Panasonic SA-AK580PH Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: This model's CD Mechanism Unit (CR14C). Please refer to the Original Service Manual
(Order No. MD0805031CE) for this CD Mechanism Unit.

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 4
1.1. General Guidelines---------------------------------------- 4
1.2. Before Use (For PH only)-------------------------------- 4
1.3. Caution For Fuse Replacement------------------------ 4
1.4. Before Repair and Adjustment ------------------------- 5
1.5. Protection Circuitry ---------------------------------------- 5
Model No.
Product Color: (K)...Black Type
PAGE
1.6. Safety Parts Information----------------------------------5
2 Warning --------------------------------------------------------------7
2.2. Precaution of Laser Diode ------------------------------- 8
© Panasonic Corporation 2009. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
CD Stereo System
SA-AK580PH
SA-AK580PN
PSG0905048CE
PAGE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SA-AK580PH

Summary of Contents for Panasonic SA-AK580PH

  • Page 1: Table Of Contents

    1.4. Before Repair and Adjustment ------------------------- 5 2.2. Precaution of Laser Diode ------------------------------- 8 1.5. Protection Circuitry ---------------------------------------- 5 2.3. Service caution based on Legal restrictions --------9 © Panasonic Corporation 2009. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 2 2.4. Handling Precautions for Traverse Unit ------------ 10 10.3. Checking and Repairing of D-Amp P.C.B.--------- 74 3 Service Navigation---------------------------------------------- 12 10.4. Checking and Repairing of SMPS P.C.B. and 3.1. Service Information -------------------------------------- 12 AC Inlet P.C.B.-------------------------------------------- 75 4 Specifications ---------------------------------------------------- 13 11 Voltage &...
  • Page 3 18.1. IC2801 (RFKWMAK580PN): Microprocessor------------------------------------------ 122 18.2. IC6601(C0HBB0000057): IC FL Driver ----------- 124 19 Exploded View and Replacement Parts List --------- 125 19.1. Exploded View and Mechanical Replacement Parts List-------------------------------------------------- 125 19.2. Electrical Replacement Part List-------------------- 130...

  • Page 4: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 5: Before Repair And Adjustment

    1.4. Before Repair and Adjustment Disconnect AC power to discharge unit AC Capacitors as such (C5700, C5701, C5703, C5704, C5705, C5706, C5707) through a 10 Ω, 10 W resistor to ground. Caution: DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices. After repairs are completed, restore power gradually using a variac, to avoid overcurrent.
  • Page 6 Safety Ref. No. Part No. Part Name & Description Remarks FP2901 K5G4013A0001 FUSE PROTECTOR TH5701 D4CAA5R10001 THERMISTOR TH5702 D4CAA2R20001 THERMISTOR TH5860 D4CC11040013 THERMISTOR P5701 K2AA2B000017 AC INLET P5701 K2AB2B000011 AC INLET C5700 F1BAF1020020 1000pF C5701 F0CAF334A087 0.33uF C5703 F0C2H1040001 0.1uF 500V C5703 F0CAF224A085 0.22uF...

  • Page 7: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...

  • Page 8: Precaution Of Laser Diode

    2.2. Precaution of Laser Diode Caution: This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens. Wavelength: 780 nm (CD) Maximum output radiation power from pickup: 100 μW/VDE Laser radiation from the pickup unit is safety level, but be sure the followings: 1.

  • Page 9: Service Caution Based On Legal Restrictions

    2.3. Service caution based on Legal restrictions 2.3.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb).

  • Page 10: Handling Precautions For Traverse Unit

    2.4. Handling Precautions for Traverse Unit The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit. Cautions to Be Taken in Handling the Optical Pickup Unit 2.4.1.
  • Page 11 2.4.2.2. Human body grounding 1. Use the anti-static wrist strap to discharge the static electricity form your body.

  • Page 12: Service Navigation

    3 Service Navigation 3.1. Service Information This service manual contains technical information which will allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service manual.

  • Page 13: Specifications

    Main Unit: SA-AK580PN-K Frequency range Front Speaker: SB-AK780PN-K For PH only 87.50 MHz to 108.00 MHz System: SC-AK580PH-K Main Unit: SA-AK580PH-K (200 kHz step) Front Speaker: SB-AK780PN-K For PN only 87.9 MHz to 107.9 MHz (200 kHz step) 87.5 MHz to 108.0 MHz (100 kHz step) 75 Ω...

  • Page 14: Location Of Controls And Components

    5 Location of Controls and Components 5.1. Main Unit Key Button Operation...

  • Page 15: Remote Control Key Button Operation

    5.2. Remote Control Key Button Operation TUNE MODE This auto off function allows you to turn off To dim the display panel. To mute the sound. the unit in disc or USB mode only after left • Press the button to activate the function. •...

  • Page 16: Disc Information

    5.3. Disc Information...

  • Page 17: Self-Diagnosis And Special Mode Setting

    6 Self-Diagnosis and Special Mode Setting This unit is equipped with features od self-diagnosis & special mode setting for checking the function & reliability. Special Note: Checking of the reliability (ageing) & changer operation must be carry out to ensure good working condition in unit. 6.1.

  • Page 18: Doctor Mode Table

    6.2. Doctor Mode Table Below is the various special modes for checking:- 6.2.1. Doctor Mode Table 1 Item FL Display Key Operation Mode Name Description Front Key Doctor Mode To enter into Doctor In CD Mode: Mode. 1. Press [ ] button on main unit fol- low by [4] and [7] on remote control.
  • Page 19 6.2.2. Doctor Mode Table 2 Item FL Display Key Operation Mode Name Description Front Key Volume Setting To check for the volume Display 1 In Doctor Mode: Check setting of the main unit. 1. Press [7] button on remote control. The volume will be auto- To exit Doctor Mode, press [OK] button on main matically set to its respec-...
  • Page 20 6.2.3. Doctor Mode Table 3 Item FL Display Key Operation Mode Name Description Front Key CR14 Inspection Below is the process: In Doctor Mode: 1. Load TRAY 1 (Move to 1. Press [DISC] button on remote con- PLAY position) trol. 2.
  • Page 21 6.2.4. Doctor Mode Table 4 Item FL Display Key Operation Mode Name Description Front Key CD to USB Recording -Automatically change to CD In Doctor Mode: & Playing Inspection -Set it to VOL 0 1. Press [4] button on remote control. -Preset EQ Set to FLAT USB Formatted When high-speed recording...

  • Page 22: Service Mode Summary Table

    6.3. Service Mode Summary Table Main unit buttons Remote control unit buttons Application Note Service Mode (Refer to the section “6.4.1 Service Mode Table 1” for more information.) Service Mode Error Code History Micro-P Version Display USB Error Code History CD Self Adjustment Result (Refer to the section “6.4.2 Service Mode Table 2”...

