DP-22S /22L /24S
Instruction Manual
Correct operation and periodic maintenance are
essential for ensuring safe use of this machine.
Thoroughly read this manual before using this
machine.
Store this manual so that it can be retrieved whenever needed.
DUPLO CORPORATION
Ver.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Duprinter DP-22SII and is the answer not in the manual?

Questions and answers

Related Manuals for Duplo Duprinter DP-22SII

Summary of Contents for Duplo Duprinter DP-22SII

  • Page 1 DP-22S /22L /24S Instruction Manual Ver.1 Correct operation and periodic maintenance are essential for ensuring safe use of this machine. Thoroughly read this manual before using this machine. DUPLO CORPORATION Store this manual so that it can be retrieved whenever needed.

  • Page 2: Introduction

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Introduction Thank you for your purchase of the Duprinter DP-22SII/22LII/24SII. To ensure safe and efficient prolonged use of this machine, read and thoroughly understand this manual before using this machine.

  • Page 3: Function Quick Reference

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Function Quick Reference The following is a quick reference to the functions of the DP-22SII/22LII/24SII printer.
  • Page 4 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Book Shadow Eraser Mode ..
  • Page 5 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 2-in-1 Layout ..

  • Page 6: Table Of Contents

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Contents Introduction .........................
  • Page 7 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Contents Chapter 3 Printing With Various Function...
  • Page 8 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Contents Chapter 7 Specifications and Maintenance...

  • Page 9: Notes On Safety (Please Read And Observe)

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) Safety Precautions Various symbols and pictures are used in this manual and on the stickers affixed to the machine.
  • Page 10 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) WARNING Do not modify the machine.
  • Page 11 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) CAUTION Before moving the machine, remove the power plug from the outlet.

  • Page 12: Warning Sticker

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) Warning Sticker Keep the WARNING stickers clean at all times.

  • Page 13: Positioning The Machine

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) Positioning the Machine Installing the machine on a flat, stable surface.

  • Page 14: Maintenance

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) Maintenance Clean the exterior of the machine as described below.

  • Page 15: Printing And Duplicating Cautions

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) Printing and Duplicating Cautions There are restrictions on what you may print on this printer.

  • Page 16: Conventions Used In This Manual

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Notes on Safety (Please Read and Observe) Conventions Used in This Manual Each page of descriptions in this manual of how to operate the DP-22SII/22LII/24SII is set up as follows.

  • Page 18: Printing Paper

    Chapter Before Using This Machine This chapter contains essential information such as the names of the machine parts, the names and functions of keys, etc., on the control panel, and the sizes of documents and printing papers that you can use. Please be sure to read this chapter carefully before attempting to use the printer.

  • Page 19: System Setup

    System Setup The machine and its optional equipment are set up as follows: Key card counter Duplo Direct Print System Tape cluster Personal computer Documents prepared on a personal computer can be Cabinet printed on this machine. PC interface kit is required to connect this machine to a personal computer.

  • Page 20: Part Names And Their Functions

    Part Names and Their Functions Printer Appearance Reference Name Function page 32, 38, Document cover Keeps the document in contact with the document glass plate. Feed tray descend switch Press to lower the feed tray. Feed pressure adjuster lever Use to adjust the paper feed pressure. Side guides Slide to match the width of the paper.

  • Page 21: Master Roll

    Part Names and Their Functions Master set lever When the master set lever is pushed, the master is pulled in and set. Master roll Scanner unit Master cover Master cover release lever Lever This lever releases the ink Front cover pack holder.
  • Page 22 Part Names and Their Functions Master ejection core Reference Name Function page — Plate ejection box release lever Press to open the master ejection box. JOG switch Press and hold to rotate the drum for a set time. Use to remove —...

  • Page 23: Control Panel

    Part Names and Their Functions Control Panel 1 : 1 Reference Name Function page “OK” monitor Flashes to display the content of the trouble and lights to indicated the part that caused the trouble in the machine. “ENLARGEMENT” key Press to set the enlargement ratio. “100%”...
  • Page 24 Part Names and Their Functions Reference Name Function page “STOP” key Press to stop printing on the way. If this key is pressed while the machine is stopped, the total number of prints and plates will be displayed on the LCD panel. “PRINT”...

