ISDM Series Industrial Monitor
IEI Technology Corp.
MODEL:
ISDM Series
Stainless Steel Industrial Monitor, RoHS Compliance
IP 65 Protection, Touch Screen, 9-36V DC Input, VGA/DVI-D
Rev. 1.13 – 16 July, 2009
ISDM Series Industrial Monitor User Manual
User Manual
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISDM-084G and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology ISDM-084G

Summary of Contents for IEI Technology ISDM-084G

  • Page 1 ISDM Series Industrial Monitor ISDM Series Industrial Monitor User Manual IEI Technology Corp. MODEL: ISDM Series Stainless Steel Industrial Monitor, RoHS Compliance IP 65 Protection, Touch Screen, 9-36V DC Input, VGA/DVI-D User Manual Page 1 Rev. 1.13 – 16 July, 2009...
  • Page 2 ISDM Series Industrial Monitor Revision Date Version Changes 16 July, 2009 1.13 Update “Chapter 6: OSD Controls” April, 2008 1.12 Added ISDM-121GX models information Added the smartOSD appendix May, 2007 1.11 AV-5300 AD Board CN25 connector pin 3 voltage changed to +9V~+36V input April, 2007 1.10...
  • Page 3 ISDM Series Industrial Monitor Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 ISDM Series Industrial Monitor Manual Conventions WARNING! Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. Warnings are easy to recognize. The word “warning” is written as “WARNING,” both capitalized and bold and is followed by text.
  • Page 5 ISDM Series Industrial Monitor CAUTION: This is an example of a caution message. Failure to adhere to cautions messages may result in permanent damage to the ISDM Series. Please take caution messages seriously. NOTE: These messages inform the reader of essential but non-critical information. These messages should be read carefully as any directions or instructions contained therein can help avoid making mistakes.
  • Page 6 ISDM Series Industrial Monitor Packing List NOTE: If any of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the ISDM Series from or contact an IEI sales representative directly.

  • Page 7: Table Of Contents

    ISDM Series Industrial Monitor Table of Contents INTRODUCTION....................18 1.1 ISDM S ............. 19 ERIES NDUSTRIAL ONITOR VERVIEW 1.1.1 Standard Features .................... 19 1.1.2 Model Variations ....................19 1.1.3 Base Model Variants ..................20 1.2 A .................. 20 PPLICATIONS AND EATURES 1.2.1 ISDM Series Industrial Monitor Applications ..........
  • Page 8 ISDM Series Industrial Monitor 2.5.4 ISDM-150 Physical Dimensions ..............34 2.5.5 ISDM-121 Physical Dimensions ..............35 2.5.6 ISDM-104 Physical Dimensions ..............36 2.5.7 ISDM-084 Physical Dimensions ..............37 2.6 O ..................38 PTIONAL OUNTING 2.6.1 ISDM-084 Mounting Kits................. 38 2.6.2 ISDM-104 Mounting Kits................. 38 2.6.3 ISDM-121 Mounting Kits.................
  • Page 9 ISDM Series Industrial Monitor 4.2 AV-5350 AD B ....................59 OARD 4.2.1 AV-5350 AD Board Overview ................59 4.2.2 AV-5350 AD Board Connectors ............... 59 4.2.3 AV-5350 AD Board Layout................60 4.2.4 AV-5350 Peripheral Interface Connectors............61 4.2.5 AV-5350 Rear Panel Connectors ..............61 4.2.6 AV-5350 On-board Jumper ................
  • Page 10 ISDM Series Industrial Monitor 4.3.17 LCD Panel Voltage Select Jumper ..............86 4.3.18 AV-5300 External (Rear Panel) Connectors..........87 4.3.19 DC 12V Connector..................87 4.3.20 VGA Connector ....................88 4.3.21 DVI-D Connector................... 89 INSTALLATION ....................91 5.1 I ................... 92 NSTALLATION RECAUTIONS 5.2 U...
  • Page 11 ISDM Series Industrial Monitor 6.2.1 Main Display Features..................112 6.2.2 Gamma......................113 6.2.3 Color .......................114 6.2.4 Image Settings....................115 6.2.5 OSD Configurations..................116 6.2.6 Signal ......................117 SOFTWARE DRIVERS ..................119 7.1 I ....................... 120 NTRODUCTION 7.2 D ................... 120 RIVER NSTALLATION 7.3 T ..............127 OUCH ANEL RIVER...
  • Page 12 ISDM Series Industrial Monitor C.4.8 About Page ....................149 OSD FAQ ....................150 SMART C.5.1 Windows 2000 Installation Failure ............... 150 C.5.2 Vista Installation Failure................151 C.5.3 Model Failure....................152 C.5.4 DCC Port Failure..................152 Page 12...
  • Page 13 ISDM Series Industrial Monitor List of Figures Figure 1-1: ISDM Series Front View................22 Figure 1-2: Typical Bottom Panel View ..............22 Figure 1-3: AV-5300 AD Board ...................23 Figure 2-1: Front Panel ....................27 Figure 2-2: Rear Panel ....................28 Figure 2-3: ISDM-190 Physical Dimensions (millimeters) ........32 Figure 2-4: ISDM-170 Physical Dimensions (millimeters) ........33 Figure 2-5: ISDM-150 Physical Dimensions (millimeters) ........34 Figure 2-6: ISDM-121 Physical Dimensions (millimeters) ........35...
  • Page 14 ISDM Series Industrial Monitor Figure 4-14: Auto-dimming Connector Location .............77 Figure 4-15: Debug Port Connector Location ............78 Figure 4-16: External OSD and LED Indication Connector Location.....79 Figure 4-17: Backlight Inverter Connector Location ..........80 Figure 4-18: LVDS Output Connector Location ............81 Figure 4-19: Power Output Connector Locations ............82 Figure 4-20: Power Input Connector Locations ............83 Figure 4-21: VGA Connector Location ..............84...
  • Page 15 ISDM Series Industrial Monitor Figure 6-4: Color Options..................114 Figure 6-5: Image Settings Menu................115 Figure 6-6: OSD Configurations Menu ..............116 Figure 6-7: Signal Menu................... 117 Figure 7-1: Driver CD Pop Up Screen..............121 Figure 7-2: Install Shield Wizard Preparation............122 Figure 7-3: Welcome Screen ...................
  • Page 16 ISDM Series Industrial Monitor List of Tables Table 1-1: ISDM Series Base Model Variants ............20 Table 1-2: ISDM Series Specifications ..............25 Table 2-1: General Physical Dimensions ..............31 Table 2-2: ISDM-084 Mounting Kits ................38 Table 2-3: ISDM-104 Mounting Kits ................38 Table 2-4: ISDM-121 Mounting Kits ................39 Table 2-5: ISDM-150 Mounting Kits ................39 Table 2-6: ISDM-170 Mounting Kits ................39 Table 2-7: ISDM-190 Mounting Kits ................40...
  • Page 17 ISDM Series Industrial Monitor Table 4-7: LVDS Output Connector Pinouts.............66 Table 4-8: VGA Connector Pinouts ................68 Table 4-9: DC 12V Connector Pinouts...............69 Table 4-10: VGA Connector Pinouts .................70 Table 4-11: LCD Panel Voltage Select Jumper Settings .........71 Table 4-12: AV-5300 Peripheral Interface Connectors ..........75 Table 4-13: AV-5300 Rear Panel Connectors ............76 Table 4-14: AV-5300 On-board Jumpers ..............76 Table 4-15: Auto-dimming Connector Pinouts............77...