  • Page 23: Service Mode Table

    6.4. Service Mode Table 6.4.1. Service Mode Table 1 Below is the various special modes for checking:- Item FL Display Key Operation Mode Name Description Front Key Service Mode To enter into Service In CD Mode: Mode. Press and hold [ ] button on main unit for 2 seconds follow by [ ] on remote control...
  • Page 24 6.4.2. Service Mode Table 2 Item FL Display Key Operation Mode Name Description Front Key CD Self Adjust- To check for CD operation In Service Mode: ment Result (self-adjusment). 1. Press [6] button on remote control. Cold Start To reset to default setting. In Service Mode: 1.

  • Page 25: Reliability Test Mode (Cd Mechanism Unit Cr14C)

    6.5. Reliability Test Mode (CD Mechanism Unit CR14C) Below is the progress flow chart of ageing for the Mechanism unit (CR14C).

  • Page 26: Error Code Table Display

    6.6. Error Code Table Display Self-Diagnosis Function (refer Section “6.4.1” Service Mode Table 1”) provides information on any problems occurring for the unit and its respective components by displaying the error codes. These error code such as U**, H** and F** are stored in memory and held unless it is cleared.
  • Page 27 6.6.2. Error Code Table (For Power Supply)

  • Page 28: Troubleshooting Guide

    7 Troubleshooting Guide 7.1. Jupiter USB...

  • Page 29: Troubleshooting Guide

    7.2. Troubleshooting Guide...

  • Page 31: Troubleshooting Guide For F61 And/Or F76

    7.3. Troubleshooting Guide for F61 and/or F76 This section illustrates the checking procedures when upon detecting the error of “F61” and/or “F76” after power up of the unit. It is for purpose of troubleshooting and checking in SMPS, D-Amp & Main P.C.B. 7.3.1.
  • Page 32 7.3.2. Troubleshooting Guide...
  • Page 33 7.3.3. Part Location 7.3.3.1. SMPS P.C.B. Feedback circuit: -30V Detect: PC5720, D5725 QR5801, QR5802, Temperature Detect: Q5860, Q5681, Q5862 Temperature Detect: TH5860 Feedback Circuit: IC5801, Q5802, D5806 SMPS P.C.B. Fig. 1 SMPS P.C.B.
  • Page 34 7.3.3.2. D-Amp P.C.B. Audio Digital Amp IC: IC5000 Audio Digital Amp IC: IC5400 Muting Circuit Q5601, Q5604 D-Amp P.C.B. Fig. 2 D-Amp P.C.B.
  • Page 35 7.3.3.3. Main P.C.B. Switching Regulator IC: IC2701 Regulator IC: IC2761 Fuse Protector: FP2901 D2906, D2908 & D2909 T2900 D2901 Main P.C.B. Fig. 3 Main P.C.B.

  • Page 36: Service Fixture & Tools

    8 Service Fixture & Tools 8.1. Service Tools and Equipment Prepare service tools before process service position. Service Tools Remarks Main P.C.B. (CN5050) - D-Amp P.C.B. (CN5050) REEX0930 (17P FFC) (RTL) Main P.C.B. (CN2701) - SMPS P.C.B. (CN5802) REXX0680 (11P wire) (RTL) SMPS P.C.B.

  • Page 37: Disassembly And Assembly Instructions

    9 Disassembly and Assembly Instructions “ATTENTION SERVICER” Be careful when disassembling and servicing. Some chassis components may have sharp edges Special Note: 1. This model uses a CD Mechanism Unit (CR14C). In this following section does not contain the necessary assembly and dis- assembly information except the assembly and disassembly of the traverse unit.

  • Page 39: Disassembly Flow Chart

    9.1. Disassembly Flow Chart...

  • Page 40: Main Components And P.c.b. Locations

    9.2. Main Components and P.C.B. Locations...

  • Page 41: Disassembly Of Top Cabinet

    9.3. Disassembly of Top Cabinet Step 1 : Remove 3 screws on each side. Step 4 : Push the Top Cabinet backwards as arrow shown to release the catches. Step 2 : Remove 5 screws. Step 5 : Remove the Top Cabinet. Step 3 : Slightly lift the sides of Top Cabinet outwards as arrow shown.

  • Page 42: Disassembly Of Cd Mechanism Unit (Cr14C)

    9.4. Disassembly of CD Mecha- nism Unit (CR14C) • Follow (Step 1) to (Step 5) of Item 9.3 Step 4 : Release claws outwards on both sides. Step 1: Remove 1 screw. Step 2 : Detach 25P FFC at the connector (CN2801) on Main P.C.B.

  • Page 43: Disassembly Of Rear Panel

    9.5. Disassembly of Rear Panel • Follow (Step 1) to (Step 5) of Item 9.3 Step 7 : Remove 2 screws. Step 8 : Remove the CD Mechanism Unit (CR14C). Step 1 : Detach 2P wire at the connector (CN2810) on Main P.C.B..
  • Page 44 • For PN only Step 2 : Remove 9 screws. Step 3 : Release 2 catches from the each side of the Rear Panel. Step 4 : Slightly lift up the CD Mechanism Unit (CR14C) to release from the 2 locators. Step 5 : Detach Voltage Selector from Rear Panel as arrow shown.

  • Page 45: Disassembly Of Fan Unit

    9.6. Disassembly of Fan Unit • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) of Item 9.5 Step 1 : Release fan wire from the holder. Step 4 : Slightly lift up the CD Mechanism Unit (CR14C) to release from the 2 locators.

  • Page 46: Disassembly Of Front Panel Assembly

    9.7. Disassembly of Front Panel Assembly • Follow (Step 1) to (Step 5) of Item 9.3 Step 1 : Detach 30P FFC at the connector (CN3200) on Main P.C.B. Step 2 : Detach 27P FFC at the connector (CN2806) on Main P.C.B.
  • Page 47 Step 5 : Release claws on both sides. Step 6 : Release catches at both side. Caution : During assembling, ensure both the claws and Step 7 : Release tabs at the bottom. catches are fully catched. Caution : Do not exert strong force when releasing the tabs.

  • Page 48: Disassembly Of Mic P.c.b

    9.8. Disassembly of Mic P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.7 Caution : Remember to tie the 5P wire with tie wrap to the Front Panel as diagram shown. Step 1 : Remove the Mic Volume Knob.

  • Page 49: Disassembly Of Panel P.c.b

    9.9. Disassembly of Panel P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.7 • Follow (Step 1) to (Step 5) of Item 9.8 Step 1 : Remove the Volume Knob. Step 2 : Remove the Track Knob.