  • Page 25: Lcd Panel

    Part Names and Their Functions LCD Panel 1 0 0% sht 1set Reference Name Function page Print count Displays the number of prints to be made. Sets Displays the number of sets to be printed. Zoom ratio Displays the selected (enlargement/reduction)ratio.

  • Page 26: Turning Power On/Off

    Turning Power ON/OFF This section describes the operating sequence from turning ON the power switch until the printer is ready to make prints, and how to turn OFF the printer power. Turning ON Printer Power ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Connect the power cable to the printer and a wall outlet.

  • Page 27: Turning Off Printer Power

    Turning Power ON/OFF Turning OFF Printer Power ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Switch the power switch to the “...

  • Page 28: Key Card Counter [Available Only With Key Card Counter Installed]

    Turning Power ON/OFF Key Card Counter Available only with Key Card Counter installed With the key card counter installed, you can control the platemaking and print quantities per person or per department, etc. See the Instruction Manual for the Key Card Counter for details. I Inserting a key card When you turn on the power, the icon shown at right is displayed if no key card has been inserted in the key card...

  • Page 29: Document/Printing Paper Specification

    Document/Printing Paper Specification Acceptable Documents I Document glass plate • Weight : Sheet documents, books, etc, not exceeding 10kg. • Size : 297mm X 432mm I ADF • Document thickness : 64g/m to 128g/m • Document size : A3 to A5 size ST to 11x17-in.

  • Page 30: How Platemaking And Printing Is Performed

    How Platemaking and Printing is Performed The machine performs two processes: platemaking and printing. Platemaking In the “platemaking” process, the old master on the drum is removed while the thermal head creates the scanned image on the new master and transfers it onto the drum. Master roll Master ejection box Drum...
  • Page 32 Chapter Printing Using Basic Functions This chapter describes how to make prints using the basic functions, including how to load the document, set zoom ratio, etc. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Basic Printmaking ....................

  • Page 33: Basic Printmaking

    Basic Printmaking This section describes how to make prints using the basic functions. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Turn ON the power.
  • Page 34 Basic Printmaking ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (PLATE MAKING) key. When the plate has been made, one test print is automatically made.

  • Page 35: Loading And Replacing Paper

    Loading and Replacing Paper Loading Paper This section describes how to load the printer with paper. You can load approximately 1,300 sheets in this printer. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Open the support tray.

  • Page 36: Adjusting Paper Feed Pressure

    Loading and Replacing Paper Adjusting Paper Feed Pressure Adjust the paper feed pressure if an feeding error occurs when using thick or thin paper. I When no thick paper is fed Adjust the paper feed pressure adjuster lever to “HIGH”. I When two pieces of thin paper are fed Adjust the paper feed pressure adjuster lever to “LOW”.

  • Page 37: Loading Documents

    Loading Documents Positioning the Document The document can be loaded in the “portrait” or “landscape” position. IMPORTANT • A4 and B5-size documents can be loaded in the “portrait” or “landscape” position. • Use the landscape position when enlarging or reducing from standard-size documents to standard-size paper, such as A5 to A4.

  • Page 38: Loading Document On Document Glass Plate

    Loading Documents Loading Document on Document Glass Plate Use the platen glass when copying from books, thick documents, or thin documents. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Gently open the document cover.

  • Page 39: Loading Document In Adf [Available Only When Adf Installed]

    Loading Documents Loading Document in ADF Available only when ADF installed Load documents that consist of a series of sheets to be printed in the ADF. When one or more documents are loaded in the ADF, platemaking and printing are automatically repeated until the document tray is empty. IMPORTANT •...

  • Page 40: Enlargement And Reduction

    Enlargement and Reduction Enlarging/Reducing from Standard-Size Document to Standard-Size Paper You can enlarge or reduce a standard-size document onto standard-size printing paper. The following zoom ratios are available when enlarging or reducing a standard-size document onto standard-size printing paper. I Enlargements You can enlarge a standard-size document onto standard-size paper using the following zoom ratios: G European paper sizes <DP-24SII>...

