Telefunken TKP2939ST Service Manual page 11

Item No.
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
26-EBP390-JCX CAP. CER 39PF 50V +/-5% CH
26-EBP390-JCX CAP. CER 39PF 50V +/-5% CH
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20%
26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20%
26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20%
26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20%
26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20%
08-02990M-AVY ASS'Y - SIDE AV BD
11-SC1815-YBX TRANSISTOR 2SC1815Y
11-SC1815-YBX TRANSISTOR 2SC1815Y
11-SK2541-0BX FET 2SK2541(N-CHANNEL)
13-000040-66P IC 4066 (ANALOG SW.)
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5%
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5%
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5%
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5%
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5%
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5%
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5%
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5%
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5%
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5%
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5%
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5%
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B
34-R220J2-0EX COIL PL - 22 UH +/-5%
40-2990UA-SIC P.C.B. SIDE AV BD
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM
41-WJ0100-B00 WIRE BARE JUMPER 10MM
41-WJ0100-B00 WIRE BARE JUMPER 10MM
46-39136H-07X 7P 2468#24/1185#26 550 TJC3-7Y/SCN-7Y
Description Quantity Req. Designator
1 J1021
1 J1022
1 C1034
1 C1035
1 C1006
1 C1009
1 C1011
1 C1018
1 C1017
1 C1030
1 C1031
1 C1032
1 C1033
1
1 Q962
1 Q963
1 Q961
1 IC951
1 R952
1 R953
1 R954
1 R955
1 R964
1 R963
1 R965
1 R967
1 R956
1 R957
1 R958
1 R966
1 R959
1 R951
1 R961
1 R962
1 C962
1 L961
1
1 J962
1 J964
1 J961
1 J963
1 P902
11
Remarks