  • Page 18: Introduction

    ISDM Series Industrial Monitor Chapter Introduction Page 18...

  • Page 19: Isdm Series Industrial Monitor Overview

    Stainless steel front frame Heavy-duty steel chassis OSD function IP 65 level protection RoHS compliance 1.1.2 Model Variations The ISDM LCD series have the following seven base models. ISDM-084G: 8.4” LCD screen ISDM-104G: 10.4” LCD screen ISDM-121G: 12.1” LCD screen ISDM-150G: 15”...

  • Page 20: Base Model Variants

    ISDM Series Industrial Monitor 1.1.3 Base Model Variants The ISDM series industrial monitor base models may or may not have a variety of variants. The standard model name is ISDM-(XXX)G, where (XXX) refers to three digit size of the monitor. Special features with the associated model prefix are listed in Table 1-1. 9~36V High Touch...

  • Page 21: Isdm Series Industrial Monitor Features

    ISDM Series Industrial Monitor X-ray imaging terminal Multimedia advertising platform Self-service Kiosk Full-service receptionist kiosk Hospital self-registration terminal General Computing Computer-based testing center General purpose information system Mobile nursing station Interactive education use 1.2.2 ISDM Series Industrial Monitor Features Some of the features of the ISDM series industrial monitor include: IP 65 compliant stainless steel front panel Analog VGA interface supports most general system boards RS-232 or USB interface touch panel...

  • Page 22: Front View

    ISDM Series Industrial Monitor 1.3.1 Front View The front of the ISDM series industrial monitor is a flat panel TFT LCD screen surrounded by a stainless steel frame (Figure 1-1). Figure 1-1: ISDM Series Front View 1.3.2 Bottom Panel View Figure 1-2 shows the bottom panel of the ISDM-104 monitor.

  • Page 23: Ad Board

    ISDM Series Industrial Monitor 1.3.3 AD Board The ISDM series industrial monitor AD board provides a wide variety of control interfaces, receiving and managing signals from a CPU card through cabling. Figure 1-3 shows the AV-5300 AD board as a sample of a typical AD board for the ISDM series industrial monitor.
  • Page 24 ISDM Series Industrial Monitor Model ISDM-084G ISDM-104G ISDM-121G ISDM-121GX ISDM-150G ISDM-170G ISDM-190G LCD Size 8.4" 10.4" 12.1" 12.1" 15" 17" 19" Input Interface DVI-D DVI-D DVI-D DVI-D DVI-D Max. 800x600 800x600 800x600 1024x768 1024x768 1280x1024 1280x1024 Resolution Brightness (cd/m2) Contrast...

  • Page 25: Certifications

    ISDM Series Industrial Monitor Table 1-2: ISDM Series Specifications 1.5 Certifications All ISDM series industrial monitor models comply with the following international standards: RoHS IP 65 For a more detailed description of these standards, please refer to Appendix B. Page 25...

  • Page 26: Mechanical Overview

    ISDM Series Industrial Monitor Chapter Mechanical Overview Page 26...

  • Page 27: Introduction

    ISDM Series Industrial Monitor 2.1 Introduction This chapter describes the general mechanical overview of the ISDM series monitors including front and bottom panel variations, available interfaces and overall dimensions. 2.2 Front Panel The front panel of the ISDM series industrial monitor is comprised of a TFT LCD in an stainless steel frame.

  • Page 28: Bottom Panel

    ISDM Series Industrial Monitor Figure 2-2: Rear Panel 2.4 Bottom Panel All peripheral device connectors are located on the bottom panel of the ISDM series industrial monitor. The following sections describe the bottom panel variants and their associated connectors. 2.4.1 Available Connectors There are a number of bottom panel peripheral device connectors available for the ISDM series industrial monitor.

  • Page 29: Isdm-104 Connectors

    ISDM Series Industrial Monitor VGA connector 12V power connector RS-232 serial connector 9~36V terminal block (M models only) 2.4.3 ISDM-104 Connectors The following is a list of the bottom panel peripheral device connectors used on the ISDM-104 series industrial monitor. VGA connector 12V power connector RS-232 serial connector...

  • Page 30: Isdm-170 Connectors

    ISDM Series Industrial Monitor USB connector (USB/T-R models only) 2.4.6 ISDM-170 Connectors The following is a list of the bottom panel peripheral device connectors used on the ISDM-170 series industrial monitor. VGA connector DVI-D connector 12V power connector 9~36V terminal block (M models only) RS-232 serial connector (T-R models only)

  • Page 31: Physical Dimensions

    ISDM Series Industrial Monitor 2.5 Physical Dimensions The following sections describe the physical dimensions for each model of the ISDM series industrial monitor. 2.5.1 General Physical Dimensions General physical dimensions for the ISDM series industrial monitors are shown in Table 2-1.

  • Page 32: Figure 2-3: Isdm-190 Physical Dimensions (Millimeters)

    ISDM Series Industrial Monitor Figure 2-3: ISDM-190 Physical Dimensions (millimeters) Page 32...

  • Page 33: Isdm-170 Physical Dimensions

    ISDM Series Industrial Monitor 2.5.3 ISDM-170 Physical Dimensions The physical dimensions of the ISDM-170 are shown in Figure 2-4. Figure 2-4: ISDM-170 Physical Dimensions (millimeters) Page 33...

  • Page 34: Isdm-150 Physical Dimensions

    ISDM Series Industrial Monitor 2.5.4 ISDM-150 Physical Dimensions The physical dimensions of the ISDM-150 are shown in Figure 2-5. Figure 2-5: ISDM-150 Physical Dimensions (millimeters) Page 34...

  • Page 35: Isdm-121 Physical Dimensions

    ISDM Series Industrial Monitor 2.5.5 ISDM-121 Physical Dimensions The physical dimensions of the ISDM-121 are shown in Figure 2-6. Figure 2-6: ISDM-121 Physical Dimensions (millimeters) Page 35...

  • Page 36: Isdm-104 Physical Dimensions

    ISDM Series Industrial Monitor 2.5.6 ISDM-104 Physical Dimensions The physical dimensions of the ISDM-104 are shown in Figure 2-7. Figure 2-7: ISDM-104 Physical Dimensions (millimeters) Page 36...

