- Page 1 LCD Monitor User Manual E719SDA/E719SD LED Backlight www.aoc.com ©2013 AOC.All Rights Reserved...
-
Page 2: Table Of Contents
Safety ..................................4 National Conventions ............................4 Power ................................5 Installation................................6 Cleaning ................................7 Other .................................. 8 Setup ..................................9 Contents in Box ............................... 9 Setup Stand & Base ............................10 ... - Page 3 Regulation ................................53 FCC Notice ..............................53 WEEE Declaration ............................54 EPA Energy Star .............................. 55 EPEAT Declaration ............................56 TCO DOCUMENT ............................57 Service ..................................58 Warranty Statement for North & South America (excluding Brazil) ............60 ...
-
Page 4: Safety
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 5: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 6: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 7: Cleaning
Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. -
Page 8: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 9: Setup
Audio cables) w ill be provided Not al l signal cables s (Analog, DV ill be provided d for all countries and region n s. Please check wit h the local dea aler or AOC b ranch office fo or confirmation... -
Page 10: Setup Stand & Base
Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:... -
Page 11: Adjusting Viewing Angle
Adjusting Viewing Angle For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle. You are able to adjust the monitor's angle as below. -
Page 12: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: E719SD E719SDA Power Audio D-SUB Turn off your computer before performing the procedure below. Connect the power cable to the AC port on the back of the monitor. Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port. -
Page 13: Adjusting
Adjusting Setting Optimal Resolution Windows 8 For Windows 8: Right click and click All apps at the bottom-right of the screen. Set the “View by” to “Category”. Click Appearance and Personalization. - Page 14 Click DISPLAY. Set the resolution to Optimal preset resolution SLIDE-BAR...
-
Page 15: Windows Vista
Windows Vista For Windows Vista: 1 Click START. 2 Click CONTROL PANEL. 3 Click Appearance and Personalization. 4 Click Personalization... - Page 16 5 Click Display Settings. 6 Set the resolution SLIDE-BAR to Optimal preset resolution...
-
Page 17: Windows Xp
Window ws XP For Wind dows XP: 1 Click ST TART. 2 Click SE ETTINGS. 3 Click CO ONTROL PAN NEL. 4 Click Ap ppearance an nd Themes. 5 Double click DISPLAY... -
Page 18: Windows Me/2000
6 Click SE ETTINGS. 7 Set the resolution SL LIDE-BAR to O Optimal preset t resolution Window ws ME/200 For Wind dows ME/2000 1 Click ST TART. 2 Click SE ETTINGS. 3 Click CO ONTROL PAN NEL. 4 Double click DISPLAY 5 Click SE ETTINGS. -
Page 19: Hotkeys
Hotkeys E719SDA E719SD Source/ Auto/ Exit Source/ Auto/ Exit Clear Vision / - Clear Vision / - Volume Menu/Enter Menu/Enter Power Power Power Press the Power button to turn on/off the monitor. Volume / When there is no OSD, press Volume adjust volume. - Page 20 Clear Vision When there is no OSD, Press the “ - ” button to activate Clear Vision. Use the “ - ” or “ + ” buttons to select between weak, medium, strong, or off settings. Default setting is always “off”.
-
Page 21: Osd Setting
OSD Setting Basic and simple instruction on the control keys. Press the MENU-button to activate the OSD window. Press or to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate. Press - or to navigate through the sub-menu. Once the desired function is highlighted, press MENU-button to activate. -
Page 22: Luminance
Luminance 1 Press (Menu) to display menu. 2 Press - or + to select (Luminance), and press to enter. 3 Press - or + to select submenu, and press to enter. 4 Press - or + to adjust. 5 Press to exit Brightness 0-100... -
Page 23: Image Setup
Image Setup 1 Press (Menu) to display menu. 2 Press - or + to select (Image Setup), and press to enter. 3 Press - or + to select submenu, and press to enter. 4 Press - or + to adjust. 5 Press to exit Clock... -
Page 24: Color Setup
Color Setup 1 Press (Menu) to display menu. 2 Press - or + to select (Color Setup), and press to enter. 3 Press - or + to select submenu, and press to enter. 4 Press - or + to adjust. 5 Press to exit Warm... -
Page 25: Picture Boost
Picture Boost 1 Press (Menu) to display menu. 2 Press - or + to select (Picture Boost), and press to enter. 3 Press - or + to select submenu, and press to enter. 4 Press - or + to adjust. 5 Press to exit Frame Size... -
Page 26: Osd Setup
OSD Setup 1 Press (Menu) to display menu. 2 Press - or + to select (OSD Setup), and press to enter. 3 Press - or + to select submenu, and press to enter. 4 Press - or + to adjust. 5 Press to exit H. -
Page 27: Extra
Extra 1 Press (Menu) to display menu. 2 Press - or + to select (Extra), and press to enter. 3 Press - or + to select submenu, and press to enter. 4 Press - or + to adjust. 5 Press to exit Input Select Auto / Analog / DVI... -
Page 28: Exit
Exit 1 Press (Menu) to display menu. 2 Press - or + to select (Exit), and press to enter. 3 Press to exit Exit Exit the main OSD. LED Indicator Status LED Color Full Power Mode Green Active-off Mode Orange... -
Page 29: Driver
Driver Monitor Driver Windows 8 Start Windows® 8 Right click and click All apps at the bottom-right of the screen. Click on the “Control panel” icon Set the “View by” to “Large icons” or “Small icons”. - Page 30 Click on the “Display” icon. Click on the “Change display settings” button. “ Click the Advanced Settings” button. button Click the “Monitor” tab and then click the “Properties”...