  • Page 50: Disassembly Of Dynamic Bass Knob

    9.10. Disassembly of Dynamic Bass Knob & Dynamic Bass Button Unit • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.7 • Follow (Step 1) to (Step 5) of Item 9.8 •...
  • Page 51 9.10.2. Disassembly of Dynamic Bass But- ton Unit Step 3 : Release 3 catches. Step 4 : Remove the Dynamic Bass Knob. Step 1 : Release 4 catches. Caution 1 : Do not misplace the Volume Gear. Caution 2 : Volume gear to align to Volume Knob & engage Step 2 : Release 2 catches.

  • Page 52: Disassembly Of Memory P.c.b

    9.11. Disassembly of Memory P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.7 • Follow (Step 1) to (Step 5) of Item 9.8 • Follow (Step 1) to (Step 8) of Item 9.9 Step 3 : Remove the Dynamic Bass Button Unit.

  • Page 53: Disassembly Of Mport/Headphone P.c.b

    9.12. Disassembly of MPort/Head- phone P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.7 Step 3 : Release 4 catches. Step 1 : Remove 1 screw. Step 2 : Release 2 catches. Step 3 : Remove the MPort/Headphone P.C.B..

  • Page 54: Disassembly Of Cd Servo P.c.b

    9.13. Disassembly Servo P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.4 Step 3 : Remove 3 screws. Step 1 : Upset the CD Mechanism Unit (CR14C). Step 4 : Flip over the CD Servo P.C.B.. Step 5 : Detach the 16P FFC at connector (CN7001) at CD Servo P.C.B..

  • Page 55: Disassembly Of D-Amp P.c.b

    9.14. Disassembly of D-Amp P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 Step 4 : Remove 2 screws. Step 1 : Remove 4 screws. Step 5 : Lift up the D-Amp P.C.B. together with inner chassis Step 2 : Detach 17P FFC at the connector (CN5050) on D-Amp assembly as arrow shown.
  • Page 56 Step 6 : Place the D-Amp P.C.B. on a support block. Caution: During assembling, ensure the D-Amp P.C.B. is Step 7 : Remove 3 screws. seated properly on the locator of the Inner Chassis. Step 8 : Lift up to remove the D-Amp P.C.B..

  • Page 57: Replacement Of Audio Digital Amp Ic (Ic5400)

    9.15. Replacement of Audio Digital 9.15.2. Assembly of Audio Digital Amp IC (IC5400) Amp IC (IC5400) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 8) of Item 9.14 9.15.1.

  • Page 58: Replacement Of Audio Digital Amp Ic (Ic5000)

    9.16. Replacement of Audio Digital 9.16.2. Assembly of Audio Digital Amp IC (IC5000) Amp IC (IC5000) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 8) of Item 9.14 9.16.1.

  • Page 59: Disassembly Of Main P.c.b

    9.17. Disassembly of Main P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 4) of Item 9.7 • Follow (Step 1) to (Step 5) of Item 9.14 Step 4 : Remove 2 screws on at bottom chassis.

  • Page 60: Disassembly Of Smps P.c.b

    9.18. Disassembly of SMPS P.C.B. (This illustration shows is for PN only) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 5) of Item 9.14 Step 4 : Flip the SMPS P.C.B.

  • Page 61: Replacement Of Switching Regulator Ic (Ic5701)

    9.19. Replacement of Switching Reg- 9.19.2. Assembly of Switching Regulator IC (IC5701) ulator IC (IC5701) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 5) of Item 9.14 •...

  • Page 62: Replacement Of Rectifier Diode (D5702)

    9.20. Replacement of Rectifier Diode (D5702) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 5) of Item 9.14 • Follow (Step 1) to (Step 4) of Item 9.18 9.20.1.
  • Page 63 9.20.2. Assembly Rectifier Diode (D5702) Step 3 : Remove 1 screw. Step 4 : Remove the Heatsink Unit B as arrow shown. Step 5 : Remove 1 screw. Step 1 : Apply grease to the Heatsink Unit B. Step 6 : Remove the Rectifier Diode (D5702) from the Heatsink Step 2 : Screw the Rectifier Diode (D5702) to the Heatsink Unit Unit B.

  • Page 64: Replacement Of Regulator Diode (D5801)

    9.21. Replacement of Regulator 9.21.2. Assembly Regulator Diode (D5801) Diode (D5801) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 5) of Item 9.14 •...

  • Page 65: Replacement Of Regulator Diode (D5802)

    9.22. Replacement of Regulator 9.22.2. Assembly Regulator Diode (D5802) Diode (D5802) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 5) of Item 9.14 •...

  • Page 66: Replacement Of Regulator Diode (D5803)

    9.23. Replacement of Regulator 9.23.2. Assembly of Regulator Diode (D5803) Diode (D5803) • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 6) of Item 9.4 • Follow (Step 1) to (Step 5) of Item 9.14 •...

  • Page 67: Disassembly Of Ac Inlet P.c.b

    9.24. Disassembly of AC Inlet P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 Step 4 : Remove 2 screws on AC Inlet P.C.B.. Step 5 : Lift up AC inlet P.C.B. from bottom chassis. Caution: During assembling, ensure the AC Inlet P.C.B. is seated properly at the locator, screw 2 screws at AC Inlet P.C.B..

  • Page 68: Disassembly Of Jupiter P.c.b

    9.25. Disassembly of Jupiter P.C.B. • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.7 Step 1 : Remove 3 screws. Step 2 : Remove the Jupiter Unit. Step 3 : Release 2 catches. Step 4 : Slightly left up the Jupiter Cover to release from 2 loca- tors.

  • Page 69: Disassembly Of Voltage Selector P.c.b. (For Ph Only)

    9.26. Disassembly of Voltage Selec- tor P.C.B. (For PH only) • Follow (Step 1) to (Step 5) of Item 9.3 Step 3 : Desolder blue wire pin & white wire pin on the Voltage Selector P.C.B.. Step 1: Remove 1 screw. Step 4 : Remove the Voltage Selector P.C.B..

  • Page 70: Replacement Of Traverse Unit Assembly

    9.27. Replacement of Traverse Unit Assembly 9.27.1. Disassembly Traverse Unit Assembly Step 2 : Detach the FFC wires from the adhesive area. Caution: Disassembly of Traverse Unit Assembly in play position. Step 3 : Remove the Traverse Unit Assembly as arrows shown. Step 1 : Release the catch and push the guide as arrows.
  • Page 71 9.27.2. Assembly of Traverse Unit Assem- Step 4 : Release the catch and push the guide as arrows shown to close both grooves. Step 1 : Slot the Traverse Unit Assembly into the guides as arrow shown. Caution: Ensure the bosses fix exactly onto the guides. Step 2 : Place down the Traverse Unit Assembly.