  • Page 37: Isdm-084 Physical Dimensions

    ISDM Series Industrial Monitor 2.5.7 ISDM-084 Physical Dimensions The physical dimensions of the ISDM-084 are shown in Figure 2-8. Figure 2-8: ISDM-084 Physical Dimensions (millimeters) Page 37...

  • Page 38: Optional Mounting Kits

    ISDM Series Industrial Monitor 2.6 Optional Mounting Kits The following sections describe the various optional mounting kits available for each model of the ISDM series industrial monitor. Refer to Section 5.5 for detailed instructions on the different mounting methods for the monitors. 2.6.1 ISDM-084 Mounting Kits Table 2-2 lists the mounting kits available for the ISDM-084 monitor.

  • Page 39: Isdm-150 Mounting Kits

    ISDM Series Industrial Monitor LCD Monitor Arm ARM-11-RS LCD Monitor Stand STAND-100-RS Table 2-4: ISDM-121 Mounting Kits 2.6.4 ISDM-150 Mounting Kits Table 2-5 lists the mounting kits available for the ISDM-150 monitor. Model ISDM-150 Panel Mounting Kit PK-150M Wall Mounting Kit WK-150MS-R10 LCD Monitor Arm ARM-31-RS...

  • Page 40: Mounting Options

    ISDM Series Industrial Monitor LCD Monitor Stand STAND-200-RS Table 2-7: ISDM-190 Mounting Kits 2.7 Mounting Options Each ISDM series industrial monitor has a number of mounting holes or slots located on the back side of the aluminum frame or on the rear panel for mounting the monitor to a panel, wall, arm or stand.

  • Page 41: Wall Mounting

    ISDM Series Industrial Monitor Model Mounting Clamps ISDM-190 ISDM-170 ISDM-150 ISDM-121 ISDM-104 ISDM-084 Table 2-8: Panel Mounting Clamps 2.7.2 Wall Mounting Each model of the ISDM series industrial monitor has four holes located on the rear panel for mounting the monitor to a wall. Figure 2-10 shows the typical methods for wall mounting.

  • Page 42: Monitor Arm Or Stand Mounting

    ISDM Series Industrial Monitor 2.7.3 Monitor Arm or Stand Mounting Most models of the ISDM series industrial monitor have four or eight Video Electronics Standards Association (VESA) standard holes located on the rear panel for mounting the monitor to a monitor arm or stand. NOTE: There is no monitor stand available for the ISDM-190 monitor.
  • Page 43 ISDM Series Industrial Monitor THIS PAGE IS INTENTIONALLY LEFT BLANK Page 43...

  • Page 44: Lcd And Touch Panel Specifications

    ISDM Series Industrial Monitor Chapter LCD and Touch Panel Specifications Page 44...

  • Page 45: Lcd Specifications

    ISDM Series Industrial Monitor 3.1 LCD Specifications 3.1.1 LCD Overview The ISDM series industrial monitors use the following LCD panels. AUO M190EG02 ISDM-190: AUO M170EG01 ISDM-170: AUO G150XG01 ISDM-150: AUO G121SN01 ISDM-121: CHI MEI G121X1-L01 ISDM-121GX: AUO G104SN03/ Toshiba LTA104D182F ISDM-104: AUO G084SN03/ Toshiba LTA084C270F ISDM-084:...

  • Page 46: Isdm-190 Lcd Specifications

    ISDM Series Industrial Monitor 3.1.2 ISDM-190 LCD Specifications Table 3-1 lists the ISDM-190 LCD specifications. Model ISDM-190 Size 19” MFR/Model AUO/M190EG02 Resolution SXGA (1280 x 1024) Active Area (mm) 376.3 x 301.1 Pixel Pitch (mm) 0.294 Mode Number of Colors 16.2M Color Saturation (NTSC%) View Angle (H/V)

  • Page 47: Isdm-170 Lcd Specifications

    ISDM Series Industrial Monitor 3.1.3 ISDM-170 LCD Specifications Table 3-2 lists the ISDM-170 LCD specifications. Model ISDM-170 Size 17" MFR/Model AUO/M170EG01 Resolution SXGA (1280 x 1024) Active Area (mm) 337.9 x 270.3 Pixel Pitch (mm) 0.264 Mode Number of Colors 16.2M Color Saturation (NTSC%) View Angle (H/V)

  • Page 48: Isdm-150 Lcd Specifications

    ISDM Series Industrial Monitor 3.1.4 ISDM-150 LCD Specifications Table 3-3 lists the ISDM-150 LCD specifications. Model ISDM-150 Size 15" MFR/Model AUO/G150XG01 Resolution XGA (1024 x 768) Active Area (mm) 304.1 x 228.1 Pixel Pitch (mm) 0.297 Mode Number of Colors 262K Color Saturation (NTSC%) View Angle (H/V)

  • Page 49: Isdm-121 Lcd Specifications

    ISDM Series Industrial Monitor 3.1.5 ISDM-121 LCD Specifications Table 3-4 lists the ISDM-121 LCD specifications. Model ISDM-121G ISDM-121GX Size 12.1” 12.1” MFR/Model AUO/G121SN01 CHE MEI/G121X1-L01 Resolution SVGA (800 x 600) XGA (1024 x 768) Active Area (mm) 246.0 x 184.5 245.76 x 184.32 Pixel Pitch (mm) 0.307...

  • Page 50: Isdm-104 Lcd Specifications

    ISDM Series Industrial Monitor 3.1.6 ISDM-104 LCD Specifications Table 3-5 lists the ISDM-104 LCD specifications. ISDM-104 Model G/GM Model GH/GHM Model Size 10.4” 10.4” MFR/Model AUO/G104SN03 Toshiba/LTA104D182F Resolution SVGA (800 x 600) SVGA (800 x 600) Active Area (mm) 211.2 x 158.4 211.2 x 158.4 Pixel Pitch (mm) 0.264...

  • Page 51: Isdm-084 Lcd Specifications

    ISDM Series Industrial Monitor 3.1.7 ISDM-084 LCD Specifications Table 3-6 lists the ISDM-084 LCD specifications. ISDM-084 Model GH/GHM Models Size 8.4” MFR/Model Toshiba/LTA084C270F Resolution SVGA (800 x 600) Active Area (mm) 170.4 x 127.8 Pixel Pitch (mm) 0.213 Mode Number of Colors 262K View Angle (H/V) 120 / 100...

  • Page 52: Touch Panels

    ISDM Series Industrial Monitor 3.2 Touch Panels IEI offers touch panels for the ISDM series industrial monitors with the following features: Small border customized design All size touch panel design Customized activation force and palm rejection Customized optical characteristics High reliability and durability in the field 3.2.1 Touch Panel Models Table 3-7 lists the ISDM series industrial monitors and their associated touch panels.

