- Page 1 COMET SYSTEM www.cometsystem.cz P8610 intelligent thermometer with PoE P8631 intelligent 3-channel transducer with PoE USER MANUAL...
- Page 2 Is prohibited to copy and make any changes in this manual, without explicit agreement of company COMET System, Ltd. All rights reserved. COMET System, Ltd. makes constant development and improvement of their products. Manufacturer reserves the right to make technical changes to the device without previous notice.
-
Page 3: Table Of Contents
IE-SNC-P86xx-01 Table of contents Introduction ................................ 4 General safety rules ............................. 4 Device description and important notices ....................5 Getting started ..............................6 What is needed for operation ........................6 Mounting the device ............................ 6 Device settings ............................. 7 Checking functions ............................9 Device function description ...........................10 Alarm limits ..............................10 Settings using TSensor software ......................11... -
Page 4: Introduction
Ethernet network. Device can be powered from external power supply adapter or by using power over Ethernet – PoE. P8610 Thermometer has compact design and measures the temperature in place of installation. To P8631 Transducer is possible connect up to three probes. Temperature probes are available as accessories. -
Page 5: Device Description And Important Notices
IE-SNC-P86xx-01 The device may be installed only in prescribed areas. Never expose the device higher or lower temperatures than is allowed. The device has not improved resistance to moisture. Protect it from dripping or splashing water and do not use at areas with condensation. Don’t use device in explosive environments. -
Page 6: Getting Started
To install the unit you need to the following equipment. Before installation check if it’s available. P8610 Thermometer or P8631 Transducer power supply adapter 5V/250mA or switch with PoE. Before using the device is necessary to decide which way of powering will be used. -
Page 7: Device Settings
Ethernet (PoE) is not used, connect the power adapter 5V/250mA LEDs on LAN connector should blink after connecting the power P8610 Thermometer connection (power supply adapter, Power over Ethernet): P8631 Transducer connection (power supply adapter, Power over Ethernet): Device settings... - Page 8 IE-SNC-P86xx-01 the window shows all available devices on network click to Change IP address to set new address according to network administrator instructions. If you need to use DHCP server for obtain IP address set 0.0.0.0. If your device is not show, then click Help! My device wasn’t found! Then follow the instructions.
-
Page 9: Checking Functions
IE-SNC-P86xx-01 after changing IP address device is restarted and new IP address is assigned. Restart of the device takes about 10 seconds. connect to device using TSensor software and check the measured values. If P8631 Transducer values are not displayed, it’s necessary to find probes using button Search probes. -
Page 10: Device Function Description
IE-SNC-P86xx-01 Chapter Device function description This chapter describes basic device configuration. There is a description of settings using TSensor software and via Telnet. Alarm limits Alarm limits can be set at bookmark Configuration in TSensor software. For each measurement channel is possible to set upper and lower limits of temperature, time-delay for alarm activation (0 –... -
Page 11: Settings Using Tsensor Software
IE-SNC-P86xx-01 Settings using TSensor software Bookmark Information In bookmark Information are the most important informations about the device. Using switch Protocol you can choose the method of reading current values from the device. Selecting item Modbus connects TSensor software to the Modbus TCP server in the device. -
Page 12: Setup Via Telnet
IE-SNC-P86xx-01 Setup via Telnet Using a text interface Telnet at port 9999 can be the device configured. It is possible to change any settings as well as using TSensor software. The Telnet is good if you need to made configuration from operation system where can not be installed TSensor software (Linux, Mac OS). -
Page 13: Factory Configuration
