BLOCK DIAGRAM

Input
DSP
Loop thru

SPECIFICATIONS

Nominal LF Power Amplifier
Nominal HF Power Amplifier
Input Type
Input Impedance
Sensitivity
Frequency Range (-10 dB)
Horizontal Coverage (-6dB)
Vertical Coverage
Rated Maximum Peak SPL at 1 m
Transducers/Replacement Parts
Enclosure Geometry
Enclosure Material
Color/Finish
Rigging System Splay Angles
Connectors
AC Power Requirements
Dimensions (H x W x D)
Weight
Accessories
1. Maximum calculated Peak SPL based on sensitivity and RMS power handling.
8
HIGH
LOW
aero 8A
Model
250 W (Class D)
100 W (Class D)
Balanced Differential Line
Line: 20 kohms
Line: 1.95 V (+8 dBu)
95 Hz -20 kHz
90º Nominal
Splay Dependent
(1)
128 dB
LF: 1 x 8MN/GM 8MN
HF: 1 x M-60N/GM M-60
Trapezoidal 5º
Birch Plywood
Black Paint
Integrated in box design
INPUT: Female XLR
LOOP THRU: Male XLR
AC INPUT: PowerCon NAC 3 FCA
AC OUTPUT: Powercon NAC 3 DFCB
115 V, 50 Hz/60 Hz
230 V, 50 Hz/60 Hz
24.5 x 52.6 x 35.5 cm
9.6 x 20.7 x 14 in
18 kg (39.6 lbs)
AX-aero8 Rigging Grid
AX-LX212 Rigging Grid
AXS-aero8
Manual del Usuario / aero 8A / User's Manual
Switching
Power
Supply
Switching
Power
Supply
Limit
Signal
ON
LX-212A
1800 W (Class D)
---
Balanced Differential Line
Line: 20 kohms
Line: 1.95 V (+8 dBu)
45 Hz -138 Hz
---
---
136 dB
LF: 2 x 12LXN/GM 12LX
Rectangular
Birch Plywood
Black Paint
Ground Stackable
INPUT: 2 x Female XLR
LOOP THRU: 2 x Male XLR
AC INPUT: PowerCon NAC 3 FCA
AC OUTPUT: Powercon NAC 3 DFCB
115 V, 50 Hz/60 Hz
230 V, 50 Hz/60 Hz
48.8 x 48 x 87 cm
(19.2 x 18.9 x 34.3 in)
49 kg (107.8 lbs)
AX-LX212 Rigging Grid
PL-212S
TRD-5
MAIN
HF
LF
LX-212RA
1800 W (Class D)
---
Balanced Differential Line
Line: 20 kohms
Line: 1.95 V (+8 dBu)
45 Hz -138 Hz
---
---
136 dB
LF: 2 x 12LXN/GM 12LX
Rectangular
Birch Plywood
Black Paint
Integrated in box design
INPUT: 2 x Female XLR
LOOP THRU: 2 x Male XLR
AC INPUT: PowerCon NAC 3 FCA
AC OUTPUT: Powercon NAC 3 DFCB
115 V, 50 Hz/60 Hz
230 V, 50 Hz/60 Hz
48.8 x 52.6 x 87 cm
(19.2 x 20.7 x 34.3 in)
65 kg (143 lbs)
AX-LX212 Rigging Grid
PL-212S
TRD-5