  • Page 53: Touch Panel Dimensions

    ISDM Series Industrial Monitor 3.2.2 Touch Panel Dimensions Table 3-8 shows the touch panel dimensions in millimeters. Model: Dimension Width Length Thick Dimensional Outline: 404.6 PanJit Viewing Area: 306.05 381.3 1190503A Active Area: 301.05 376.3 Key Area: 300.05 375.3 Dimensional Outline: 295.08 PanJit Viewing Area:...

  • Page 54: Touch Panel Specifications

    ISDM Series Industrial Monitor 3.2.3 Touch Panel Specifications Table 3-9 lists the touch panel specifications. Type Analog Resistive Type Touch Panel Input Method Finger, Stylus or gloved hand Wire Type 5-wire/4-wire Maximum Voltage and Currant DC7V Position Accuracy Less than 1.5% Isolation ≥20M ohm Resolution...

  • Page 55: Touch Panel Rs-232 Controller Specifications

    ISDM Series Industrial Monitor 3.2.4 Touch Panel RS-232 Controller Specifications Table 3-10 lists the touch panel RS-232 controller specifications. Circuit Board 20mm x 75mm (0.79inches x Dimension 2.95inches)----(5-Wire) Power Requirements D.C.+5V (100mA typical, 50mV peak to peak maximum ripple and noise) Operating 0°C to 50°C Temperature...

  • Page 56: Touch Panel Usb Controller Specifications

    ISDM Series Industrial Monitor 3.2.5 Touch Panel USB Controller Specifications Table 3-11 lists the touch panel USB controller specifications. Circuit Board 20mm x 75mm (0.79inches x Dimension 2.95inches)----(5-Wire) Power Requirements D.C.+5V (100mA typical, 50mV peak to peak maximum ripple and noise) Operating 0°C to 50°C Temperature...

  • Page 57: Power Adapters

    ISDM Series Industrial Monitor 3.3 Power Adapters Table 3-12 lists the AC/DC power adapter specifications. Model ISDM-190, ISDM-170, ISDM-150, ISDM-104, ISDM-084 ISDM-121 Power 45 Watt AC/DC Adapter 25 Watt AC/DC Adapter General Description Universal Input 90 to 264 VAC Universal Input 90 to 264 VAC EMI Meets FCC/CISPR 22 Class B EMI Meets FCC/CISPR 22 Class B MTBF 165Khrs...

  • Page 58: Ad Boards

    ISDM Series Industrial Monitor Chapter AD Boards Page 58...

  • Page 59: Ad Board Overview

    ISDM Series Industrial Monitor 4.1 AD Board Overview The ISDM series industrial monitor AD board provides a wide variety of control interfaces, receiving and managing interface signals from a CPU card through cabling. There are two AD boards used for the ISDM series monitors: AV-5350 and AV-5300. Refer to Table 1-2 for a listing of ISDM series monitors and their associated AD board.

  • Page 60: Av-5350 Ad Board Layout

    ISDM Series Industrial Monitor 1 x VGA connector 1 x External OSD and LED Indication connector 1 x LVDS connector 3 x 5V power connector 1 x Backlight Inverter connector The AV-5350 AD board has the following connectors on the board rear panel: 1 x VGA connector 1 x 12V DC power connector The locations of the peripheral interface connectors for the AV-5350 AD board are shown...

  • Page 61: Av-5350 Peripheral Interface Connectors

    ISDM Series Industrial Monitor 4.2.4 AV-5350 Peripheral Interface Connectors Table 4-1 shows a list of the peripheral interface connectors on the AV-5350 AD board. Detailed descriptions of these connectors can be found in Section 4.2.7. Connector Type Label 5V Power connector 2-pin header CN7, CN8, CN9 Backlight Inverter connector...

  • Page 62: Av-5350 On-Board Jumper

    ISDM Series Industrial Monitor 4.2.6 AV-5350 On-board Jumper Table 4-3 lists the on-board jumper. A detailed description of the jumper can be found in Section 4.2.16. Jumper Type Label LCD Panel Voltage Select 3-pin header Table 4-3: AV-5350 On-board Jumper 4.2.7 AV-5350 Internal Peripheral Connectors Internal peripheral connectors on the AV-5350 AD board are only accessible when the board is outside of the monitor.

  • Page 63: Backlight Inverter Connector

    ISDM Series Industrial Monitor Figure 4-3: 5V Power Connector Location 4.2.9 Backlight Inverter Connector CN Label: 6-pin header CN Type: See Table 4-5 CN Pinouts: See Figure 4-4 CN Location: The Inverter connector connects to the LCD backlight. DESCRIPTION +12V +12V On/Off BKLT_ADJ...

  • Page 64: External Osd And Led Indication Connector

    ISDM Series Industrial Monitor Figure 4-4: Backlight Inverter Connector Location 4.2.10 External OSD and LED Indication Connector CN Label: 9-pin header CN Type: See Table 4-6 CN Pinouts: See Figure 4-5 CN Location: The External OSD and LED Indication connector connects to an external OSD controller. Page 64...

  • Page 65: Figure 4-5: External Osd And Led Indication Connector Location

    ISDM Series Industrial Monitor DESCRIPTION LED_ORANGE LED_GREEN MENU/ENTER RIGHT LEFT AUTO LCD ON/OFF Table 4-6: External OSD and LED Indication Connector Pinouts Figure 4-5: External OSD and LED Indication Connector Location Page 65...

  • Page 66: Lvds Output Connector

    ISDM Series Industrial Monitor 4.2.11 LVDS Output Connector CN Label: 30-pin header CN Type: See Table 4-7 CN Pinouts: See Figure 4-6 CN Location: Use the LVDS output connector to connect the LCD panel to a system. DESCRIPTION DESCRIPTION TXO3+ TXO3- TXOC+ TXOC-...

  • Page 67: Vga Connector

    ISDM Series Industrial Monitor Figure 4-6: LVDS Output Connector Location NOTE: The supply voltage (3.3V (Default), 5V or 12V) can be selected via JP1. 4.2.12 VGA Connector CN Label: 10-pin header CN Type: See Table 4-8 CN Pinouts: See Figure 4-7 CN Location: In addition to the standard DB-15 female VGA connector (J1), a VGA connection can also be made through the on-board CN2 10-pin header.

  • Page 68: Av-5350 External (Rear Panel) Connectors

    ISDM Series Industrial Monitor DESCRIPTION DESCRIPTION DDCCLK GREEN DDCDAT BLUE GROUND HSYNC GROUND VSYNC GROUND Table 4-8: VGA Connector Pinouts Figure 4-7: VGA Connector Location 4.2.13 AV-5350 External (Rear Panel) Connectors Figure 4-8 shows the AV-5350 external (rear panel) connectors. The peripheral connectors on the back panel of the monitor can connect to external devices.

  • Page 69: Dc 12V Connector

    ISDM Series Industrial Monitor Figure 4-8: AV-5350 External (Rear Panel) Connectors 4.2.14 DC 12V Connector CN Label: DC 12V Jack CN Type: See Table 4-9 CN Pinouts: See Figure 4-8 CN Location: Use the DC 12V connector to power the monitor. DESCRIPTION DC 12V Table 4-9: DC 12V Connector Pinouts...