  • Page 41: 94% Reduction

    Enlargement and Reduction ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (ENLARGEMENT) key or (REDUCTION) key several times to display...
  • Page 42 Enlargement and Reduction ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (SELECT) key to display “ON”. 3.x 94% ○...

  • Page 43: 1%-Step Enlargement And Reduction

    Enlargement and Reduction 1%-Step Enlargement and Reduction You can set a zoom ratio between 50% and 200% in 1% steps. IMPORTANT • Select “1%-Step Enlargement and Reduction” before starting platemaking. • You cannot select “94% Reduction” at the same time as “1%-Step Enlargement and Reduc- tion”.
  • Page 44 Enlargement and Reduction ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press key. The scaling ratio is set, and the 100% lamp goes out. •...

  • Page 45: Selecting Printing Paper Size

    Selecting Printing Paper Size Select a paper size. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (FUNCTION SWITCH) key.
  • Page 46 MEMO...

  • Page 47: Text/Photograph/Text And Photograph Mode

    Text/Photograph/Text and Photograph Mode This function includes three modes for enhancing text and photographic documents. I Text/Photograph/Text and Photograph Mode In this mode, the print quality is adjusted to match the document. Text Text/Photograph Photograph ABCDEFGH ABCDEFGH ABCDEFGHIJKLNO ABCDEFGHIJKLNO ABCDEFGHIJKLNO PQRSTUVWXYZ PQRSTUVWXYZ PQRSTUVWXYZ...
  • Page 48 Text/Photograph/Txt and Photograph Mode ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Proceed with steps 1 to 4 of the sequence described in “Basic Printmaking”...

  • Page 49: Print Output

    Print Output This section describes how to install the print tray and remove printed pages from the print tray. Installing Print Tray ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Remove the print tray.
  • Page 50 Print Output ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Open out the paper stopper. ○...

  • Page 51: Truing Up Printed Pages

    Print Output Truing up Printed Pages Available only when sorter is installed Adjust when the edges of the printed pages are not trued up. Adjusting jump plate Adjust the plate according to the paper size. Ex: Expand the guides fully when using paper with B4 or larger size.
  • Page 52 Chapter Printing With Various Function This chapter describes how to make prints using the various printer functions. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Saving Settings ....................

  • Page 53: Saving Settings

    Saving Settings You can save and retrieve nine sets of settings for platemaking and printing. The settings are stored in memory even when the power is turned OFF. Tips The following settings are saved: • Number of prints (including sets) •...
  • Page 54 Saving Settings ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (FUNCTION SWITCH) key. The settings are saved, and the standard screen appears. 100% sht 1set IMPORTANT...

  • Page 55: Retrieving Settings

    Retrieving Settings Retrieving Settings ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (FUNCTION SWITCH) key. Press (SELECT) key several times to show the screen 5.MEMORYMODE at right.

  • Page 56: Clearing Settings

    Clearing Settings Clearing Settings ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (FUNCTION SWITCH) key several times to show the screen at right.

  • Page 57: Multiple Printing On One Page

    Multiple Printing on One Page This mode allows you to print Multiple copies of the document on one page. I Multiple Function (a a a a a page 58) This mode prints multiple images of the document on one page. 2 images 4 images Document...
  • Page 58 Multiple Printing on One Page ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Proceed with steps 1 to 4 of the sequence described in “Basic Printmaking”...

  • Page 59: 2-In-1 Layout [Available Only When Adf Installed]

    Multiple Printing on One Page 2-in-1 Layout Available only with ADF installed Two-in-one (2-in-1) mode allows you to print two small documents on one page and also easily print for creating booklets that will be saddle stitched. When you use 2-in-1 mode, the layout is as follows: Printout1 Printout2 Documents (even number)
  • Page 60 Multiple Printing on One Page ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (SELECT) key several times to select “2IN1”.

  • Page 61: Book Shadow Eraser Mode

    Book Shadow Eraser Mode I Prints book documents without shadows This mode erases the shadows caused by the book binding when printing an open spread from a book or other folded document. It also erases the shadow around the periphery of the document. Printout With shadow eraser Document...
  • Page 62 Book Shadow Eraser Mode ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (FUNCTION SWITCH) key.