  • Page 72: Disassembly Of Cd Lid

    9.28. Disassembly of CD Lid • Follow (Step 1) to (Step 5) of Item 9.3 • Follow (Step 1) to (Step 8) of Item 9.7 Step 1: Remove the spring as arrow shown in order of sequences (1) to (3). Caution: During assembling, please ensure that the spring is assembly at right position.

  • Page 73: Service Position

    10 Service Position Note: For description of the disassembly procedures, see the Section 9. 10.1. Checking and Repairing of 10.2. Checking and Repairing of Main P.C.B. Panel P.C.B., Mic P.C.B., Jupiter P.C.B. and MPort/Headphone Step 1 : Remove Top Cabinet. P.C.B.

  • Page 74: Checking And Repairing Of D-Amp P.c.b

    10.3. Checking and Repairing of D- Amp P.C.B. Step 1 : Remove Top Cabinet. Step 2 : Remove CD Mechanism Unit (CR14C). Step 3 : Remove D-Amp P.C.B.. Step 8 : Connect 10P FFC at the connector (CN2807) on Main P.C.B.

  • Page 75: Checking And Repairing Of Smps P.c.b. And Ac Inlet P.c.b

    10.4. Checking and Repairing of SMPS P.C.B. and AC Inlet P.C.B. Step 1 : Remove Top Cabinet. Step 2 : Remove CD Mechanism Unit (CR14C). Step 3 : Remove D-Amp P.C.B.. Step 4 : Remove AC Inlet P.C.B.. Step 5 : Remove Voltage Selector P.C.B.. Step 8 : Position SMPS P.C.B., AC Inlet P.C.B.

  • Page 76: Voltage & Waveform Chart

    STANDBY Ref No. IC7001 MODE CD PLAY STANDBY Ref No. IC7001 MODE CD PLAY STANDBY Ref No. IC7002 MODE CD PLAY STANDBY Ref No. IC7002 MODE CD PLAY STANDBY Ref No. Q7601 MODE CD PLAY STANDBY SA-AK580PH/PN CD SERVO P.C.B.

  • Page 77: Main P.c.b. (1/3)

    CD PLAY STANDBY Ref No. IC2801 MODE CD PLAY STANDBY Ref No. IC2801 MODE CD PLAY STANDBY Ref No. IC2801 MODE CD PLAY STANDBY Ref No. IC2801 MODE CD PLAY STANDBY Ref No. IC2801 MODE CD PLAY STANDBY SA-AK580PH/PN MAIN P.C.B.

  • Page 78: Main P.c.b. (2/3)

    Q2510 MODE CD PLAY -7.5 -7.5 STANDBY Ref No. Q2320 Q2501 Q2708 Q2711 Q2735 MODE CD PLAY -9.0 -0.6 10.2 STANDBY Ref No. Q2743 Q2745 Q2751 Q2761 Q2771 MODE CD PLAY 16.8 10.0 -9.0 -12.0 -10.0 STANDBY SA-AK580PH/PN MAIN P.C.B.

  • Page 79: Main P.c.b. (3/3)

    Q3116 Q3301 MODE CD PLAY STANDBY Ref No. QR2317 MODE CD PLAY -7.5 STANDBY SA-AK580PH/PN MAIN P.C.B. 11.5. Panel P.C.B. Ref No. IC6601 MODE -14.5 -16.8 -22.2 -22.2 -22.2 -22.2 -20.2 CD PLAY STANDBY Ref No. IC6601 MODE CD PLAY -16.8 -22.2 -22.2 -20.4 -16.8 -20.2 -20.3 -24.0 -20.2...

  • Page 80: D-Amp P.c.b

    29.0 -29.0 -20.6 29.3 -29.3 -19.2 -29.3 -0.1 29.3 -29.0 -29.0 29.0 Ref No. IC5400 MODE CD PLAY STANDBY Ref No. IC5500 MODE CD PLAY STANDBY Ref No. Q5101 Q5102 Q5601 Q5603 Q5604 MODE CD PLAY STANDBY SA-AK580PH/PN D-AMP P.C.B.

  • Page 81: Jupiter P.c.b. (1/2)

    CD PLAY STANDBY Ref No. IC751 MODE CD PLAY STANDBY Ref No. IC751 MODE CD PLAY STANDBY Ref No. IC751 MODE CD PLAY STANDBY Ref No. IC801 MODE CD PLAY STANDBY Ref No. IC801 MODE CD PLAY STANDBY SA-AK580PH/PN JUPITER P.C.B.

  • Page 82: Jupiter P.c.b. (2/2)

    CD PLAY STANDBY Ref No. IC801 MODE CD PLAY STANDBY Ref No. IC801 MODE CD PLAY STANDBY Ref No. IC801 MODE CD PLAY STANDBY Ref No. IC802 MODE CD PLAY STANDBY Ref No. Q801 MODE CD PLAY STANDBY SA-AK580PH/PN JUPITER P.C.B.

  • Page 83: Mic P.c.b

    11.9. Mic P.C.B. Ref No. IC1000 MODE CD PLAY STANDBY SA-AK580PH/PN MIC P.C.B. 11.10. SMPS P.C.B. Ref No. IC5701 MODE CD PLAY 162.0 19.3 STANDBY 19.3 162.0 Ref No. IC5799 MODE CD PLAY 20.3 162.2 STANDBY 20.3 163.0 Ref No.

  • Page 84: Waveform Table (1/3)

    11.11. Waveform Table (1/3) WF No. IC551 - 1,2 WF No. IC551 - 9 WF No. IC552 - 3 WF No. IC552 - 9,10 (RECORD) (RECORD) (PLAY) (PLAY) 108mVp-p (50nsec.div) 3.92Vp-p (500nsec.div) 3.8Vp-p (500nsec.div) 3.36Vp-p (500usec.div) WF No. IC801 - 121 WF No.

  • Page 85: Waveform Table (2/3)

    11.12. Waveform Table (2/3) WF No. IC2121 - 1,7 WF No. IC2121 - 2,3 WF No. IC2804 - 5,6 WF No. IC2810 - 1,7 (PLAY) (PLAY) (PLAY) (PLAY) 109mVp-p (250 nsec.div) 104mVp-p (250nsec.div) 2.88Vp-p (250usec.div) 1.32Vp-p (250usec.div) WF No. IC5000 - 10,14 WF No.