  • Page 70: Av-5350 On-Board Jumper

    ISDM Series Industrial Monitor DESCRIPTION DESCRIPTION No Connect Green Ground Blue No Connect No Connect DDC DAT Ground Horizontal Synchronization Ground Vertical Synchronization Ground DDC Clock Ground Table 4-10: VGA Connector Pinouts Figure 4-9: VGA Connector Pinout Locations 4.2.16 AV-5350 On-board Jumper NOTE: A jumper is a metal bridge used to close an electrical circuit.

  • Page 71: Lcd Panel Voltage Select Jumper

    ISDM Series Industrial Monitor Figure 4-11: Jumper Location 4.2.17 LCD Panel Voltage Select Jumper Jumper Label: 6-pin header Jumper Type: See Figure 4-11 Jumper Location: See Table 4-11 Jumper Settings: The JP1 jumper sets the voltage to the LCD panel. Description Panel Voltage select 3.3V (Default) Panel Voltage select 5V...

  • Page 72: Av-5300 Ad Board Overview

    ISDM Series Industrial Monitor 4.3 AV-5300 AD Board Overview The AV-5300 AD board provides a wide variety of control interfaces, receiving and managing interface signals from a CPU card through cabling. The following sections describe the AV-5300 AD board in detail. Figure 4-12: AV-5300 AD Board Overview Page 72...

  • Page 73: Av-5300 Ad Board Connectors

    ISDM Series Industrial Monitor 4.3.1 AV-5300 AD Board Connectors The AV-5300 AD board has the following connectors on-board: 1 x Auto-dimming connector 1 x Debug connector 1 x External OSD and LED Indication connector 1 x Inverter interface connector 1 x LVDS connector 2 x Power output connector 2 x Power input connector 1 x VGA connector...

  • Page 74: Av-5300 Ad Board Layout

    ISDM Series Industrial Monitor 4.3.2 AV-5300 AD Board Layout Figure 4-13 shows the on-board peripheral connectors and on-board jumpers. Figure 4-13: Connector and Jumper Locations Page 74...

  • Page 75: Av-5300 Peripheral Interface Connectors

    ISDM Series Industrial Monitor 4.3.3 AV-5300 Peripheral Interface Connectors Table 4-12 shows a list of the peripheral interface connectors on the AV-5300 AD board. Detailed descriptions of these connectors can be found in Section 4.3.6. Connector Type Label Auto-dimming connector 6-pin wafer CN16 connector...

  • Page 76: Av-5300 On-Board Jumpers

    ISDM Series Industrial Monitor Connector Type Label 12V DC power connector DC Power Jack DVI connector 24-pin DVI-D connector VGA connector 15-pin VGA connector Table 4-13: AV-5300 Rear Panel Connectors 4.3.5 AV-5300 On-board Jumpers Table 4-14 lists the on-board jumpers. A detailed description of these jumpers can be found in Section 4.3.15.

  • Page 77: Debug Port Connector

    ISDM Series Industrial Monitor DESCRIPTION +3.3V Table 4-15: Auto-dimming Connector Pinouts Figure 4-14: Auto-dimming Connector Location 4.3.8 Debug Port Connector CN Label: CN Type: 4-pin wafer connector CN Pinouts: See Table 4-16 CN Location: See Figure 4-15 Use the debug port connector to update the AD board BIOS. DESCRIPTION Page 77...

  • Page 78: External Osd And Led Indication Connector

    ISDM Series Industrial Monitor Table 4-16: Debug Port Connector Pinouts Figure 4-15: Debug Port Connector Location 4.3.9 External OSD and LED Indication Connector CN Label: CN Type: 9-pin wafer connector CN Pinouts: See Table 4-17 CN Location: See Figure 4-16 The External OSD and LED Indication connector connects to an external OSD controller.

  • Page 79: Backlight Inverter Connector

    ISDM Series Industrial Monitor Table 4-17: External OSD and LED Indication Connector Pinouts Figure 4-16: External OSD and LED Indication Connector Location 4.3.10 Backlight Inverter Connector CN Label: CN Type: 6-pin wafer connector CN Pinouts: See Table 4-18 CN Location: See Figure 4-17 The Inverter connector connects to the LCD backlight.

  • Page 80: Lvds Output Connector

    ISDM Series Industrial Monitor Table 4-18: Backlight Inverter Connector Pinouts Figure 4-17: Backlight Inverter Connector Location 4.3.11 LVDS Output Connector CN Label: CN Type: 30-pin connector CN Pinouts: See Table 4-19 CN Location: See Figure 4-18 Use either LVDS output connector to connect the LCD panel to a system. DESCRIPTION DESCRIPTION TXO3+...

  • Page 81: Power Output Connector

    ISDM Series Industrial Monitor DESCRIPTION DESCRIPTION TXEC+ TXEC- TXE2+ TXE2- TXE1+ TXE1- TXE0+ TXE0- Table 4-19: LVDS Output Connector Pinouts Figure 4-18: LVDS Output Connector Location NOTE: The supply voltage (3.3V (Default), 5V or 12V) can be selected via JP1. 4.3.12 Power Output Connector CN Label: CN12, CN13...

  • Page 82: Power Input Connector

    ISDM Series Industrial Monitor CN Pinouts: See Table 4-20 and Table 4-21 CN Location: See Figure 4-19 The AV-5300 supports two power output connectors, one for 12V and the other for 5V. DESCRIPTION +12V Table 4-20: Power Output Connector Pinouts (CN12) DESCRIPTION Table 4-21: Power Output Connector Pinouts (CN13) Figure 4-19: Power Output Connector Locations...

  • Page 83: Figure 4-20: Power Input Connector Locations

    ISDM Series Industrial Monitor CN Type: 2-pin wafer connector, 3-pin wafer connector CN Pinouts: See Table 4-22 and Table 4-23 CN Location: See Figure 4-20 The AV-5300 supports two internal power input connectors. DESCRIPTION +12V Table 4-22: Power Input Connector Pinouts (CN24) DESCRIPTION +12V Input +9V~36V to external power...

  • Page 84: Vga Connector

    ISDM Series Industrial Monitor 4.3.14 VGA Connector CN Label: CN Type: 10-pin box header CN Pinouts: See Table 4-24 CN Location: See Figure 4-21 In addition to the standard DB-15 female VGA connector (J1), a VGA connection can also be made through the on-board CN2 10-pin header. DESCRIPTION DESCRIPTION SMCLK...