  • Page 63: Adjusting Plate Darkness

    Adjusting Plate Darkness The plate darkness (the level at which black and white are differentiated) can be adjusted in 3 steps. Make the plate more “dark” if the document is light, or “light” if the document is dark. IMPORTANT • Set the “Plate Darkness” before making the plate. •...

  • Page 64: Batch Printing

    Batch Printing You can print the specified number of sets of prints in each set. I Batch Printing (a a a a a page 63) The machine stops after each set of prints. 1st set 2nd set 3rd set 5 copies x 2 sets 3 copies x 4 sets 2 copies x 5 sets Document...
  • Page 65 Batch Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Proceed with steps 1 to 5 of the sequence described in “Basic Printmaking”...
  • Page 66 Batch Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press key. The number of prints is set. 100% sht 0set ○...
  • Page 67 Batch Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (PRINT) key. The print runs starts from the last-entered set, and stops after the first set of printouts.

  • Page 68: Batch Printing (Changing Print Quantity Per Document)

    Batch Printing Batch Printing (changing print quantity per document) You can change the number of prints made from each document. You can separate the number of prints for up to 15 documents. IMPORTANT • Select “Batch Printing” before starting platemaking. ○...
  • Page 69 Batch Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Use the keypad to enter the number of prints. Example: 25 •...
  • Page 70 Batch Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press key. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Repeat steps 2 to 6.

  • Page 71: Dividing Sections With Tape [Available Only With Tape Cluster Device]

    Batch Printing Dividing Sections with Tape-04 Available only with Tape Cluster Device Only the specified number of sets is printed with the specified number of prints taken as one set. Paper tape is inserted when printing of each set is completed. You can enter up to 15 groups of number of prints x number of sets.
  • Page 72 Batch Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Leave end of tape approximately 1 cm out. ○...
  • Page 74 Chapter Miscellaneous Functions This chapter describes miscellaneous functions such as the confidential safeguard function, and the print speed and print position adjustments. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Confidential Safeguard Function ..............

  • Page 75: Confidential Safeguard Function

    Confidential Safeguard Function The confidential safeguard function, which prevents printing unless platemaking has been completed, is a simple means of prohibiting others from printing sensitive documents. IMPORTANT • When the Confidential Safeguard function is ON, printing cannot be performed with (PRINT) or (TEST PRINT) keys.

  • Page 76: Total Counter Display Function

    Total Counter Display Function This function displays the total numbers of prints and plates on the LCD panel. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Check that the machine is not printing.

  • Page 77: Print Speed Adjustment Function

    Print Speed Adjustment Function The printing speed can be selected from among 60 pages per minute, 80 pages per minute and 120 pages per minute. The default setting when the power is turned ON is about 80 pages per minute. Tips •...

  • Page 78: Printing Position Adjustment Function

    Printing Position Adjustment Function After platemaking has finished, you can fine-tune the position of the image (in the horizontal direction) within ±10mm. • You can adjust the printing position while the machine is printing. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press “PRINTING POSITION AD- 1 : 1...

  • Page 79: On-Line Print Function [Available Only With Interface Kit Installed]

    On-Line Print Function Available Only With Interface Kit Installed This function allows you to make prints of documents directly from on-line data from personal computers. IMPORTANT • PC interface kit is required to connect this machine to a personal computer. •...
  • Page 80 Chapter Replacing Consumables This chapter describes how to supply paper, ink pack, and other consumables. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Replacing the Ink Pack ..................

  • Page 81: Replacing The Ink Pack

    Replacing the Ink Pack The message “EXCHANGE INK” is displayed on the LCD panel when the remaining ink is low. Replace the ink pack using the following procedure. EXCHANGE INK IMPORTANT • Only use ink packs designed for this machine. ○...
  • Page 82 Replacing the Ink Pack ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Remove the cap from a new ink pack. Ink pack IMPORTANT •...
  • Page 83 Replacing the Ink Pack ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Close the front cover. Front cover ○...

