RETURN TO MAIN MENU
IM10030
RANGER 3 PHASE
November, 2010
For Machines with Code Number 11619
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However,
your overall safety can be
increased by proper installation ...
and thoughtful operation on your
part.
DO
NOT
I NST AL L,
OPERATE OR REPAI R THI S
EQUI PM ENT W I THOUT READ-
I NG THI S M ANUAL AND THE
SAFETY PRECAUTI ONS CON-
TAI NED THROUGHOUT. And,
most importantly, think before you
act and be careful.
OPERATOR'S MANUAL
Copyright © Lincoln Global Inc.
• World's Leader in Welding and Cutting Products •
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
Advertisement
Table of Contents
Related Manuals for Lincoln Electric RANGER IM10030
Summary of Contents for Lincoln Electric RANGER IM10030
- Page 1 RETURN TO MAIN MENU IM10030 RANGER 3 PHASE November, 2010 For Machines with Code Number 11619 Safety Depends on You Lincoln arc welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation ...
-
Page 2: California Proposition 65 Warnings
351040, Miami, Florida 33135 or CSA Standard W117.2-1974. A Free copy of “Arc Welding Safety” booklet E205 is available from the Lincoln Electric Company, 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199. bE SURE ThAT ALL INSTALLATION, OPERATION, MAINTENANCE AND REPAIR PROCEDURES ARE PERFORMED ONLY bY QUALIFIED INDIVIDUALS. - Page 5 PRÉCAUTIONS DE SÛRETÉ Pour votre propre protection lire et observer toutes les instructions et les précautions de sûreté specifiques qui parraissent dans ce manuel aussi bien que les précautions de sûreté générales suiv- antes: Sûreté Pour Soudage A L’Arc 1. Protegez-vous contre la secousse électrique: a.
- Page 6 Electric for advice or information about their use of our products. We respond to our customers based on the best information in our posses- sion at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such infor- mation or advice.
-
Page 7: Table Of Contents
Auxiliary Power While Welding, Standby Power Connections ...A-8 Premises Wiring ...A-9 ________________________________________________________________________________ Operation...Section b Safety Precautions ...B-1 General Description...B-1 Welder Controls Function and Operation ...B-1 Range, Polarity Control Switch and Fuel Consumption ...B-2 Start in/Shutdown Instructions ...B-3 Starting the Engine...B-3 Safety Precautions ...B-3 Stopping the Engine ...B-3 Break-In Period ...B-3... -
Page 8: Installation
Cast Iron Liners, Electronic Ignition RATED OUTPUT @ 104°F (40°C)- WELDER RATED OUTPUT @ 104°F (40°C)- GENERATOR 11,500 Watts Preak, 10,000 Watts continuous 3 Phase 60Hz AC, 480V 10,500 Watts Peak, 8500 Watts Continuous Single Phase 60 Hz AC... -
Page 9: Safety Precautions
To prevent dangerous electric shock, other equip- ment to which this engine driven welder supplies power must: • be grounded to the frame of the welder using a grounded type plug, or be double insulated. Do not ground the machine to a pipe that carries explosive or combustible material. -
Page 10: Vehicle Mounting
Use caution as the electrolyte is a strong acid that can burn skin and damage eyes. ------------------------------------------------------------------------ This welder is shipped with the negative battery cable disconnected. Make sure that the Engine Switch is in the “STOP” position and attach the disconnected cable securely to the negative battery terminal before attempting to operate the machine. -
Page 11: Angle Of Operation
Listed below are copper cable sizes recommended for the rated current and duty cycle. Lengths stipulated are the distance from the welder to work and back to the welder again. Cable sizes are increased for greater lengths primarily for the purpose of minimizing cable voltage drop. -
Page 12: Location And Ventilation
Also, locate the welder so that engine exhaust fumes are properly vented to an outside area. -
Page 13: Welder Operation
WELDER OPERATION WELDER OUTPUT • Maximum Open Circuit Voltage at 3700 RPM is 80 Volts RMS. • Duty Cycle is the percentage of time the load is being applied in a 10 minute period. For example, a 60% duty cycle represents 6 minutes of load and 4 minutes of no load in a 10 minute period. -
Page 14: Motor Starting
Resistive Capacitive Inductive Capacitive/Inductive The Lincoln Electric Company is not responsible for any damage to electrical components improperly connected to the RANGER® 3 PHASE. INSTALLATION MOTOR STARTING Most 1.5 hp AC single phase motors can be started if there is no load on the motor or other load connected to the machine, since the full load current rating of a 1.5 hp motor is approxi-... -
Page 15: Auxiliary Power While Welding
AUXILIARY POWER WhILE WELDING Simultaneous welding and power loads are permitted by following Table I. The permissible currents shown assume that current is being drawn from either the 120V or 240V supply (not both at the same time). Also, the “Output Control” is set at “10” for maximum auxiliary power. - Page 16 INSTALLATION Figure A.1 CONNECTION OF RANGER® 3 PhASE TO PREMISES WIRING WARNING Connection of RANGER® 3 PhASE to premises wiring must be done by a licensed electrician and must comply with the National Electrical Code and all other applicable electrical codes. See the INSTALLATION section for important information about not using 480V 3 Phase receptacle for con- nection to single Phase Premisis Wiring.