  • Page 85: Av-5300 On-Board Jumpers

    ISDM Series Industrial Monitor 4.3.15 AV-5300 On-board Jumpers NOTE: A jumper is a metal bridge used to close an electrical circuit. It consists of two or three metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 86: Lcd Panel Power Input Jumper

    ISDM Series Industrial Monitor 4.3.16 LCD Panel Power Input Jumper Jumper Label: Jumper Type: 6-pin header Jumper Location: See Figure 4-23 Jumper Settings: See Table 4-25 The JP4 jumper sets the input source from either the 12V power connector (J3) or the external terminal block.

  • Page 87: Av-5300 External (Rear Panel) Connectors

    ISDM Series Industrial Monitor 4.3.18 AV-5300 External (Rear Panel) Connectors Figure 4-24 shows the AV-5300 external (rear panel) connectors. The peripheral connectors on the back panel of the monitor can connect to external devices. The peripheral connectors on the rear panel are: 1 x DC 12V connector 1 x DVI-D connector 1 x VGA connector...

  • Page 88: Vga Connector

    ISDM Series Industrial Monitor 4.3.20 VGA Connector CN Label: CN Type: D-sub 15 female connector CN Pinouts: See Table 4-28 and Figure 4-25 CN Location: See Figure 4-24 Use the standard D-sub 15-pin VGA connector to connect the monitor to a system. DESCRIPTION DESCRIPTION No Connect...

  • Page 89: Dvi-D Connector

    ISDM Series Industrial Monitor 4.3.21 DVI-D Connector CN Label: CN Type: D-sub DVI female connector CN Pinouts: See Table 4-29 and Figure 4-26 CN Location: See Figure 4-24 The 24-pin female dual link digital only DVI [Digital Visual Interface] connector is a standard for high-speed, high-resolution digital displays.

  • Page 90: Figure 4-26: Dvi-D Connector Pinout Locations

    ISDM Series Industrial Monitor Figure 4-26: DVI-D Connector Pinout Locations Page 90...

  • Page 91: Installation

    ISDM Series Industrial Monitor Chapter Chapter Installation Page 91...

  • Page 92: Installation Precautions

    ISDM Series Industrial Monitor 5.1 Installation Precautions When installing the ISDM series industrial monitor, please follow the precautions listed below: Read the user manual: The user manual provides a complete description of the ISDM series industrial monitor, installation instructions and configuration options.

  • Page 93: Unpacking

    ISDM Series Industrial Monitor 5.2 Unpacking 5.2.1 Packaging When shipped, the ISDM series industrial monitor is wrapped in a plastic bag. Two polystyrene ends are placed on either side of the monitor. The monitor is then placed into a first (internal) cardboard box. This box is then sealed and placed into a second (external) cardboard box.

  • Page 94: Packing List

    ISDM Series Industrial Monitor Make sure all the components listed in the packing list are present. Step 7: Step 0: 5.2.3 Packing List All the monitors in the ISDM series are shipped with the following components: 1 x ISDM-190/170/150/121/104/84 series industrial monitor. 1 x AC Power cable 1 x VGA Cable 1 x 45W AC Power Adapter (ISDM-190 / 170 / 150 / 121)

  • Page 95: Voltage Select Jumper Settings

    ISDM Series Industrial Monitor 5.3.2 Voltage Select Jumper Settings If the monitor comes with both 12V and 9~36V DC power connectors, the voltage select jumper on the integrated AD board must be configured for the DC connector that is used to power the monitor.

  • Page 96: Connectors

    ISDM Series Industrial Monitor 5.4 Connectors Table 5-1 lists the rear panel connectors for the ISDM series industrial monitors. ISDM-084G ISDM-104G ISDM-121G ISDM-150G ISDM-170G ISDM-190G DVI-D Power (12V Jack) Touch Panel Power (9~36V) (Optional) Table 5-1: Rear Panel Connectors Page 96...

  • Page 97: Rear Panel Connectors Overview

    ISDM Series Industrial Monitor 5.4.1 Rear Panel Connectors Overview Figure 5-1: Monitor Rear Panel Connections Figure 5-1 shows all the possible rear panel connectors for the ISDM series industrial monitor. Refer to Table 5-1 for a list of the monitors and their corresponding connectors. The following sections fully describe the rear panel connectors for the ISDM series industrial monitor.

  • Page 98: Dvi-D Connector

    ISDM Series Industrial Monitor Figure 5-2: VGA Connector 5.4.3 DVI-D Connector Use the rear panel standard 24-pin female DVI-D connector to connect the monitor to the system graphics interface. DESCRIPTION DESCRIPTION DESCRIPTION TMDS Data2- TMDS Data1- TMDS Data0- TMDS Data2+ TMDS Data1+ TMDSData0+ TMDS Data2/4 Shield...

  • Page 99: Optional Dc Power Connector

    ISDM Series Industrial Monitor Figure 5-4: 12V Power Connector 5.4.5 Optional DC Power Connector Use the rear panel 3-pin terminal block DC power connector to connect the monitor to a DC power source. Figure 5-5: DC Power Connector 5.4.6 Optional RS-232 Touch Panel Connector Use the rear panel standard RS-232 DB-9 female touch panel connector to connect the monitor to the system graphics interface.

  • Page 100: Optional Usb Touch Panel Connector

    ISDM Series Industrial Monitor Table 5-4: Optional RS-232 Touch Panel Connector Pinouts Figure 5-6: Optional RS-232 Touch Panel Connector 5.4.7 Optional USB Touch Panel Connector Use the rear panel standard USB touch panel connector to connect the monitor to the system graphics interface.

  • Page 101: Mounting The Isdm Series Industrial Monitor

    ISDM Series Industrial Monitor 5.5 Mounting the ISDM Series Industrial Monitor The ISDM series industrial monitor can be mounted in a panel or wall. The monitor can also be mounted on a monitor arm or stand. The mounting methods are described below. CAUTION: When mounting the monitor take care to tighten the retention screws or bolts until fully secure, but do not over tighten.

  • Page 102: Figure 5-8: Panel Opening

    ISDM Series Industrial Monitor Figure 5-8: Panel Opening Slide the monitor through the hole until the metal frame is flush against the panel Step 3: (Figure 5-9). Figure 5-9: Insert the Monitor Insert the panel mounting clamps into the pre-formed holes along the edges of Step 4: the monitor, behind the metal frame.

  • Page 103: Figure 5-10: Panel Mounting Clamp Position

    ISDM Series Industrial Monitor required number of mounting clamps. Figure 5-10: Panel Mounting Clamp Position Tighten the screws that pass through the panel mounting clamps until the plastic Step 5: caps at the front of all the screws are firmly secured to the panel (Figure 5-10). Step 3: Page 103...

  • Page 104: Wall Mounting

    ISDM Series Industrial Monitor 5.5.2 Wall Mounting To mount the ISDM series industrial monitor onto a wall, please follow the steps below. Select a location on the wall for the wall-mounting bracket. Step 4: Carefully mark the locations of the four bracket screw holes on the wall. Step 5: Drill four pilot holes at the marked locations on the wall for the bracket retention Step 6:...

