Kozi DV1-FS series Owner's Manual

Direct vent freestanding gas stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Direct Vent Freestanding Gas Stove
*Installation * Operation * Service * Parts *
Model Identification
DV1-FS-*
*=NG
Natural Gas
*=LP
Propane
Manufactured By: APR Industries Ltd. 1354 Waverley Street, Winnipeg, Manitoba, Canada, R3T 0P5
Save This Manual For Future Reference
Owner's Manual
WARNING: If the information in these instructions are
not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance
• WHAT TO DO IF YOU SMELL GAS
o Do not try to light any appliance.
o Do not touch any electrical switch; do not
use any phone in your building.
o Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
o If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed by a
qualified installer, service agency or the gas
supplier
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the types of gas
indicated on the rating plate. A conversion kit is
available for the appliance.
Printed in Canada
Revision July 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV1-FS series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kozi DV1-FS series

Summary of Contents for Kozi DV1-FS series

  • Page 1 Owner’s Manual Direct Vent Freestanding Gas Stove *Installation * Operation * Service * Parts * WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life •...
