Summary of Contents for Sentry US NC-DS2
- Page 1 Operation and Installation Manual Color IR Camera & Video Intercom System Color IR Camera 7” Color Monitor Outdoor Station Inside Station NC-DS2 NC-MON4 Please read the Operational Manual before attempting to use this product.
-
Page 2: Table Of Contents
Wiring Connection System Diagram ……...……………………………...…… 5 Installation ….………………………………………..…….……………..……. 5-6 Operation ……………………………………………………………….……... 6-7 Specifications …………………………………………………………….……... 8 Package Contents ………………………………………………….………….. 8 Features NC-DS2 Color IR Camera Outdoor Station • 1/3” CCD • 0.05 Lux • 120 sec Communication Duration • Duplex Communication Type • IP55 Rating •... -
Page 3: Video Camera Intercom System Configuration Diagram
Video Camera Intercom System Configuration Diagram Color IR Camera Outdoor Station NC-CS2 No. Name Description Water Cover Protect the camera from outside water Provide lighting during night time for better LED Assistant visibility CCD Camera Capture the image to send to the monitor Speaker Sound from the monitor is delivered Calling Button... -
Page 4: Indoor Color Monitor
Color Monitor Inside Station NC-MON4 For built-in power supply 371 Icon Description Icon Description Microphone Speaker Monitor Talking Volume Hang Off Brightness Door Lock Releasing Chrome/Contrast Talking System Terminal TFT Display/CRT Calling Copyright © 2009. All rights reserved. REV122109 www.SentryUS.com... -
Page 5: Wiring Connection System Diagram
Note: Socket CN1 is just retained for outdoor station in alone system (like as an outdoor unit is matched with an indoor unit). Please recheck the polarity of CN1 and have the 4-wire connected as per the enclosed label. Installation NC-DS2 Color IR Camera Outdoor Station Copyright © 2009. All rights reserved. REV122109 www.SentryUS.com... -
Page 6: Operation
NC-MON4 Color Monitor Inside Station Instructions: 1. System Cable: Non-STP core cable, wire > 0.5mm , from outdoor station to the farthest monitor < 200ft / 70m 2. Any monitor can be paralleled, max 4 monitors and 2 outdoor stations 3. - Page 7 2. Monitor 3. Communication Among The Optional Monitors & Audio Copyright © 2009. All rights reserved. REV122109 www.SentryUS.com...
-
Page 8: Specifications
240mm x 175mm x 38mm *Specifications are subject to change without notice Package Contents • One (1) NC-DS2 Color IR Camera Outdoor Station o One (1) Flush Mounting Back Cover o Four (4) Long Mounting Screws o One (1) Allen Wrench •...