  • Page 105: Figure 5-12: Monitor Support Screws

    ISDM Series Industrial Monitor Figure 5-12: Monitor Support Screws Align the mounting screws on the monitor rear panel with the mounting holes on Step 10: the bracket. Carefully insert the screws through the holes and gently pull the monitor Step 11: downwards until the monitor rests securely in the slotted holes (Figure 5-13).

  • Page 106: Monitor Stand Installation

    ISDM Series Industrial Monitor Figure 5-13: Wall Mounting the Monitor 5.5.3 Monitor Stand Installation The ISDM series industrial monitor has Video Electronics Standards Association (VESA) standard mounting holes tapped into the rear panel. The standard holes are M4 set at 100m x 100mm apart (Figure 5-14).

  • Page 107: Monitor Arm Installation

    ISDM Series Industrial Monitor series industrial monitor onto a stand, please follow the steps below. Line up the threaded holes on the monitor rear panel with the screw holes on the Step 1: monitor stand mounting plate. Secure the monitor to the stand with the supplied retention screws (Figure Step 2: 5-15).Step 0: Figure 5-15: Monitor Stand Mounting...

  • Page 108: Figure 5-16: Monitor Arm Mounting

    ISDM Series Industrial Monitor Secure the monitor to the arm with the supplied retention screws (Figure 5-16). Step 2: Step 0: Figure 5-16: Monitor Arm Mounting Page 108...

  • Page 109: On-Screen-Display (Osd) Controls

    ISDM Series Industrial Monitor Chapter On-Screen-Display (OSD) Controls Page 109...

  • Page 110: User Mode Osd Structure

    ISDM Series Industrial Monitor 6.1 User Mode OSD Structure 6.1.1 OSD Buttons There are several on-screen-display (OSD) control buttons oriented either vertically along the right hand side of the monitor rear panel. Refer to Section 2.3 for availability and orientation of the OSD controls on specific ISDM series monitors. Figure 6-1 shows the arrangement of OSD controls for all models of the ISDM series industrial monitor.

  • Page 111: Osd Menu Structure

    ISDM Series Industrial Monitor 6.1.2 OSD Menu Structure Table 6-1 shows the OSD menu structure for all models of the ISDM series LCD monitor. Level 0 Level 1 Value Main Display Features Menu Brightness 0 to 100 Contrast 0 to 100 Horizontal Size 0 to 100 Sharpness...

  • Page 112: Using The Osd

    ISDM Series Industrial Monitor 6.2 Using the OSD OSD menu options are described below. 6.2.1 Main Display Features Main display features are shown in Figure 6-2. Figure 6-2: Main Display Features Brightness: The brightness option adjusts the brightness of screen. This function adjusts the offset value of ADC.

  • Page 113: Gamma

    ISDM Series Industrial Monitor 6.2.2 Gamma Gamma options are shown in Figure 6-4. Figure 6-3: Color Options The Gamma menu adjusts the gamma for the LCD. Volume: This item adjusts the volume. It is only implemented with models equipped with speakers. Mute: This item mute the audio.

  • Page 114: Color

    ISDM Series Industrial Monitor 6.2.3 Color Color options are shown in Figure 6-4. Figure 6-4: Color Options The Color menu fine-tunes the palette of color hues for the LCD. 9300k: NTSC standard Kelvin 7500k: NTSC standard Kelvin 6500k: NTSC standard Kelvin User Temp: This item allows fine-tuning the balance among Red, Green, and Blue color hues if images look garish or unrealistic.

  • Page 115: Image Settings

    ISDM Series Industrial Monitor 6.2.4 Image Settings The image settings are shown in Figure 6-5. Figure 6-5: Image Settings Menu Image settings are described below. Auto Color: Automatically adjusts the color settings. Width: Adjusts the width of the display screen. Phase: Adjusts the input signal and dot clock position (Analog only).

  • Page 116: Osd Configurations

    ISDM Series Industrial Monitor Adjusts the vertical position of the display screen. 6.2.5 OSD Configurations The OSD configurations are shown in Figure 6-6. Figure 6-6: OSD Configurations Menu OSD Configurations are described below. OSD Time Out: Determines how many seconds the OSD screen stays on screen before it disappears when OSD is left unattended.

  • Page 117: Signal

    ISDM Series Industrial Monitor 6.2.6 Signal The Signal menu in Figure 6-7 enables manual selection of the type of graphic source input: Analog (15-pin VGA) Digital (DVI-D) Figure 6-7: Signal Menu Page 117...
  • Page 118 ISDM Series Industrial Monitor THIS PAGE IS INTENTIONALLY LEFT BLANK Page 118...

  • Page 119: Software Drivers

    ISDM Series Industrial Monitor Chapter Software Drivers Page 119...

  • Page 120: Introduction

    ISDM Series Industrial Monitor 7.1 Introduction The touch panel controller enables analog resistive touch panels for four-wire, five-wire & eight-wire models. The controller directly communicates with the PC system through the touch panel communications interface. The controller design is superior in sensitivity, accuracy, and friendly operation.

  • Page 121: Figure 7-1: Driver Cd Pop Up Screen

    ISDM Series Industrial Monitor Figure 7-1: Driver CD Pop Up Screen Select the operating system installed on the system from the menu on the left Step 3: side of the screen. NOTE: The following description is for driver installation using a Windows 2000 OS.

  • Page 122: Figure 7-2: Install Shield Wizard Preparation

    ISDM Series Industrial Monitor Figure 7-2: Install Shield Wizard Preparation After the Install Shield Wizard is ready, a welcome screen appears (Figure 7-3). Step 5: Figure 7-3: Welcome Screen To continue the installation process click N Step 6: An Install PS/2 interface driver screen appears (Figure 7-4). It is not necessary Step 7: to install the PS/2 interface driver.

  • Page 123: Figure 7-4: Install Ps/2 Interface Driver

    ISDM Series Industrial Monitor Figure 7-4: Install PS/2 Interface Driver Four point calibration options are then selected. Four point calibrations can be Step 8: done every time a user boots up, during the next time the system boots or never. Select if and when a four-point calibration should be done.

  • Page 124: Figure 7-5: Install Ps/2 Interface Driver

    ISDM Series Industrial Monitor Figure 7-5: Install PS/2 Interface Driver The user is then prompted to ensure the touch monitor or the USB for the touch Step 9: controller is plugged into the system (Figure 7-6). Once the touch controller is plugged into the system, click “OK.”...

  • Page 125: Figure 7-7: Controller Installation Directory

    ISDM Series Industrial Monitor Figure 7-7: Controller Installation Directory The user is then prompted to select a file directory in which the program icons Step 11: are saved (Figure 7-8). The default folder is “TouchKit.” If a different folder must be used, select a folder from the list shown.

  • Page 126: Figure 7-8: Program Icon Directory

    ISDM Series Industrial Monitor Figure 7-8: Program Icon Directory The program then starts installing (Figure 7-9). Step 12: Figure 7-9: Installing Page 126...