- Page 31 Click the “Driver” tab. 10. Open the “Update Driver Software-Generic PnP Monitor” window by clicking on “Update Driver... “ and then click the "Browse my computer for driver software" button. 11. Select "Let me pick from a list of device drivers on my computer".
- Page 32 12. Click the “Have Disk” button. Click on the “Browse” button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). 13. Select the "xxx.inf" file and click the “Open” button. Click the “OK” button. 14.
-
Page 33: Windows 7
Windows 7 Start Windows® 7 Click on the 'Start' button and then click on 'Control Panel'. Click on the 'Display' icon. - Page 34 Click on the “Change display settings” button. “ Click the Advanced Settings” button. button. Click the “Monitor” tab and then click the “Properties”...
- Page 35 Click the “Driver” tab. Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... “ and then click the "Browse my computer for driver software" button. Select "Let me pick from a list of device drivers on my computer".
- Page 36 10. Click the “Have Disk” button. Click on the “Browse” button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). 11. Select the "xxx.inf" file and click the “Open” button. Click the “OK” button. 12.
-
Page 37: Windows Vista
Windows Vista Click "Start" and "Control Panel". Then, double-click on "Appearance and Personalization". Click "Personalization" and then "Display Settings". Click "Advanced Settings...". - Page 38 Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means the configuration for your monitor is completed. The monitor can be used as is. If the message "Windows needs..." is displayed, as shown in the figure below, click "Continue". Click "Update Driver..."...
-
Page 39: Windows Xp
Window ws XP Start Windows® X Click on the 'Start' button and th en click on 'Co ontrol Panel'. Selec ct and click on n the category y ‘Appearance and Themes’ Click on the 'Displa ay' Item. - Page 40 Selec ct the 'Settings s' tab then clic ck on the 'Adv anced' button Selec ct 'Monitor' tab If the 'Proper rties' button is inactive, it me eans your mon nitor is properl ly configured. Please stop in nstallation. If the 'Proper rties' button is s active, click o on 'Properties'...
- Page 41 Selec ct the 'Install f rom a list or s pecific locatio n [advanced]' radio button a and then click on the 'Next' button. Selec ct the 'Don't S earch. I will ch hoose the driv ver to install' ra adio button.
-
Page 42: Windows 2000
Windows 2000 Start Windows® 2000 Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. Double click on the 'Display' Icon. Select the 'Settings' tab then click on 'Advanced...'. Select 'Monitor' If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. If the 'Properties' button is active. -
Page 43: I-Menu
i-Men Welcome to “i-Menu” so oftware by AO OC. i-Menu ma akes it easy to o adjust your m monitor display y setting by us sing on screen me enus instead o of the OSD bu utton on the m monitor. -
Page 44: E-Saver
Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver); the actual shutdown time depends on your preferences (see example below). -
Page 45: Screen
Screen+ Welcome to "Screen+" software by AOC. Screen+ software is a desktop screen splitting tool; it splits the desktop into different panels, and each panel displays a different window. You only need to drag the window to a corresponding pane, when you want to access it. It supports multiple monitor display to make your task easier. -
Page 46: Troubleshoot
Adjust the maximum resolution and frequency that the monitor can handle properly. Make sure the AOC Monitor Drivers are installed. Adjust the Contrast and Brightness Controls. Press for auto adjust. - Page 47 Move electrical devices that may cause electrical interference as far away Picture Bounces, Flickers Or from the monitor as possible. Wave Pattern Appears In The Use the maximum refresh rate your monitor is capable of at the resolution Picture you are using. The Computer Power Switch should be in the ON position.