  • Page 86: Waveform Table (3/3)

    11.13. Waveform Table (3/3) WF No. IC7001 - 14 (PLAY) 1.2Vp-p (25nsec.div)

  • Page 87: Illustration Of Ics, Transistor And Diode

    12 Illustration of ICs, Transistor and Diode C0FBBY000027 (16P) C3ABQG000105 (54P) C0CAAKG00046 C0HBB0000057 (44P) BA5948FPE2 C0FBAK000026 (16P) C1AB00003130 (14P) C1AB00003093 (52P) C0JBAB000902 (14P) MN2WS0042AA (216P) C0ABBB000230 (8P) MN6627553PA (80P) RFKWFAK580PN (48P) RFKWMAK580PN (100P) RFKWEAK580PN (8P) C5HACYY00005 (7P) C0AABB000125 (8P) C0DABFC00002 (3P) MIP4110MSSCF C0DBZYY00293 (5P) C1BA00000492 (23P)

  • Page 88: Block Diagram

    TO MAIN (2/2) COIL SHIFT CN7001 CN7002 CN2801 M7301* CN7002 [14]TRVP CN2801 TRAVERSE [CH2] LEVEL SHIFT OPTICAL PICKUP P.C.B MOTOR M7302* [13]SPOUT SPINDLE [CH1] LEVEL SHIFT MOTOR MUTE [12]PC [CH1] MUTE [CH2] CD SERVO P.C.B SA-AK580PH/PN CD SERVO BLOCK DIAGRAM...

  • Page 89: Jupiter Block Diagram

    TO MAIN (2/2) IC551 IC552 C0FBAK000026 C0FBBY000027 Q801 D803 ADC IC DAC IC CN601 CN3200 LED DRIVE IC503 C0DBZHE00026 POWER SUPPLY IC USB5V TO MAIN (1/2) TO MAIN (1/2) TO MAIN (1/2) TO MAIN (1/2) TO JTAG SA-AK580PH/PN JUPITER BLOCK DIAGRAM...

  • Page 90: Main(1/2) Block Diagram

    D2946 Q2735 DC DETECT DC DETECT DC_DET REGULATOR SWITCH SWITCH +VCC SWITCH FROM PANEL Q2708 Q2761 POWER -9V POWER CONTROL SUPPLY TO SMPS SWITCH SWITCH TO JUPITER TO PANEL D2503 Q2501 LM_1 LEVEL METER CONTROL SWTICH SA-AK580PH/PN MAIN(1/2) BLOCK DIAGRAM...

  • Page 91: Main(2/2) Block Diagram

    SUBW_LVL2 SUBW_LVL1 SUBW_LVL1 MUTE_A MUTE_A X2602 X2611 Q2745 SWITCH Q2812 IC2741 SWITCH C0DBGYY00089 VOLTAGE REGULATOR IC Q2743 SWITCH W_DET CTRL W_MUTE TO PANEL TO JUPITER TO SMPS FROM DEBUG TO MIC TO MPORT/ TO JUPITER HEADPHONE SA-AK580PH/PN MAIN(2/2) BLOCK DIAGRAM...

  • Page 92: Panel / Mport/Headphone / Mic / Memory Block Diagram

    CONTROL TO MAIN (2/2) SENSOR Q6511, D6511 Q6512 D6512 LED DRIVE LED_SUPPLY MPORT/HEADPHONE CIRCUIT JK6810 MUSIC PORT VR6882 TRACK JOG TO MAIN (1/2) TO MAIN (2/2) JK6800 HEADPHONE M.PORT/HEADPHONE P.C.B. SA-AK580PH/PN PANEL / MPORT/HEADPHONE / MIC / MEMORY BLOCK DIAGRAM...

  • Page 93: D-Amp Block Diagram

    IN1+ RIGHT SPEAKER OUT2 IN1- IN2+ VDDA1 IN2- VDDA2 VSSA1 SURROUND LEFT SPEAKER MODE VSSA2 IC5500 C0JBAB000902 HEX INVERTER (CLOCK GENERATOR) TO MAIN (2/2) X5500 X5501 TO SMPS TO SMPS Q5101,Q5102 TO MAIN (2/2) DC DETECT SA-AK580PH/PN D-AMP BLOCK DIAGRAM...

  • Page 94: Smps / Ac Inlet / Voltage Selector Block Diagram

    AC INLET P.C.B. SWITCHING VOLTAGE SELECTOR CIRCUIT S5701 WHITE WIRE VOLTAGE IC5899 BLUE WIRE C0DAEMZ00001 SELECTOR SHUNT REGULATOR VOLTAGE SELECTOR P.C.B. PC5799 FEEDBACK IC5799 MIP4110MSSCF SWITCHING REGULATOR PC5702 SYNC SWITCH SA-AK580PH/PN SMPS / AC INLET / VOLTAGE SELECTOR BLOCK DIAGRAM...

  • Page 95: Wiring Connection Diagram

    14 Wiring Connection Diagram CN7001 CD SERVO P.C.B. CN7002 VR6882 (SOLDER SIDE) PANEL P.C.B. 16 15 (SOLDER SIDE) TO OPTICAL PICKUP UNIT D-AMP P.C.B. (SOLDER SIDE) VR6500 CN5500 CN6001 JK5001 SPEAKERS VR6630 1 2 3 CN5050 CN6602 CN601 VOLUME TRACK BASS CONTROL SENSOR CN503...

  • Page 96: Schematic Diagram Notes

    15 Schematic Diagram Notes • Voltage and signal line : +B signal line • This schematic diagram may be modified at any time : -B signal line with the development of new technology. : CD Audio input signal line Notes: : AUX/MUSIC PORT/MIC/Audio input sig- nal line S5701:...

  • Page 97: Schematic Diagram

    R7349 AVSS2-2 DQSY C7335 R7329 R7328 IC7002 C7334 C7352 BA5948FPE2 C7339 10V220 0.018 0.018 4 CH DRIVE IC C7154 C7155 R7323 R7331 6.8K W7014 M7301* R7325 R7315 TRV MOTOR R7335 3.3K M7302* SPL MOTOR R7332 +7.5V SA-AK580PH/PN CD SERVO CIRCUIT...

  • Page 98: Main Circuit (1/6)

    C2602 100P H2B100500004 R2744 C2743 C2742 HP_R SWITCH 4.7K 0.01 HP_R DIAGRAM - 10 R2605 AGND HP_GND R2745 R2606 D2812 C2813 HP_L C2812 HP_L B0ACCK000005 50V3.3 Q2745 B1GBCFLL0037 TO MAIN SWITCH SECTION (4/6) TO MAIN SECTION (2/6) SA-AK580PH/PN MAIN CIRCUIT...

  • Page 99: Main Circuit (2/6)

    LEVEL METER LM_1 R2123 OP-AMP CONTROL SWITCH R2502 R2504 R2505 C2505 C2507 R2510 C2509 16V10 0.22 10V33 R2125 C2123 C2136 C2140 TO MAIN R2126 R2128 SECTION (3/6) R2124 C2130 R2134 R2138 50V1 R2143 TO MAIN SECTION (5/6) SA-AK580PH/PN MAIN CIRCUIT...