  • Page 127: Touch Panel Driver Configuration

    ISDM Series Industrial Monitor Once the program is finished installing, the user is prompted to restart the Step 13: computer now or to restart the computer later (Figure 7-10). Select when the computer should be restarted and click “F ” to complete the driver INISH installation procedure.Step 0:...
  • Page 128 ISDM Series Industrial Monitor THIS PAGE IS INTENTIONALLY LEFT BLANK Page 128...

  • Page 129: Asafety Precautions

    ISDM Series Industrial Monitor Appendix Safety Precautions Page 129...

  • Page 130: Safety Precautions

    ISDM Series Industrial Monitor WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the ISDM Series. A.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: A.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times.

  • Page 131: Anti-Static Precautions

    ISDM Series Industrial Monitor A.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the ISDM Series may result in permanent damage to the ISDM Series and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the ISDM Series.

  • Page 132: Cleaning Tools

    ISDM Series Industrial Monitor The interior of the ISDM Series does not require cleaning. Keep fluids away from the ISDM Series interior. Be cautious of all small removable components when vacuuming the ISDM Series. Turn the ISDM Series off before cleaning the ISDM Series. Never drop any objects or liquids through the openings of the ISDM Series.

  • Page 133: Bcertifications

    ISDM Series Industrial Monitor Appendix Certifications Page 133...

  • Page 134: Rohs Compliant

    ISDM Series Industrial Monitor B.1 RoHS Compliant All models in the ISDM industrial monitor series comply with the Restriction of Hazardous Materials (RoHS) Directive. This means that all components used to build the industrial workstations and the workstation itself are RoHS compliant. The RoHS Directive bans the placing on the EU market of new electrical and electronic equipment containing more than agreed levels of lead, caISDMium, mercury, hexavalent chromium, polybrominated biphenyl (PBB) and polybrominated diphenyl ether (PBDE)

  • Page 135: Csmartosd

    ISDM Series Industrial Monitor Appendix smartOSD Page 135...

  • Page 136: Iei Smartosd Quick Installation Guide

    ISDM Series Industrial Monitor C.1 IEI smartOSD Quick Installation Guide IEI smartOSD is a proprietary On-Screen-Display (OSD) software solution from IEI that enables easy, remote monitor setting adjustments in a Windows environment. IEI smartOSD delivers excellent performance and provides more flexibility than the typical OSD hardware solutions when adjusting a monitor.

  • Page 137: Figure 8-2: Smartosd Installer

    ISDM Series Industrial Monitor Figure 7-11: smartOSD Installer Click “Smart OSD” in Figure 7-11. Step 2: The welcome screen shown in Figure 7-12 appears. Step 3: Figure 7-12: smartOSD Welcome Screen Click Next to continue. Step 4: The Folder Select screen in Figure 7-13 appears. Step 5: Page 137...

  • Page 138: Figure 8-4: Smartosd Folder Select Screen

    ISDM Series Industrial Monitor Figure 7-13: smartOSD Folder Select Screen Select the installation folder in Figure 7-13 shown above. Step 6: Click Next to continue. Step 7: The screen in Figure 7-14 appears. Step 8: Figure 7-14: smartOSD Confirm Installation Confirm the installation by clicking Next in the screen above.

  • Page 139: Figure 8-6: Smartosd Installation Progress

    ISDM Series Industrial Monitor Figure 7-15: smartOSD Installation Progress When the installation is complete the “Complete Installation” screen in Figure Step 11: 7-16 appears. Figure 7-16: smartOSD Installation Complete Click Close in the screen above. Step 12: After quick setup is complete, the IEI smartOSD wizard logo appears on the Step 13: desktop as shown in the screen below.

  • Page 140: Software Illustration

    ISDM Series Industrial Monitor C.4 Software Illustration The table below shows the smartOSD menu structure for all IEI LCD monitors. NOTE: To update the display setting status immediately, push the refresh button on every page To turn the system on, press ALT + P. Item Elements Save/Load File...

  • Page 141: Table C-1: Smartosd Menu Structure

    ISDM Series Industrial Monitor Phase Clock Auto Color Color User Red Gain User Green Gain User Blue Gain Color Temperature (5000k and 4200k disabled in the ISDM Series) Gamma PIP (disabled in the ISDM Series) PIP Source Input (disabled in the ISDM Series) PIP Size (disabled in the ISDM Series) Monitor Power Control System...

  • Page 142: Manage Page

    ISDM Series Industrial Monitor C.4.1 Manage Page Figure 7-17: Manage Page Page 142...

  • Page 143: Edid Page

    ISDM Series Industrial Monitor C.4.2 EDID Page Page 143...

  • Page 144: Image Page

    ISDM Series Industrial Monitor C.4.3 Image Page Page 144...

  • Page 145: Display Page (For Analog Signal)

    ISDM Series Industrial Monitor C.4.4 Display Page (for analog signal) Page 145...

  • Page 146: Color Page

    ISDM Series Industrial Monitor C.4.5 Color Page Page 146...

  • Page 147: Pip Page

    ISDM Series Industrial Monitor C.4.6 PIP Page NOTE: The functions in the PIP page are only available in the MDM Series and AFOLUX Series monitors. Page 147...

  • Page 148: System Page

    ISDM Series Industrial Monitor C.4.7 System Page NOTE: Some of the functions in the System Page are only available to some of the IEI LCD series as following: Auto Brightness: SRM, MDM and AFOLUX series only Main Source Input: MDM and AFOLUX series only Volume: AFOLUX series only Mute: AFOLUX series only Page 148...

  • Page 149: About Page

    ISDM Series Industrial Monitor C.4.8 About Page Page 149...

  • Page 150: Smartosd Faq

    ISDM Series Industrial Monitor C.5 smartOSD FAQ For troubleshooting, please see the steps below: C.5.1 Windows 2000 Installation Failure Installation fails under Windows 2000 and shows the following image: Figure C-18: DLL Missing Solution: Download and install service pack Windows Installer 3.1 Page 150...

  • Page 151: Vista Installation Failure

    ISDM Series Industrial Monitor C.5.2 Vista Installation Failure Installation fail under Vista while showing following image: Figure C-19: Windows Vista Error Solution: Install SmartOSD.exe as the administrator authority Figure C-20: Install as Administrator Page 151...

  • Page 152: Model Failure

    ISDM Series Industrial Monitor C.5.3 Model Failure The Model Fail error message shown below appears. Figure C-21: Firmware Incompatibility Solution: SmartOSD only supports firmware version 2.0 and following versions. C.5.4 DCC Port Failure The DDC port fail error message shown below appears. Figure C-22: DCC Port Failure Solutions: Check VGA or DVI cable...

This manual is also suitable for:

Isdm-104gIsdm-150gIsdm-121gIsdm-170gIsdm-190g

Table of Contents
