Summary of Contents for Comet System P8510
- Page 1 COMET SYSTEM www.cometsystem.cz P8510 intelligent thermometer P8511 intelligent single-channel transducer P8541 intelligent four-channel transducer USER MANUAL...
- Page 2 Is prohibited to copy and make any changes in this manual, without explicit agreement of company COMET System, Ltd. All rights reserved. COMET System, Ltd. makes constant development and improvement of their products. Manufacturer reserves the right to make technical changes to the device without previous notice.
-
Page 3: Table Of Contents
IE-SNC-P85x1-11 Table of contents Introduction ................................ 4 General safety rules ............................. 4 Device description and important notices ....................5 Getting started ..............................6 What is needed for operation ........................6 Mounting the device ............................ 6 Device settings ............................. 8 Checking functions ............................10 Device setup ..............................11 Setup using web interface .........................11 Setup using TSensor software .........................18... -
Page 4: Introduction
This chapter provides basic information about device. Before starting please read this manual carefully. P8510 Intelligent Thermometer or P8511 and P8541 Transducers are used to measure temperature or relative humidity. Temperature can be displayed in °C or °F. Relative humidity have unit %RH. Communication with the device is realized via Ethernet network. -
Page 5: Device Description And Important Notices
IE-SNC-P85x1-11 Don’t stress the device mechanically. Device description and important notices This chapter contains informations about basic features. Also there are important notices concerning to functional safety. Values from the device can be read using an Ethernet connection. The following formats are supported: Web pages with user changeable look and XML files Modbus TCP protocol... -
Page 6: Getting Started
What is needed for operation To install the unit you need to the following equipment. Before installation check if it’s available. P8510 Thermometer or P8511 Transducer, P8541 Transducer power supply adapter 5V/250mA (or compatible PoE splitter) RJ45 LAN connection with appropriate cable free IP address in your network for P8511 Transducers one probe. - Page 7 When you installing several new devices, connect them to the network one after another. connect probes to P8511 or P8541 Transducer connect the Ethernet connector connect the power adapter 5V/250mA LEDs on LAN connector should blink after connecting the power P8510 Thermometer connection: P8511 Transducer connection:...
-
Page 8: Device Settings
IE-SNC-P85x1-11 P8541 Transducer connection: Connect via PoE splitter: Device settings run configuration software TSensor on your PC switch to an Ethernet communication interface press button Find device... the window shows all available devices on your network... - Page 9 IE-SNC-P85x1-11 click to Change IP address to set new address according to network administrator instructions. If your device is not listed, then click Help! My device wasn’t found! Then follow the instructions. MAC address is on product label. The device is factory set to IP 192.168.1.213. gateway may not be entered if you want to use the device only in local network.
-
Page 10: Checking Functions
IE-SNC-P85x1-11 Checking functions The last step is to check measured values on the device website. In the address bar of the web browser, enter the device IP address. If the default IP address was not changed, then insert http://192.168.1.213. Displayed web page lists actual measured values. If the web pages are disabled, you can see text Access denied. -
Page 11: Device Setup
IE-SNC-P85x1-11 Chapter Device setup This chapter describes basic device configuration. There is a description of settings using web interface. Setup using web interface Device can be setup using web interface or TSensor software. Web interface can be managed by the web browser. Main page will be shown when you insert device address into address bar of your web browser. - Page 12 IE-SNC-P85x1-11 General Device name can be changed using item Device name. Measured values are stored into memory according History storage interval field. After changing of this interval all history values will be cleared. Changes must be confirmed by Apply settings button. Network Network parameters can be obtain automatically from DHCP server using option Obtain an IP address automatically.
- Page 13 IE-SNC-P85x1-11 Alarm limits For each measurement channel is possible to set upper and lower limits, time-delay for alarm activation (0 – 65535s) and hysteresis for alarm clearing. Example of setting the limit to the upper alarm limit: In Point 1 the temperature exceeded the limit. From this time, the time-delay is counting. Because at point 2 the temperature dropped below the limit value before the time delay expired, alarm was not set.
- Page 14 IE-SNC-P85x1-11 Channels Channel can be enabled or disabled for measuring using item Enabled. Channel can be renamed (max. 14 characters) and it is possible select unit of measured value according connected probe type. When channel is not used, it is possible copy to it one of other channels –...
- Page 15 IE-SNC-P85x1-11 Email Email sending enabled option allows email features. It is necessary set address of the SMTP as IP address into SMTP server IP address field. Default port of the SMTP server can be changed using item SMTP server port. SMTP authentication can be enabled using SMTP authentication option.
- Page 16 IE-SNC-P85x1-11 Modbus a Syslog protocols ModbusTCP and Syslog protocol settings are configurable via menu Protocols. Modbus server is enabled by default. Deactivation is possible via Modbus server enabled option. Modbus port can be changed via Modbus port field. Syslog protocol can be enabled using item Syslog enabled.
- Page 17 IE-SNC-P85x1-11 Time Time synchronization with SNTP server can be enabled by Time synchronization enabled option. IP address of the SNTP is necessary to set into SNTP server IP address item. SNTP time is synchronized at UTC format, and due to be necessary set corresponding time offset - GSM offset [min].