  • Page 100: Main Circuit (3/6)

    B0EAKM000117 B0EAKM000117 IC2761 +7.5V C0CAAKG00046 OUT GND VOLTAGE REGULATOR R2733 FAN2 DC18V R2735 C2738 C2735 C2737 C2734 C2731 C2732 C2733 0.01 10V33 16V47 0.01 16V47 0.01 25V1000 MGND GND2 TO MAIN SECTION (2/6) TO MAIN SECTION (6/6) SA-AK580PH/PN MAIN CIRCUIT...

  • Page 101: Main Circuit (4/6)

    C2900 R2950 G4D1A0000117 5.6K 50V47 FP2901 R2914 C2913 50V47 SWITCHING 0.4A TRANSFORMER K5G4013A0001 D2903 B0EAMM000057 Q2900 CHASIS GND B1BABK000001 CHASIS SCREW B D2901 B0BC035A0007 PSAVE CONTROL SWITCH R2902 C2802 3900P C2005 C2912 16V100 D2906 GND1 B0JAME000114 FL-GND SA-AK580PH/PN MAIN CIRCUIT...

  • Page 102: Main Circuit (5/6)

    C2358 C2357 1000P 1000P R2365 100K R2358 R2354 R2357 R2353 C2365 R2448 25V4.7 R2363 R2359 HP_L 5.6K R2361 5.6K R2360 5.6K TO MAIN SECTION (6/6) Q2510 R2362 5.6K B1GFGCAA0001 TO MAIN R2364 MUTING SWITCH SECTION (4/6) HP_R SA-AK580PH/PN MAIN CIRCUIT...

  • Page 103: Main Circuit (6/6)

    C2753 16V100 D2753 0.01 POWER CONTROL SWITCH MAZ8100G0L AGND Q2708 C2763 C2764 C2768 0.01 16V100 0.01 R2762 C2766 C2765 R2765 C2767 C2762 0.01 16V10 2.7K 16V33 0.01 Q2761 TO MAIN B1BCCG000002 SECTION (5/6) -9V POWER SUPPLY SWITCH SA-AK580PH/PN MAIN CIRCUIT...

  • Page 104: Panel Circuit (1/2)

    MANUAL EQ + 3 2 1 VR6500 S6301 EVEKE2F3524B MANUAL EQ VOLUME JOG S6300 MANUAL EQ - R6884 C6633 C6634 R6882 100P 100P TO PANEL SECTION (2/2) 3 2 1 VR6630 VR6882 K9AA012Y0003 K9AA012Y0002 BASS CONTROL JOG TRACK JOG SA-AK580PH/PN PANEL CIRCUIT...

  • Page 105: Panel Circuit (2/2)

    B3AAA0001031 Q6512 CN6602 B1GBCFJN0033 2GB_LED MEMORY CIRCUIT LED DRIVE R6511 LVL0 2.2K (H6603*) D6511 LVL1 R6516 B3AAA0001031 IN SCHEMATIC LVL2 DIAGRAM - 10 LED_SUPPLY Q6511 B1GBCFJN0033 C6512 1000P LED DRIVE R6608 R6607 LED_DIMMER TO PANEL SECTION (1/2) SA-AK580PH/PN PANEL CIRCUIT...

  • Page 106: Memory / Mport/Headphone / Mic Circuit

    AGND MAIN CIRCUIT (CN2813) C1113 MIC_SW C1121 C1110 IN SCHEMATIC 2200P 50V1 DIAGRAM - 2 DGND C1107 IC1000 50V2.2 C1AB00003130 MIC AMP JK1100 C1114 0.01 C1111 R1103 L1201 50V0.1 J0JBC0000019 C1109 R1104 1000P SA-AK580PH/PN MEMORY / MPORT/HEADPHONE / MIC CIRCUIT...

  • Page 107: D-Amp Circuit (1/2)

    1.2K MODE2 R5113 120K SL_+ FL_- FR_+ R5020 120K R5019 FL_+ Q5604 Q5102 R5602 B1ABCF000176 B1ABCF000176 MOD_DA DC DETECT SWITCH Q5101 Q5601 B1ABCF000176 B1ABCF000176 MUTE_F DC DETECT SWITCH R5609 AGND FAN_GND K5251 K5253 TO D-AMP SECTION (2/2) SA-AK580PH/PN D-AMP CIRCUIT...

  • Page 108: D-Amp Circuit (2/2)

    AGND IN+_SL SURROUND L AGND MAIN CIRCUIT K5302 IN+_SR (CN5050) SURROUND R IN SCHEMATIC REAR L/AGND DIAGRAM - 3 CENTER MUTE_S MUTE S_C (MODE 1) MUTE_F MUTE F_SW (MODE 2) FHOP FHOP ECO/FAN DC_DET DC_DET MOD_DA MOD_DA SA-AK580PH/PN D-AMP CIRCUIT...

  • Page 109: Jupiter Circuit (1/4)

    R893 DGND R879 R894 C513 RX841 EXB2HV100JV IC503 5 OUT C0DBZHE00026 POWER SUPPLY IC 4 #OC C514 C515 6.3V10 R525 R807 D803 R527 B3AAB0000322 R526 Q801 B1GBCFGN0016 LED DRIVE TO JUPITER SECTION (2/4) TO JUPITER SECTION (3/4) SA-AK580PH/PN JUPITER CIRCUIT...

  • Page 110: Jupiter Circuit (2/4)

    DAGND C562 6.3V10 RSTN VCOM XTRST GPIO2 C563 6.3V10 XTRST R558 SMUTE AOUTL LSI+3.3V R560 C564 6.3V10 R557 ACKS AOUTR R561 TO JTAG DIF0 DIF1 IC552 C0FBBY000027 R704 R602 TO JUPITER SECTION (1/4) TO JUPITER SECTION (4/4) SA-AK580PH/PN JUPITER CIRCUIT...

  • Page 111: Jupiter Circuit (3/4)

    0.01 [56] FLTR1 [107] BCKIN SDRD12 VDD3 [57] AVSS1 [108] SRDATA R895 SRDAT2 DQ14 SDRD13 SRDAT2 SRDAT1 DQ15 R873 SDRD14 SRDAT1 BLKCK SDRD15 BLKCK RX808 VSS0 EXB2HV100JV C807 0.01 VDD3 56 57 C756 0.01 LSI+1.2V C757 0.01 SA-AK580PH/PN JUPITER CIRCUIT...

