Summary of Contents for Engel MHD13F-DM
- Page 1 Fridge / Freezer / Warmer with DIGITAL TEMPERATURE CONTROL MODEL MHD13F-DM...
- Page 2 SPECIFICATION DESIGNATION OF PARTS SHOLDER MODEL MHD13F-DM STRAP CAPACITY OUTER DIMENSIONS 442×284×372 (W×D×H) INPUT RATING VOLTAGE DC 12/24V (FRIDGE or FREEZER) 3.0/1.5A CABINET (WARMER) 2.5/1.3A REFRIGERANT HFC-134a WEIGHT APPROX. 11.5kg LOUVER CONTROL PANEL INSTALLATION Though it will operate satisfactory for long period of up to 30°off level, the product should be installed on a level and solid surface.
- Page 3 ＊ TO ENSURE THE EFFICIENT OPERATION OF THE PRODUCT PLEASE ADHERE TO THE FOLLOWING: 1 ) Ensure that the lighter socket is clean and free from dust, corrosion or other foreign materials. 2 ) To adjust the plug setting, please refer to Fig 3. For Japanese American Australian built vehicles Plug Cover...
- Page 4 From 6m to 10m SWG#14 (AWG#12) ( Fig 7 ) Contact your Engel dealer for advice More than 10m ⑤INSTALLING A FUSE IN THE WIRING CIRCUIT To avoid burn out of wiring from battery to the product in the event of a short circuit, install 10A fuse in the wiring circuit, nearby the battery.
-
Page 5: Troubleshooting
ENGEL dealer if there are any questions regarding engine generators and the product compatibilities. FRIDGE engine generator OPERATON To operate the product – insert the cigarette lighter plug of the DC cord into the cigarette lighter socket of the vehicle. - Page 6 Holder A Table ② Holder B Seam Should be upper side Check whether the power voltage is too low or too high. Check whether the power voltage is too low or too high. ( Fig 10 ) If the problem still exists after solving it according to Table, it should be seen to by a specialist. FRIDGE B A T T Never disassemble the refrigerator by yourself.
-
Page 7: Refrigerator Maintenance
WARNING Do not make use of conventional glass tube fuses. We recommend only using an Engel thermal fuse. This special thermal fuse has a polarity. Please read the under mentioned instructions on how to replace the fuse and make sure to check the polarity connection is correct before replacing it. - Page 8 Secure SHOULDER STRAP onto the product by referring to Fig 10. 1. Thread both ends of the SHOULDER STRAPS through holder A (on both sides of your ENGEL). 2. Then fasten both ends of the SHOULDER STRAPS onto holder B as shown on ② of Fig10.
