XLCD12
Model:
Professional 12" LCD CCTV
Monitor & Digital Photo Frame
Before you begin
Please unpack the box carefully and identify that all the parts are present.
Please bear in mind the following points when choosing a mounting position.
Do not expose the display to humidity, dust, direct sunlight or to extreme weather conditions.
Do not use thinner or other chemical detergents when cleaning. Use a soft cloth to remove dust
or dirt from the display screen.
Avoid storage and use of this display in areas of extreme hot or cold. The display's operating
temperature range is -10°C to +40°C.
Do not drop or strike the display.
For your own safety, when the display is not in use, remove the AC adapter from the mains.
Do not cut the LCD cables, this will void the warranty.
Make sure you use only the recommended power supply. Damage caused to the LCD by
incorrect voltage or wiring is not covered by the warranty.
Model:
XLCD12
Professional 12" LCD CCTV Monitor
& Digital Photo Frame
CCTV
Advertisement
Table of Contents
Related Manuals for XVision XLCD12
Summary of Contents for XVision XLCD12
-
Page 1: Before You Begin
CCTV XLCD12 Model: Professional 12” LCD CCTV Monitor & Digital Photo Frame Before you begin Please unpack the box carefully and identify that all the parts are present. Please bear in mind the following points when choosing a mounting position. -
Page 2: Safety Precautions
2. Product Description The XLCD12 Colour monitor combines the small form factor of an LCD monitor with the large screen size of a CRT monitor. It features a 12" TFT LCD which generates 1024 x 768 resolution images, making it ideal for medium to high risk applications. - Page 3 3. Contents XLCD12 Monitor Stand Bracket Remote Control Batteries Mains Power Supply DVR Connection Connectors & Lead Adapters 4. Controls- Front 1. LCD Screen 2. Remote Control Receiver...
- Page 4 5. Controls- Rear Top of Monitor Bottom of Monitor 1. Stop Video/Photo 8. USB Port (in VGA mode) 2. Pause/Play 9. 12V DC Input (in VGA mode) 3. On/Off Switch 10. USB Port 4. Volume Down 11. SD/MS/MMC Card Reader (in VGA mode) 5.
-
Page 5: Remote Control
6. Remote Control Mute POWER MUTE SOURCE Source Power On/Off Numeric Buttons _/__ RETURN Menu DISPLAY EXIT MENU MODE Display Mode Exit VOL - VOL + ECHO - ECHO+ Volume Down Channel Down Volume Up Channel Up PHOTO MUSIC MOVIE FILE Photo Mode Movie Mode... - Page 6 6. Remote Control (continued) 6.1 Controls POWER - Press the POWER button to turn the monitor display ON or OFF. Please turn the unit off at the mains during long periods when you are not using the monitor. MUTE - Press this button to mute (disable) the sound. Press it again to resume normal operation or press either the Vol+ or Vol- buttons.
- Page 7 TV-MODE - Press this button to shift to AV output CARD SELECT - Unavailable AUDIO - Press this button to switch tracks between the original song and accompany song or the different language in the movie ZOOM - Press the Zoom button to turn Zoom on and off ROTATE- Press this button to rotate the picture 90°, 180°...
-
Page 8: Basic Operation
7. Basic Operation There are 2 modes on the XLCD12 monitor: AV and VGA mode. AV mode should be selected to watch video via the AV input. VGA mode should be activated to access and playback files via the USB ports or the memory card slots. -
Page 9: Picture Menu
7.1.2 PICTURE Menu Press ECHO+ or ECHO- to choose the setting required from the following: • Auto Config - Automatically configures the Picture settings of the monitor • Auto Color - Automatically set the colour • H Position - Alter the horizontal position of the picture on the screen •... -
Page 10: Sound Menu
7.1.4 SOUND Menu Press ECHO+ or ECHO- to choose the setting required from the following: • Volume - Alter the Volume of the monitor • Volume Mute - Turn OFF the sound by setting this option to ON. Setting this option to OFF will allow the volume to be controlled manually •... -
Page 11: Vga Mode
Numeric Buttons 7.2 VGA MODE _/__ RETURN Menu NOTE: Before trying to access any of the following functions insert a media card DISPLAY EXIT MENU MODE Display Mode (SD/MS/MMC/CF) into one of the card reader slots on the bottom of the unit or Exit VOL - VOL +... -
Page 12: Speaker Setup Menu
5. Press the SETUP button to access the menus (listed below) in turn. 6. Press to select the sub menus. 7. Press to enter the setting you wish to change and press ENTER to change the value of the selected menu item followed by set the changes. -
Page 13: Preferences Menu
7.2.3 PREFERENCES Menu Press the arrow keys to choose the setting required from the following: • OSD LANG - Choose between English, Chinese, French, German, Italian, Spanish. • TRANSITION - Choose between 14 types of OSD Language Transition types between images •... -
Page 14: Troubleshooting
9. Troubleshooting SYMPTOM POSSIBLE CAUSE 1. Make sure the power adapter is plugged in correctly System does not turn ON 2. Make sure the power switch is switched 1. Make sure VGA mode is activated 2. Ensure memory card/device is inserted/connected correctly 3. -
Page 15: Specifications
10. Specifications Model: XLCD12 Screen Type: Screen Size: 12” Resolution: 1024 x 768 Audio: Video Inputs: 2x Phono Sockets Audio Inputs: 1x Phono Socket Audio Output: 2 Watts (Max.) Speakers: Dual Loopthroughs: Remote Control: Power Requirements: 110 to 240V AC, 12V Output... -
Page 16: Technical Support
CCTV CCTV TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