  • Page 112: Jupiter Circuit (4/4)

    D1H84734A024 IC802 C0DBZYY00293 R813 C816 C817 HIGH SPEED LDO REGULATOR C811 C850 R812 SRDAT0_1 6.3V47 R814 R828 SRDAT0 0.01 6.8K VOUT LRCK_1 LRCK C808 R827 C809 6.3V47 D804 B0JCMD000022 D802 B0JCMD000022 R829 BCLK RX820 RX826 D1H81004A024 D1H81004A024 SA-AK580PH/PN JUPITER CIRCUIT...

  • Page 113: Smps Circuit (1/2)

    MA2J1110GL FOR PN ONLY IC5801 R5726 FOR PH ONLY C0DABFC00002 FEED BACK SHUNT REGULATOR R5727...PN C5700 F1BAF1020020 1000P R5750 Q5802 PC5701 B1ABCF000176 B3PBA0000402 FEED BACK CONTROL -30V_SENSE ZJ5803 D5806 MAZ8075GML SYS6V FEED BACK QR5810 PCONT B1GBCFLL0037 SA-AK580PH/PN SMPS CIRCUIT INVERTER...

  • Page 114: Smps Circuit (2/2)

    FOR PH ONLY C5798 FOR PH ONLY 50V56 SYS6V C5712 D5896 400V470...PH B0EAMM000057 200V820...PN D5797 MA2J7280GL R5786 R5795 200K IC5899 C0DAEMZ00001 C5794 C5790 SHUNT REGULATOR 2200P R5796 D5793 2.2K B0HAMP000094 R5797 4.7K C5791 50V2.2 IC5799 MIP4110MSSCF SWITCHING REGULATOR SA-AK580PH/PN SMPS CIRCUIT...

  • Page 115: Ac Inlet / Voltage Selector Circuit

    F0CAF334A087 IN SCHEMATIC 220V ~ 240V 0.33 DIAGRAM - 18 50Hz / 60Hz...PH 120V 60Hz...PN DZ5701 TH5702...PH ERZV10V511CS D4CAA2R20001 C5706...PH C5707...PH F1BAF1020020 C5704 C5705 F1BAF1020020 1000P F1BAF1020020 F1BAF1020020 1000P 1000P 1000P ZJ5702...PH ZJ5701 SA-AK580PH/PN AC INLET / VOLTAGE SELECTOR CIRCUIT...

  • Page 116: Printed Circuit Board

    17 Printed Circuit Board 17.1. CD Servo / Jupiter P.C.B. JUPITER P.C.B. (RFKBX0750B) CD SERVO P.C.B. (REPX0739A) RX841 TP38 RL2* TP16 RL1* C7227 M7301* R876 R849 TP19 X802 R801 R655 RX656 (TRV MOTOR) R807 R843 R654 R7212 C836 C515 R7216 C7216 C852 R844...

  • Page 117: Main P.c.b

    17.2. Main P.C.B. MAIN P.C.B. (REPX0735D...PN) (REPX0735F...PH) AUX IN Z3601* W134 (TUNER PACK) W217 R2305 C2313 K2400 W135 C2308 R2303 C2196 R2304 C2092 C2307 D2947 C2192 C2194 R2302 C2306 C2083 C2091 C2305 C2190 R2184 C2316 C2312 Q2949 R2301 C2304 C2188 C2303 W136 R2314...

  • Page 118: Panel / Memory / Mport/Headphone / Mic P.c.b

    17.3. Panel / Memory / MPort/Headphone / Mic P.C.B. PANEL P.C.B. (REPX0749C) MEMORY P.C.B. (REPX0749C) S6200 S6100 (OPEN/CLOSE) H6603* (POWER) D6412 0635AC 0635AC S6201 (CHANGE) FL6601 W6661 R6608 Q6600 R6600 W6669 MPORT/ HEADPHONE P.C.B. D6605 D6604 (REPX0749C) IC6601 C6611 R6620 K6003 CN6807 R6619...

  • Page 119: D-Amp P.c.b

    17.4. D-Amp P.C.B. D-AMP P.C.B. (REPX0727C) W5048 D5501 R5506 C5553 R5507 R5023 R5504 X5501 X5500 C5557 C5550 C5558 C5559 W5036 D5503 R5505 R5515 W5780 IC5500 W5033 R5513 K5401 C5117 C5000 W5044 W5032 W5004 C5001 R5402 R5405 R5005 R5004 C5007 C5404 HEATSINK C5006 C5406...

  • Page 120: Smps / Ac Inlet / Voltage Selector P.c.b. (For Ph)

    17.5. SMPS / AC Inlet / Voltage Selector P.C.B. (For PH) SMPS P.C.B. (REPX0714K...PH) R5809 R5807 0562W-1 W5806 R5820 R5821 W5803 0562W-1 PC5720 R5730 D5725 Q5862 QR5810 W5807 Q5860 W5804 R5728 R5862 W5801 R5824 Q5861 C5816 R5825 CN5802 CAUTION R5863 R5864 PC5701 Q5803...

  • Page 121: Smps/ Ac Inlet P.c.b. (For Pn)

    17.6. SMPS/ AC Inlet P.C.B. (For PN) SMPS P.C.B. (REPX0714J...PN) R5809 R5807 R5820 R5821 W5803 0562T-1 0562T-1 W5806 PC5720 R5730 Q5862 D5725 QR5810 W5807 Q5860 W5804 R5728 R5862 Q5861 W5801 R5824 C5816 R5825 CN5802 CAUTION R5863 R5864 PC5701 Q5803 RISK OF ELECTRIC SHOCK AC VOLTAGE LINE.

  • Page 122: Terminal Function Of Ics

    18 Terminal Function of ICs 18.1. IC2801 (RFKWMAK580PN): IC Microprocessor Pin Name Fucntions Pin Name Fucntions ASP_CLK O ASP commiunication line DCdet1 Detect of DAMP faulty SD_CMD O Jupiter and CD communication (F61) UART(TX) DCdet2 Detect of Power Supply & SD_STAT Jupiter and CD communication SMPS faulty...
  • Page 123 Pin Name Fucntions Vol jog AD To detect vol jog pulses for vol- ume control Key3 AD manual EQ/ CD/ FM-AM/ Mport- /Memory/USB button detect Key2 AD tray Open_close/ change/CD1/ CD2/CD/3/CD4/CD5/Stop but- ton detect Key1 AD Power/USB Rec/Memory rec/ Subwoofer/ Dbass button detect 100 VREF+ - 3.3V supply...

  • Page 124: Ic6601(C0Hbb0000057): Ic Fl Driver

    18.2. IC6601(C0HBB0000057): IC FL Driver Terminal Name Function O No Connection No Connection No Connection No Connection Oscillator Input No Connection Data Input Clock Input Serial Interface Strobe Key Data Input 1 (No Connec- tion) Key Data Input 2 (No Connec- tion) Power Supply (+5V) O Segment Output 18...

