HDMI Splitter
USER MANUAL
1 Function
SHD2/SHD4/SHD8 is equipped with high-quality 1 input, 2 / 4 / 8 outputs distribution chip,
perfect matching with outside devices and anti-static function enable the advantages over others
in distributing HDMI signal.
It is a HDMI 1 x 2/4/8 splitter with HDMI 1.3 connectors, HDCP compliant, HDTV compatible, up
to 1920*1200@60Hz, 1080p, 2k.
2 SHD2 / SHD4 /SHD8 (HDMI splitter 1x2 / 1x4 / 1X8)
SHD2:
SHD8:
PTN electronics Limited
HDMI Splitter
SHD2, SHD4 & SHD8
SHD4
www.PTN-electronics.com