-
Page 17: Operation
• Insulate yourself from work and ground • Always wear dry insulating gloves. • Always operate the welder with the hinged door closed and the side panels in place. • Read carefully the Safety Precautions page before operating this machine. Always follow... - Page 18 “ RANGE” SWITCh The “Range” switch is used to select one of four amperage ranges with generous overlap for Stick/TIG welding, or one Wire Feed welding range. Process Range Setting STICK/TIG 90 Max. (constant current) 145 Max. (3 range settings) 225 MAX WIRE FEED (constant voltage)
-
Page 19: Start In/Shutdown Instructions
STARTING/ShUTDOWN INSTRUCTIONS STARTING ThE ENGINE WARNING • Do not touch electrically live parts of electrode with skin or wet clothing. • Keep flammable material away. • Insulate yourself from work and ground. Wear eye, ear, and body protection. • Keep your head out of the fumes. •... -
Page 20: Welding Process
WELDING PROCESS For any electrodes the procedures should be kept within the rating of the machine. For electrode infor- mation see the appropriate Lincoln publication. STICK (CONSTANT CURRENT) WELDING Connect welding cables to the "TO WORK” and "ELECTRODE” studs. Start the engine. Set the "Polarity”... -
Page 21: Wire Feed Welding Processes (Constant Voltage
WIRE FEED WELDING PROCESSES (CONSTANT VOLTAGE) ® electrode recommended for use with The Innershield ® the RANGER® 3 PHASE is NR -211-MP. The elec- trode sizes and welding ranges that can be used with the RANGER® 3 PHASE are shown in the following table: Diameter Wire Speed... -
Page 22: Accessories
OPTIONAL EQUIPMENT K2635-1 SMALL TWO-WhEEL ROAD TRAILER WITh DUO-hITCh-For heavy-duty road, off-road, plant and yard use. Includes pivoting jack stand, safety chains, and 13" wheels. Overall width 60". Stiff .120" welded rectangu- lar steel tube frame construction is phosphate etched and powder coat painted for superior rust and corro- sion resistance. -
Page 23: Recommended Equipment
RECOMMENDED EQUIPMENT STICK K704 Accessory Kit- (400 AMP Capacity) which includes: • Electrode Holder & Cable • Work Clamp & Cable • Headshield K875 Accessory Kit- (150 AMP Capacity) WIRE FEED K449 LN-25 - Includes internal contactor for across the arc operation (no control cable). Provides “cold” electrode until gun trigger is pressed. -
Page 24: Engine Oil Refill Capacities
SAFETY PRECAUTIONS WARNING have qualified personnel do the maintenance work. Turn the engine off before working inside the machine. In some cases, it may be necessary to remove safety guards to perform required maintenance. Remove guards only when necessary and replace them when the mainte- nance requiring their removal is complete. -
Page 25: Air Cleaner And Other Maintenance
Use 4-stroke motor oil that meets or exceeds the requirements for API service classification SG or SH. Always check the API SERVICE label on the oil con- tainer to be sure it includes the letters SG or SH. SAE 10W-30 is recommended for general, all-tempera- ture use, -5 F to 104 F (-20 C to 40 C). -
Page 26: Maintenance
RANGER® 3 PhASE WARNING cable from old battery first and connect to new bat- tery last. tery from welder by disconnecting negative cable first, then positive cable and battery clamp. When reinstalling, connect negative cable last. Keep well ventilated. first then connect negative lead to engine foot. -
Page 27: How To Use Troubleshooting Guide
TO USE TROUbLEShOOTING GUIDE Service and Repair should only be performed by Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on this equipment may result in danger to the technician and machine operator and will invalidate your factory warranty. For your safety and to avoid Electrical Shock, please observe all safety notes and precautions detailed throughout this manual. - Page 28 Observe all Safety Guidelines detailed throughout this manual PRObLEMS (SYMPTOMS) No welder output power or Auxiliary Power. Engine will not idle down to low speed. Engine will not go to high idle when attempting to weld. * Printed Circuit Board (PCB) If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
- Page 29 Observe all Safety Guidelines detailed throughout this manual PRObLEMS (SYMPTOMS) Engine will not go to high idle when using auxiliary power. Engine will not crank or is hard to crank. Engine shuts down. Engine does not develop full power. Engine is hard to start. If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
- Page 30 DIAGRAMS RANGER® 3 PhASE...
- Page 31 DIAGRAMS RANGER® 3 PhASE...
-
Page 32: Dimension Print
DIMENSION PRINT RANGER® 3 PhASE... - Page 33 NOTES RANGER® 3 PhASE...
- Page 36 • World's Leader in Welding and Cutting Products • • Sales and Service through Subsidiaries and Distributors Worldwide • Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com...