  • Page 84: Replacing The Master Roll

    Replacing the Master Roll The message “ROLL-MASTER END” is displayed on the LCD panel when the master roll is used up. Replace the master roll using the following procedure. ROLL-MASTER END IMPORTANT • Only use a master roll designed for use in this machine. ○...
  • Page 85 Replacing the Master Roll ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Take out a new master roll from the bag.
  • Page 86 Replacing the Master Roll ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Make sure that the leading edge of the master is protruding from the inner side of the master cover.

  • Page 87: Replacing The Master Ejection Core

    Replacing the Master Ejection Core The message “EXCHANGE EJECT ROLL” is displayed on the LCD panel when the master ejection core is full. Remove the master ejection core using the following procedure: EXCHANGE EJECT ROLL IMPORTANT • Use only a master ejection core designed for use in this machine. ○...
  • Page 88 Replacing the Master Ejection Core ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Holding the edges of the master ejection core, pull out the core and discard it.

  • Page 89: Replacing The Drum Unit

    Replacing the Drum Unit Removing the Drum Unit WARNING • Avoid pressing and damaging the drum surface with fingers etc. It can stain your clothes, and the warp in the drum surface may cause bad prints. • Always place the drum unit on flat and stable surface. Otherwise, the drum surface may be damaged or warped and may cause bad prints.
  • Page 90 Replacing the Drum Unit ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Handle for end Hold the handle on the far end of the drum, and of drum lift the front end of the drum slightly to pull the...

  • Page 91: Installing The Drum Unit

    Replacing the Drum Unit Installing the Drum Unit ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Hold the drum level and place the drum guide roller onto the rail in the machine.
  • Page 92 Replacing the Drum Unit ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Lever Lower the lever. ○...
  • Page 94 Chapter Troubleshooting This chapter describes how to remove paper jams and what to do when error messages are displayed. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Countermeasures to Troubles ................

  • Page 95: Countermeasures To Troubles

    Countermeasures to Troubles Power Does Not Turn ON If the power does not turn ON, check the following. THE MACHINE DOESN'T TURN ON. IS POWER PLUG INSERTED? Insert the power plug securely. IS POWER SWITCH ON? Turn the power switch ON. Please contact your service person.

  • Page 96: Error Messages

    Error Messages Message Countermeasure There is no paper in the feed tray. Load the feed tray with printing paper. SET PRINT PAPER There is no ink. Replace the old ink pack with a new one. (a For details, see page 80, “Replacing the Ink Pack”.) EXCHANGE INK There is no master.
  • Page 97 Error Messages Message Countermeasure A paper jam has occurred in the feed tray. Remove the jammed paper. (a For details, see page 102, “When ‘PAPER LEFT JAM’ is displayed (Feed Tray)”.) PAPER LEFT JAM. A paper jam has occurred on the print tray side. Inspect the print tray side and remove the jammed paper.

  • Page 98: Service Call

    Error Messages Message Countermeasure Cannot print. This message is displayed just after the master setting error or PLEASE plate ejection error occurs. It is also displayed if you (PRINT) key or (TEST PLATE MAKING PRINT) key without making a plate while the confidential safeguard function is activated.

  • Page 99: Supplying Or Changing Paper While Printing

    Supplying or Changing Paper While Printing If Paper Runs Out During Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ If paper runs out during printing, printing stops and the feed tray is lowered automatically.
  • Page 100 Supplying or Changing Paper While Printing IMPORTANT • If the sheet is still in the feed roller ring, pull it out and align it with the stack. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Align the stack to be added and place it on top of the existing stack.

  • Page 101: Changing Paper Selection While Printing

    Supplying or Changing Paper While Printing Changing Paper Selection While Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (STOP) key.
  • Page 102 Supplying or Changing Paper While Printing ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ When the feed tray comes to a stop, reset the paper size.

  • Page 103: Paper Jams

    Paper Jams When “PAPER LEFT JAM” is Displayed (Feed Tray) When a paper jam occurs in the feed tray, the message “PAPER LEFT JAM” is displayed on the LCD. Follow the procedure below to remove the jammed paper. PAPER LEFT JAM. ○...