SNTP synchronization enabled 1400 Turn on all channels Upper limit [°C] Lower limit [°C] Hysteresis – hysteresis for alarm clearing [°C] Delay – time-delay of alarm activation [s] Password to access the settings cleared Device name P8610 sensor or P8631 sensor... -
Page 14: Communication Protocols
IE-SNC-P86xx-01 Chapter Communication protocols Short introduction to communication protocols of the device. To use some communication protocols is necessary software, which can use the protocol. This software is not included. Detailed description of protocols and application notes can be found in the manual appendix. Website The device supports displaying of measured values, limits, alarm status and history graphs on its websites. -
Page 15: Snmp
IE-SNC-P86xx-01 administrator to obtain IP address of SMTP server. For communication with SMTP server is used TCP connection on port 25. E-mail sent by the device can not be answered. SNMP Using SNMP protocol you can read actual measured values, alarm status and alarm parameters. -
Page 16: Soap
IE-SNC-P86xx-01 Modbus device registers. Address could be by 1 higher, depending on type used communication library: Address [DEC] Address [HEX] Value Type 40000 0x9C40 channel 1 temperature Int*10 40001 0x9C41 channel 1 alarm status Ascii 40002 0x9C42 channel 1 upper limit Int*10 40003 0x9C43... -
Page 17: Syslog
IE-SNC-P86xx-01 Syslog The device allows sending text message to selected Syslog server. Events are send using UDP protocol on port 514. Events when Syslog messages are send: Text Event <00001> Device restart Device reboot <00001> SOAP connection error Error sending SOAP messages <00002>... -
Page 18: Troubleshooting
IE-SNC-P86xx-01 Chapter Troubleshooting The chapter describes the common problems with P8610 Thermometer, P8631 Transducer and methods how to fix these problems. Pleas read this chapter before you will call technical support. I forgot the device IP address IP address is factory set to 192.168.1.213. If you had changed it and forgot new IP address, run the TSensor software and press Find device... -
Page 19: Error1 Is Displayed Instead The Measured Value
IE-SNC-P86xx-01 Error1 is displayed instead the measured value Error1 is displayed immediately after start or reboot the device. If the error code is displayed permanently, check if the temperature probe is connected to device correctly. Check if the temperature probes are not at a temperature outside the measuring range and check probes cables. -
Page 20: Technical Specifications
IE-SNC-P86xx-01 Chapter Technical specifications Informations about technical specifications of the device. Dimensions P8610 Thermometer: P8631 Transducer:... -
Page 21: Basic Parameters
±0.5°C in temperature range from -10°C to +80°C ±2.0°C in temperature range from -10°C td -40°C Resolution: 0.1°C P8610 temperature measurement range: -20°C to +60°C P8631 temperature measurement range (limited by temperature range of used probe): -55°C to +80°C Recommended probe P8631: DSTR162/C or DSTGL40/C max. -
Page 22: Operating Terms
-20°C to +60°C, 0 to 100% RH (no condensation) Temperature range of recommended probe DSTR162/C for P8631: -40°C to +80°C P8610 working position: with sensor cover downwards. When mounting in RACK 19" with universal holder MP046 (accessories) then sensor cover can be placed horizontally. -
Page 23: End Of Operation
IE-SNC-P86xx-01 End of operation Disconnect the device and dispose it according to current legislation for dealing with electronic equipment. Electronic devices must be professionally destroyed in accordance with EU Directive 2002/96/ES of 27th January 2003. Technical support and service Technical support and service is provided by distributor. Contact is included in warranty certificate. -
Page 24: Optional Accessories
PVC cable with lengths 1, 2, 5 or 10m. Power supply Adapter A1825 Power supply adapter with CEE 7 plug, 100-240V 50-60Hz/5V DC, 1.2A for P8610 Thermometer or P8631 Transducer. Adapter must be used if the device is not powered by Ethernet cable. -
Page 25: Database Software Dbs Sensor Monitor
IE-SNC-P86xx-01 Database software DBS Sensor monitor Database software DBS Sensor Monitor for online data collection and data analysis from Ethernet sensors. It contains all components for data acquisition from sensors, including a one license DBV Database Viewer. For more informations please visit our webpages www.cometsystem.cz. - Page 26 IE-SNC-P86xx-01...
- Page 27 IE-SNC-P86xx-01...
- Page 28 www.cometsystem.cz...
