Lincoln Electric Idealarc DC-1500 Technical Specifications

Idealarc
The DC-1500 is a multiprocess DC arc welding power source for
automatic welding applications. It produces outstanding arc
characteristics on both constant voltage and constant current
processes. This provides great welding versatility in a single power
source.
The DC-1500 is designed for submerged arc welding, and FCAW
processes within the capacity of the machine. It produces
outstanding welding performance with a single range full output
control potentiometer.
The precise output of the DC-1500 enhances productivity and
quality control when used with Lincoln NA-3 and NA-5 automatic
wire feeders, and the LT-7 tractor.
Processes
Flux-Cored, Submerged Arc
Advantage Lincoln
• Solid state circuitry provides extra ling life for repetitive welding
applications.
• Full range output voltage control for easy operation and precise output
control.
• Mode switch used to select the desired output characteristics for the
process being used.
• Line voltage compensation for maintaining weld consistency, even
with line voltage changes of ±10%.
• Fan cooled with electronic and thermostatic protection from current
overload and excessive temperatures.
Product Product
Name Number
DC-1500 K1275
K1383-4 380/440/3/50/60
®
DC-1500
TECHNICAL SPECIFICATIONS
Input Rated Output
Power Current/Voltage/Duty Cycle
460/3/60 1500A / 44V / 100%
1500A / 60V / 100%
MULTIPROCESS WELDERS
• Function lights built into the printed circuit boards speed diagnostics.
• Windings and rectifiers protected against moisture and corrosive
environments.
• Eight amp fuse protected 115V wire feeder auxiliary power with 1000
volt-amp capacity.
• Three-year warranty on parts and labor.
• Seven-year warranty on the power rectifier.
• Manufactured under a quality system certified to ISO 9001
requirements and ISO 14001 environmental standards.
Input Current Output
@ Rated Output Range
184A 20-60V
216A/187A 200-1500A
Output
CC
CV
DC
Input
3
PHASE
60
Hz
50
Hz
Dimensions Net
H x W x D Weight
inches (mm) lbs. (kg)
57.2 x 22.3 x 38.0 1420 (644)
(1453 x 566 x 965)