  • Page 104: When "Paper Right Jam" Is Displayed (Print Tray)

    Paper Jams When “PAPER RIGHT JAM” is Displayed (Print Tray) When a paper jams in the print tray, “PAPER RIGHT JAM” is displayed on the LCD panel. Follow the procedure below to remove the jammed paper. PAPER RIGHT JAM. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press the plate ejection box release lever to open Plate ejection box release lever the master ejection box.

  • Page 105: Paper Adhering To Drum

    Paper Jams ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Close the master ejection box, pressing it until it locks.
  • Page 106 Paper Jams ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Peel off the edge of the paper from the drum. ○...

  • Page 107: When "Mast. Eject Error" Is Displayed

    When “MASTER EJECT MISS” is Displayed When and old master remains on the drum, “MASTER EJECT MISS” is displayed on the LCD panel. Remove it by following the procedure below. MASTER EJECT MISS ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press the plate ejection box release lever to open Plate ejection box release lever the master ejection box.
  • Page 108 When “MASTER EJECT MISS” is Displayed ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Master clamp Lift the lever toward you.
  • Page 109 When “MASTER EJECT MISS ” is Displayed ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Press (STOP) key.

  • Page 110: When "Master Set Miss" Is Displayed

    When “PLATE EJECTION ERROR” is Displayed When “MASTER SET MISS” is Displayed The message “MASTER SET MISS” is displayed on the LCD panel. Remove the master and remake the plate by following the procedure below. MASTER SET MISS ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Scanner unit Slide the scanner unit.
  • Page 111 When “MASTER SET MISS” is Displayed ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Lift out the master roll. ○...
  • Page 112 When “MASTER SET MISS” is Displayed ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Master Push the master set lever.

  • Page 114: Chapter 7 Specifications And Maintenance

    Chapter Specifications and Maintenance This chapter lists the machine specifications and describes maintenance, etc. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Specifications ....................

  • Page 115: Specifications

    Specifications Product name/model No. Duprinter DP-22SII Duprinter DP-22LII Duprinter DP-24SII Model Table top Platemaking method Thermal digital platemaking Platemaking time 21 seconds (A4, same size) Resolution 300 dpi (Main scanning direction) x 600 dpi (Sub scanning direction) Scanning method Fixed document...
  • Page 116 Specifications Product name/model No. Duprinter DP-22SII Duprinter DP-22LII Duprinter DP-24SII Power source 120 VAC model 120VAC 60 Hz, 2.1 A 230 VAC model 230VAC 50 Hz, 1.1 A Size In use: 1270mm (W) x 615mm (D) x 666mm (H) In storage: 695mm (W) x 615mm (D) x 666mm (H) <When ADF is installed>...

  • Page 118: Appendix

    Appendix This section contains an index and quick reference diagrams for basic operations. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Index ........................

  • Page 119: Index

    Document/Printing Paper Specification ..... 28 Multiple printing ............56 drum handle ..............20 drum unit ..........18, 20, 29, 88 Duplo Direct Print System .......... 18 number of prints ........... 33, 75 Enlargement and Reduction ........39 Enlargements .............. 39 On-Line Print Function ..........
  • Page 120 Index Positioning the Machine ..........12 Power Does Not Turn ON .......... 94 power swich ............ 19, 25, 26 “U” groove of holder ..........81 press roller ..............29 Print count ..............33 PRINT key ..............23 Vertical Placement ............36 Print Output ..............

  • Page 121: Quick Operation Guide

    Quick Operation Guide GPlatemaking ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Install the print tray. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Open the supplemental paper tray.

  • Page 122: Turning The Power On

    Quick Operation Guide ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Raise the paper stacker guides and Make the required settings on the paper stopper, and adjust them to...
  • Page 123 MEMO...
  • Page 124 MEMO...
  • Page 125 MEMO...
  • Page 126 DUPLO CORPORATION Duplo building, 1-6, Oyama 4 chome, Sagamihara, Kanagawa 229-1180, Japan TEL: +81-42-775-3602 FAX: +81-42-775-3606 E-mail : Info@duplo.com M7-Y1520 2003.08...

This manual is also suitable for:

Duprinter dp22liiDuprinter dp-24sii

Table of Contents
