XVision X5LCD User Manual

Professional 5/8” lcd cctv monitor with 3d noise filter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X5/8LCD
Model:
Professional 5/8" LCD CCTV
Monitor with 3D Noise Filter

Before you begin

Please unpack the box carefully and identify that all the parts are present.
Please bear in mind the following points when choosing a mounting position.
Do not expose the display to humidity, dust, direct sunlight or to extreme weather conditions.
Do not use thinner or other chemical detergents when cleaning. Use a soft cloth to remove dust
or dirt from the display screen.
Avoid storage and use of this display in areas of extreme hot or cold. The display's operating
temperature range is -10°C to +40°C.
Do not drop or strike the display.
For your own safety, when the display is not in use, remove the AC adapter from the mains.
Do not cut the LCD cables, this will void the warranty.
Make sure you use only the recommended power supply. Damage caused to the LCD by
incorrect voltage or wiring is not covered by the warranty.
Model:
X5/8LCD
Professional 5/8" LCD CCTV Monitor with 3D Noise Filter
X8LCD
CCTV
X5LCD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X5LCD and is the answer not in the manual?

Questions and answers

Related Manuals for XVision X5LCD

Summary of Contents for XVision X5LCD

  • Page 1: Before You Begin

    CCTV X8LCD X5LCD X5/8LCD Model: Professional 5/8” LCD CCTV Monitor with 3D Noise Filter Before you begin Please unpack the box carefully and identify that all the parts are present. Please bear in mind the following points when choosing a mounting position.

  • Page 2: Safety Precautions

    Thank you for purchasing this Xvision monitor. Before operating this product, please read this instruction manual carefully. 1. Safety Precautions Make sure that you use only the recommended power supply supplied with the unit. When installing the monitor, please make sure that you observe the necessary safety precautions.
  • Page 3 3. Contents X5/8LCD Monitor with Bracket Remote Control Mains Power Adaptor...
  • Page 4 4. Connections AV1 Input (Phono Socket) Standard Connections from AV2 Input Monitor (Phono Socket) (X5/8LCD) Power Input Mains Power Adaptor (Red DC Socket) (DC Plug) Plug into Mains Power Additional Connections from VGA Input Monitor (X8LCD only) 5. Controls Power Menu Top of Monitor 1.

  • Page 5: Remote Control Functions

    6. Remote Control Power Video Select VIDEO SELECT Menu MENU -/+ Buttons MODE SELECT Mode Select (Function unavailable) NOTE: Remember to remove the plastic sheet located at the bottom of the remote control before use. 1. Aim the remote control at the infra-red receiver on the front of the LCD. 2.

  • Page 6: Troubleshooting

    7. OSD Menu In AV mode, press the MENU button to enter Menu mode and then to select the menu category you wish to adjust. Use the buttons on the remote control or the -/+ buttons on the monitor to make any adjustments to the following: BRIGHTNESS - Adjustment range: 0-100.

  • Page 7: Specifications

    9. Specifications Model: X5LCD X8LCD Screen Type: Professional LCD Screen Size: 5” 8” Resolution: 640x480 800x600 Audio: AV Inputs: 2x Phono Socket VGA Input: Remote Control: Power Requirements: 12V DC, 2000mA Power Consumption: < 10W < 20W Suggested Power Supply:...

  • Page 8: Technical Support

    CCTV TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 2 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