  • Page 125: Exploded View And Replacement Parts List

    19 Exploded View and Replacement Parts List 19.1. Exploded View and Mechanical Replacement Parts List 19.1.1. Cabinet Parts Location (JUPITER P.C.B) CN601 CN503 CN602 VR6882 FL6601 Z6601 VR6500 CN6602 CN6001 VR6630 (PANEL P.C.B) (MPORT / HEADPHONE P.C.B) JK6810 CN6807 JK6800 *(SUPPORT P.C.B.) VR1200 JK1100...
  • Page 126 (CD MECHANISM UNIT (CR14C)) CN7001 S7201 (CD SERVO P.C.B) S7202 CN7002 JK5001 ZJ5410 CN5050 *HEATSINK UNIT A ZJ5400 (D-AMP P.C.B) CN5500 CN2810 *HEATSINK UNIT C CN2801 S5701 (MAIN P.C.B.) *HEATSINK UNIT B (VOLTAGE SELECTOR P.C.B.) JK2801 CN2802 FOR PH ONLY CN2811 (FOR PH ONLY) *Z3601...
  • Page 127 19.1.2. Packaging SB-AK780PNA *CORRUGATED PAD ACCESSORIES BAG REMOTE CONTROL SA-AK580PH/PN A1-1 R/C BATTERY COVER AC CORD (FOR PN ONLY) AC CORD (FOR PH ONLY) O/I BOOK FM INDOOR ANTENNA AM LOOP ANTENNA F R O N AC PLUG ADAPTOR (FOR PH ONLY)
  • Page 128 19.1.3. Mechanical Repacement Parts List Safety Ref. No. Part No. Part Name & Qty Remarks Description Safety Ref. No. Part No. Part Name & Qty Remarks REZX0023-1 RED WIRE (AC Description INLET-SMPS) REXX0686-1 WHITE WIRE (VOLT CABINET AND SELECTOR-SMPS) CHASSIS L6FALEFH0023 FAN UNIT ASS’Y RFKGAK580PHK...
  • Page 129 Safety Ref. No. Part No. Part Name & Qty Remarks Description RHD30111-31 SCREW RHD30119-S SCREW RHD30119-S SCREW RKA0072-KJ LEG CUSHION RKMX0144A-K TOP CABINET RMAX0333-2 CHASSIS SUPPORT RMBX0091 CD LID OPEN SPRING RMC0465 TR SPRING RMGX0033 CUSHION RUBBER RMKX0148A-3 BOTTOM CHASSIS RMKX0149-2 INNER CHASSIS RMKX0151B...

  • Page 130: Electrical Replacement Part List

    19.2. Electrical Replacement Part List Safety Ref. No. Part No. Part Name & Qty Remarks Description Safety Ref. No. Part No. Part Name & Qty Remarks IC802 C0DBZYY00293 Description IC1000 C1AB00003130 PRINTED CIRCUIT IC2121 C0ABBB000230 BOARDS IC2200 RFKWEAK580PN IC2701 C0DAAYG00001 PCB1 REPX0714J SMPS P.C.B.
  • Page 131 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description Q2772 B1GBCFJJ0051 TRANSISTOR D5503 MAZ8051GML DIODE Q2812 B1GBCFLL0037 TRANSISTOR D5701 B0FBAR000041 DIODE Q2900 B1BABK000001 TRANSISTOR D5702 B0ZAZ0000052 DIODE Q2942 B1ACKD000006 TRANSISTOR...
  • Page 132 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description LB801 J0JCC0000407 INDUCTOR CN503 K1FY104B0011 4P CONNECTOR LB802 J0JCC0000407 INDUCTOR (USB) CN601 K1MY30BA0046 30P CONNECTOR TRANSFORMERS CN602 K1MY10AA0021 10P CONNECTOR CN2801 K1MN25AA0004...
  • Page 133 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description JK2801 K2HA204B0153 JK AUX IN W5807 D0GDR00JA017 1/10W JK5001 K4AL04B00001 JK SPEAKER W6641 D0GDR00JA017 1/10W JK6800 K2HC103A0031 JK HEADPHONE W6652 D0GDR00JA017 1/10W...
  • Page 134 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description R818 D0GA473JA023 1/16W R2125 D0GB183JA008 1/16W R821 D0GA473JA023 1/16W R2126 D0GB183JA008 1/16W R822 D0GA473JA023 1/16W R2127 D0GB223JA008 1/16W R824 D0GA473JA023 1/16W...
  • Page 135 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description R2605 D0GB103JA008 1/16W R2840 D0GD101JA017 1/10W R2606 D0GB103JA008 1/16W R2843 D0GB101JA008 1/16W R2620 D0GB473JA008 1/16W R2845 D0GDR00JA017 1/10W R2621 D0GB473JA008 1/16W...
  • Page 136 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description R5003 D0GB562JA008 5.6K 1/16W R5796 D0AF222JA039 2.2K 1/2W R5004 D0GF100JA014 1/8W R5797 D0GD472JA017 4.7K 1/10W R5005 D0GF100JA014 1/8W R5798 D0GD100JA017 1/10W...
  • Page 137 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description R6600 D0GB181JA008 1/16W C557 F1J0J106A004 10uF 6.3V R6607 D0GB151JA008 1/16W C558 F1G1H101A566 100pF R6608 D0GB151JA008 1/16W C559 F1G1H101A566 100pF R6618 D0GB221JA007...
  • Page 138 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description C1107 F2A1H2R2A234 2.2uF C2311 F1J0J106A020 10uF 6.3V C1108 F1H1H472A013 4700pF C2312 F1J0J106A020 10uF 6.3V C1109 F1H1H102A219 1000pF C2313 F1H1H223A219 0.022uF 50V C1110...
  • Page 139 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description C2942 F1H1C104A042 0.1uF C5405 F1H1H104A013 0.1uF C2944 F1H1H102A219 1000pF C5406 F1H1H104A013 0.1uF C2946 F1H1H103A219 0.01uF C5407 F1J2A221A030 220pF 100V C2947 F2A0J101A181...
  • Page 140 Safety Ref. No. Part No. Part Name & Qty Remarks Safety Ref. No. Part No. Part Name & Qty Remarks Description Description C5797 F1A3A470A023 47pF 1000V C7216 ECJ1VB1H681K 680pF C5798 F2A1H5600009 56uF C7217 F1H1C104A042 0.1uF C5800 ERJ6GEY0R00A 1/8W C7218 ECJ1VB1C823K 0.082uF 16V C5805 F2B1V332A007...

This manual is also suitable for:

Sa-ak580pn

Table of Contents
