Summary of Contents for PTN SUH2
- Page 1 User Manual SUH2 PTN 4K HDMI Splitter 1x2 All Rights Reserved Version: SUH2_2014V1.0 www.PTN-electronics.com...
- Page 2 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. PTN Electronics Limited www.PTN-electronics.com...
- Page 3 Please refer to the dealers for the latest details. This manual is copyright PTN Electronics Limited. All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of PTN Electronics Limited.
-
Page 4: Table Of Contents
4K HDMI Splitter 1x2 Contents 1. Introduction ......................... 1 1.1 Introduction to SUH2 ..................1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Panel Description ......................2 2.1 Front Panel ......................2 2.2 Rear Panel ......................3 3. System Connection ..................... 4 3.1 Usage Precautions .................... -
Page 5: Introduction
1. Introduction 1.1 Introduction to SUH2 SUH2 is a HDMI splitter featuring the capability to repeat HDMI or DVI source to 2 displays synchronously. Compliance with HDMI 1.4& HDCP1.4, SUH2 provides comprehensive resolution capacities up to 4K& 1080p 3D. It’s capable to automatically recognize the resolution and HDCP compliant status of the input signal. -
Page 6: Panel Description
HDMI OUTPUT 1~2 separately ④ FIRMWARE USB port, used for firmware update. Note: Output HDCP compliant status depends on input signal. When the input signal is with HDCP, then output signal is with HDCP and vice versa. PTN Electronics Limited www.PTN-electronics.com... -
Page 7: Rear Panel
Dolby Digital , DTS, DTS-HD) , while DVI signal contains solely video signal. c) SUH2 is capable to switch input signal format according to the displays. For example, when the input signal is HDMI and the display can only support DVI signal, SUH2 will switch the signal into DVI format. -
Page 8: System Connection
Step1. Connect a HDMI/ DVI source device (e.g. Blue-ray DVD) to the HDMI INPUT socket of SUH2 with HDMI cable. Step2. Connect HDMI displays to HDMI OUTPUT sockets of SUH2 with HDMI cable. Step3. Plug a DC 5V power adapter to the power port of SUH2. -
Page 9: Application
& control center and smart house etc. 3.5 Firmware Upgrade SUH2 boasts a USB port for online firmware upgrade. Follow these steps to upgrade firmware: Step1. Copy the latest upgrade file (.hex) to PC. -
Page 10: Specification
Max Pixel Clock 340MHz Gain HDCP Compliant with HDCP1.4 EDID In-built EDID management General Reference Temperature -10 ~ +40℃ 10% ~ 90% Humidity Power 2.5 W Power DC 5V 1A Consumption Dimension Weight 0.08kg 100x 11x 70mm (W*H*D) PTN Electronics Limited www.PTN-electronics.com... -
Page 11: Supported Input Video Formats
1920 x 1080I@30Hz 3840 x 2160@25Hz 3840 x 2160@30Hz 1080P 3D@60Hz Note: SUH2 supports 4k& 3D HDMI signals, please adopt quality HDMI cables compliant with HDMI1.4 for better transmission when connecting 4K or 3D sources. PTN Electronics Limited www.PTN-electronics.com... -
Page 12: Panel Drawing
4K HDMI Splitter 1x2 5. Panel Drawing 100.00 mm 10.96 mm SUH2 FIRMWARE PTN Electronics Limited www.PTN-electronics.com... -
Page 13: Troubleshooting & Maintenance
The connecting cables may Check whether the cables not be connected correctly are connected correctly No HDMI signal output in SUH2 while local HDMI or it may be broken. and in working condition. input is in normal working state Splash screen in output... -
Page 14: After-Sales Service
4K HDMI Splitter 1x2 7. After-sales Service If there appear some problems when running SUH2, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: PTN warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail). - Page 15 4K HDMI Splitter 1x2 PTN Electronics Limited www.PTN-electronics.com...
- Page 16 PTN Electronics Limited Tel: +86-755-2846 1819 Fax: +86-755-8471 7796 Email: info@PTN-electronics.com Website: www.PTN-electronics.com...
