X17LCD
Model:
Professional 17" LCD CCTV
Monitor with 3D Noise Filter
Before you begin
Please unpack the box carefully and identify that all the parts are present.
Please bear in mind the following points when choosing a mounting position.
Do not expose the display to humidity, dust, direct sunlight or to extreme weather conditions.
Do not use thinner or other chemical detergents when cleaning. Use a soft cloth to remove dust
or dirt from the display screen.
Avoid storage and use of this display in areas of extreme hot or cold. The display's operating
temperature range is -10°C to +40°C.
Do not drop or strike the display.
For your own safety, when the display is not in use, remove the AC adapter from the mains.
Do not cut the LCD cables, this will void the warranty.
Make sure you use only the recommended power supply. Damage caused to the LCD by incorrect
voltage or wiring is not covered by the warranty.
Model:
X17LCD/X19LCD
Professional 17"/19" LCD CCTV Monitor
with 3D Noise Filter
X19LCD
Model:
Professional 19" LCD CCTV
Monitor with 3D Noise Filter
CCTV
Advertisement
Table of Contents
Related Manuals for XVision X17LCD
Summary of Contents for XVision X17LCD
-
Page 1: Before You Begin
CCTV X17LCD X19LCD Model: Model: Professional 17” LCD CCTV Professional 19” LCD CCTV Monitor with 3D Noise Filter Monitor with 3D Noise Filter Before you begin Please unpack the box carefully and identify that all the parts are present. Please bear in mind the following points when choosing a mounting position. -
Page 2: Safety Precautions
2. Product Description The X17LCD and X19LCD feature a 17" and 19” TFT LCD respectively, which generate 1280 x 1024 pixel (800 TVL) resolution images, making them ideal for high risk applications. Specially designed for CCTV use, they feature High Brightness LCD displays with a special noise reduction filter for excellent image quality and high fidelity speakers for good quality audio. -
Page 3: Refresh Rate
1280 X 960 1152 X 864 SXGA 1280 X 1024 Recommended mode: 1280x1024@60Hz 3. Contents POWER MUTE SMART S SMART P MENU SOURCE INFO 16:9 DCDi COLOR AUDIO X17LCD/X19LCD Monitor Remote Mains Power Lead Control Audio Connection VGA Connection Lead Lead... -
Page 4: Installation And Connection
4. Installation & Connection 4.1 CONNECTIONS FOR CCTV / DVR 1. Remove the cover FIG. 1 FIG. 2 on the rear right on the monitor by lifting the VIDEO INPUT AUDIO INPUT panel up as shown in VIDEO OUTPUT O OUTPUT LEFT CHANNEL AUDIO OUTPUT Fig. -
Page 5: The Front Panel
5. Controls 5.1 THE FRONT PANEL Cursor Keys CH+ CH- Vol+ Vol- Menu Power Source 5.2 REMOTE CONTROL POWER MUTE Mute Power Numerical Keys Program List (optional) SMART S SMART P Smart Sound Smart Image MENU SOURCE Menu Source OK (confirm selction) Cursor Keys Channel Up/Down Volume Up/Down... -
Page 6: Control Functions
1. Aim the remote control at the infra-red receiver on the front of the LCD. 2. Avoid pressing, dropping, moistening or disassembling the unit. 3. Avoid pressing remote control buttons continuously and quickly. Allow at least 2 seconds for the remote control to function correctly. 4. -
Page 7: Basic Operation
6. Basic Operation POWER ON Plug power cord into the electrical socket (the LED on the monitor will light up RED) and press ' ' key on the front panel, then press the POWER Cursor Keys button on the Remote Control to turn on the monitor. The LED on the monitor will light up GREEN when it is ON. -
Page 8: Menu Navigation
MENU NAVIGATION Use the following steps to navigate through the Menu systems on the monitor. 1. To enter the Menu system, press MENU button on the Remote Control or on the Front Panel. The monitor will display the Main Menu. 2. -
Page 9: Picture Adjustment Menu
6.1 PICTURE ADJUSTMENT MENU See the table below for the options available with the Picture Adjustment Menu: Option Function Description PICTURE There are four modes; STANDARD, Select picture mode DYNAMIC, SOFT or PERSONAL MODE Increasing value increases Contrast; Adjust the contrast of CONTRAST Decreasing value decreases Contrast whole picture... - Page 10 Note: 1. The value adjusted by user, such as Contrast, Brightness, Saturation, Hue, and Sharpness, will be saved automatically when the settings are changed 2. You can only adjust Brightness, Contrast, Sharpness and Black Light in PERSONAL mode. REMOTE CONTROL SHORTCUT KEYS SMART P (Smart Picture) - Switch the Picture Mode between STANDARD, DYNAMIC, SOFT or PERSONAL 16:9 - Switch the Scale of the display between FULL, ZOOM1, ZOOM2,...
-
Page 11: Sound Adjustment Menu
6.2 SOUND ADJUSTMENT MENU See the table below for the options available with the Sound Adjustment Menu: Option Function Description There are four modes; PERSONAL, SOUND MODE Adjust audio effect mode STANDARD, NEWS or MUSIC Increasing value increases bass; BASS Adjust bass value Decreasing value decreases bass (0-100) Increasing value increases treble;... -
Page 12: Advance Menu
6.3 ADVANCE MENU See the table below for the options available with the Advanced Menu: Option Function Description Selects the 3D Noise There are three modes; WEAK, STRONG or Reduction mode Turn ON or OFF BLUE BLUE SCREEN Select ON or OF SCREEN Select the scale of the There are five modes;... -
Page 13: System Menu
6.4 SYSTEM MENU See the table below for the options available with the System Menu: Option Function Description Choose OSD menu display Select the Language you wish the OSD language menu to be displayed in. LANGUAGE Increasing value will move OSD menu right; Adjust H-position of OSD H-POSITION Decreasing value will move OSD menu left... -
Page 14: Troubleshooting
7. Troubleshooting Symptom Possible Fault Solution 1.Check power cord to see if it is Power plug is loose, properly connected No image. No sound. power cord is not 2. Press the POWER button on the connected properly. Front Panel or on the Remote Control. -
Page 15: Specifications
8. Specifications Model: X17LCD X19LCD Screen Type: Colour LCD Screen Size: 17” 19” Resolution: 1280x1024 @ 60HZ Audio: SVHS Socket Video Inputs: VGA/HDMI Sockets BNC/Phono Sockets Audio Inputs: BNC/Phono Sockets Headphone Output: Speakers: Dual BNC Socket (Video Output) Loopthroughs: BNC/Phono Sockets (Audio Output) -
Page 16: Technical Support
CCTV CCTV TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