-
Page 18: Setup Using Tsensor Software
IE-SNC-P85x1-11 Setup using TSensor software TSensor software is an alternative to web configuration. Some less important parameters are configurable only by the TSensor software. Parameter MTU size can reduce size of the Ethernet frame. Lowering of this size can solve some communication problems mainly with Cisco network infrastructure. Sensor software can set offset of values at temperature probes. - Page 19 IE-SNC-P85x1-11 Password for SNMP reading public Sending SNMP Trap Website refresh interval [sec] Website enabled Website port Security Administrator password cleared User password cleared Modbus TCP protocol port Modbus TCP enabled History storage interval [sec] SOAP server IP address 0.0.0.0 SOAP destination port SOAP server target place cleared...
-
Page 20: Communication Protocols
IE-SNC-P85x1-11 Chapter Communication protocols Short introduction to communication protocols of the device. To use some communication protocols is necessary software, which can use the protocol. This software is not included. Detailed description of protocols and application notes can be found in the manual appendix. Website The device supports displaying of measured values, history graphs and configuration using web browser. -
Page 21: Snmp
IE-SNC-P85x1-11 SNMP Using SNMP protocol you can read actual measured values, alarm status and alarm parameters. Via SNMP protocol is also possible to get last 1000 measured values from history table. Writing via SNMP protocol is not supported. It is supported SNMPv1 protocol version only. -
Page 22: Modbus Tcp
IE-SNC-P85x1-11 Modbus TCP Device supports Modbus protocol for communication with SCADA systems. Device use Modbus TCP protocol. TCP port is set to 502 by default. Port can be changed using TSensor software or web interface. Only two Modbus clients can be connected to device at one moment. -
Page 23: Soap
IE-SNC-P85x1-11 40022 0x9C56 Channel 4 hysteresis Int*10 40023 0x9C57 Channel 4 delay uInt Description: Int*10 registry is in format integer*10 – 16 bits uInt registry range is 0-65535 Ascii character registry is coded as BCD item is not defined, should be read Possible alarm states: no alarm value is lower than set limit... -
Page 24: Syslog
IE-SNC-P85x1-11 </InsertP8xxxSample> </soap:Body> </soap:Envelope> Syslog The device allows sending text message to selected Syslog server. Events are send using UDP protocol on port 514. Syslog protocol implantation is according to RFC5424 and RFC5426. Events when Syslog messages are send: Text Event Sensor - fw 4-5-5.x Reset of the device... -
Page 25: Troubleshooting
IE-SNC-P85x1-11 Chapter Troubleshooting The chapter describes the common problems with P8510 Thermometer, P8511 and P8541 Transducer and methods how to fix these problems. Pleas read this chapter before you will call technical support. I forgot the device IP address IP address is factory set to 192.168.1.213. If you had changed it and forgot new IP address, run the TSensor software and press Find device... -
Page 26: Error Or N/A Is Displayed Instead The Measured Value
IE-SNC-P85x1-11 Follow the software instructions. An alternative is to reset device to factory defaults using factory-defaults jumper. Error or n/a is displayed instead the measured value Value n/a is shown a shortly after device restart. If the error code or n/a is displayed permanently, check if the probes are connected to device correctly. -
Page 27: Technical Specifications
IE-SNC-P85x1-11 Chapter Technical specifications Informations about technical specifications of the device. Dimensions P8510 Thermometer: P8511 Transducer:... -
Page 28: Basic Parameters
±0.5°C in temperature range from -10°C to +80°C ±2.0°C in temperature range from -10°C td -30°C Resolution: 0.1°C 0.1%RH P8510 temperature measurement range: -30°C to +80°C P8511 and P8541 temperature measurement range (limited by range of used probe): -55°C to +80°C Recommended probe for P8511 and P8541:... - Page 29 1000 values for each channel inside non-backup RAM memory Case material: Mounting the device: With two holes at the bottom of the unit Weight: P8510 ~ 130g, P8511 ~ 125g, P8511 ~ 135g EMC emission: EN 55022, Class B EMC resistance: EN 61000-4-2, levels 4/8kV, Class A EN 61000-4-3, intensity of electromagnetic filed 3V/m, Class A EN 61000-4-4, levels 1/0.5kV, Class A...
-
Page 30: Operating Terms
-50°C to +80°C Temperature and humidity range of probe DSRH for P8511 and P8541: 0°C to +50°C, 10 to 90%RH P8510 working position: with sensor cover downwards. When mounting in RACK 19" with universal holder MP046 (accessories) then sensor cover can be placed horizontally. -
Page 31: Optional Accessories
±2°C. Operating temperature range is 0 to +50°C. Probe length 88mm, diameter 18mm, connected to PVC cable with lengths 1, 2 or 5m. Power supply Adapter A1825 Power supply adapter with CEE 7 plug, 100-240V 50-60Hz/5V DC, 1.2A for P8510 Thermometer or P8511 and P8541 Transducer. - Page 32 Device case holder for RACK 19" MP046 MP046 is a universal holder for mounting of P8510 Thermometer and P8511, P8541 Transducer to RACK 19". Probes holder for RACK 19" MP047 Universal holder for easy mounting probes in RACK 19". Database software DBS Sensor monitor Database software DBS Sensor Monitor for online data collection and data analysis from Ethernet sensors.
