Lincoln Electric Metalshield MC-715 Specification Sheet

Mild steel metal-cored wire.
Hide thumbs


Advertisement

Metalshield
Mild Steel Metal-Cored Wire
Metalshield MC-715 is designed for virtually slag free deposits in single or multiple pass
welding applications. Its design achieves robust low temperature impacts and can be
used in semiautomatic and automatic applications. Excellent for welding over scale or
surface contaminants.
Advantage Lincoln
• Smooth, spray-type arc transfer and low spatter level.
• High deposition efficiency.
• Good resistance to porosity on mill scale.
• Excellent "fast follow" characteristics.
• Robust low temperature impact properties.
• Manufactured under a quality system certified to ISO 9001
requirements.
Typical Applications
• Mining equipment
• Heavy equipment
• Offshore
• General structural fabrication
DIAMETERS/PACKAGING
Diameter
33 Lb. (15kg)
in. (mm)
Plastic Spool Foil Bag
.045 (1.1)
ED030944
1/16 (1.6)
ED030945
MECHANICAL PROPERTIES – As Required per AWS A5.18-01
Yield
Strength
psi (MPa)
Requirements
58,000 (400)
AWS E70C-6M H8
min.
Test Results
80% Ar/20% CO 2
65,000-71,000
(460-490)
MC-715
(AWS E70C-6M H8)
Welding Positions
1F
3G
Shielding Gas
75-95% Argon / Balance CO 2
Flow Rate: 30-45 CFH
Higher argon percentage will lower the amount of generated welding
fume. A 15-25% CO 2 range may be used for improved arc
characteristics when welding in the short circuiting mode.
Conformance
AWS A5.18-01: E70C-6M H8
ASME SFA-5.18: E70C-6M H8
BV: SA3-3YMHH
ABS: 4Y403H
DNV: IV Y40H5
GL: 4Y40H5S
LR: 4Y40H5
Diffusible Hydrogen -
Requirements (AWS E70C-6M H8)
Test Results: 80% Ar/20% CO 2
Tensile
Strength
Elongation
psi (MPa)
(%)
@ -20ºF (-29ºC)
70,000 (483)
22
20 (27)
min.
min.
76,000-81,000
25-31
Exceeds
(527-556)
Requirements
CORED WIRE
1G
2G
2F
4G
As required per AWS A5.18-01
Charpy V-Notch, ft•lbf (Joules)
@-40°F(-40°C)
@-51°F(-46°C)
Not Specified
Not Specified
min.
76-115
(103-156)
(94-119)
3F
3G
8.0
2.0 - 5.0
69-88
Publication C3.11.1 5/05
www.lincolnelectric.com