-
Page 48: Specification
Specification General Specification E719SDA Model name Driving system TFT Color LCD 43.2cm diagonal Viewable Image Size 0.264 (H)mm x 0.264(V)mm Pixel pitch Panel R, G, B Analog lnterface & Digital Interface Video Separate Sync. H/V TTL Display Color 16.7M Colors... - Page 49 General Specification E719SD Model name Driving system TFT Color LCD 43.2cm diagonal Viewable Image Size 0.264 (H)mm x 0.264(V)mm Pixel pitch Panel R, G, B Analog lnterface & Digital Interface Video Separate Sync. H/V TTL Display Color 16.7M Colors Pixel Clock 108MHz Horizontal scan range 30 kHz - 83 kHz...
-
Page 50: Preset Display Modes
Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY(kHZ) FREQUENCY(Hz) 640×480@60Hz 31.469 59.940 640×480@72Hz 37.861 72.809 640×480@75Hz 37.500 75.000 SVGA 800×600@56Hz 35.156 56.250 SVGA 800×600@60Hz 37.879 60.317 SVGA 800×600@72Hz 48.077 72.188 SVGA 800×600@75Hz 46.875 75.000 1024×768@60Hz 48.363 60.004 1024×768@75Hz 60.023 75.029 SXGA 1280×1024@60Hz 63.981... -
Page 51: Pin Assignments
Pin Assignments 15-Pin Side of the 15-Pin Side of the Pin Number Pin Number Signal Cable Signal Cable Video-Red Video-Green Ground Video-Blue N.C. N.C. DDC-Serial data Detect Cable H-sync GND-R V-sync GND-G DDC-Serial clock GND-B 24-Pin Color Display Signal 24-Pin Color Display Signal Pin Number Pin Number Cable... -
Page 52: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 53: Regulation
Regulation FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 54: Weee Declaration
E Decla aration Disposal o of Waste Equ ipment by Use ers in Private Household in the European n Union. This symb bol on the pro duct or on its packaging ind dicates that thi is product mus st not be dispo osed of with y your other household... -
Page 55: Epa Energy Star
EPA Energy Star ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, AOC International (Europe) BV and Envision Peripherals, Inc. have determined that this product meets the ENERGY STAR® guidelines for energy efficiency. (FOR EPA CERTIFIED MODELS) -
Page 56: Epeat Declaration
AOC believes in protecting the environment. With a key concern for the conservation of natural resources, as well as landfill protection, AOC announces the launch of AOC monitor’s packaging recycling program. This program is designed to help you discard of your monitor carton and filler materials properly. -
Page 57: Tco Document
TCO DOCUMENT Congratulations! This product is designed for both you and the planet! TCO Development works for sustainable IT - manufacture, use and recycling of IT products reflecting environmental, social and economic responsibility. TCO Certified is a third party verified program, where every product model is tested by an accredited impartial test laboratory. -
Page 58: Service
Three (3) years after the original date of consumer purchase. During this period, AOC International (Europe) B.V. will, at its option, either repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except as *stated below. In the absent of the proof of purchase, the warranty will start 3 months after the date of manufacturing indicated on the product. - Page 59 OF THE INDIVIDUAL UNIT WHOSE DEFECT OR DAMAGE IS THE BASIS OF THE CLAIM. IN NO EVENT SHALL AOC INTERNATIONAL (EUROPE) B.V. BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE OR FACILITIES OR EQUIPMENT, OR OTHER INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
-
Page 60: Warranty Statement For North & South America (Excluding Brazil)
In the United States and Canada contact your Dealer or EPI Customer Service, RMA Department at the toll free number (888) 662-9888. Or you can request an RMA Number online at www.aoc.com/na-warranty. * This limited warranty does not cover any losses or damages that occur as a result of:... - Page 61 ARGENTINA: http://ar.aoc.com/support/warranty BOLIVIA: http://bo.aoc.com/support/warranty CHILE: http://cl.aoc.com/support/warranty COLOMBIA: http://co.aoc.com/warranty COSTA RICA: http://cr.aoc.com/support/warranty DOMINICAN REPUBLIC: http://do.aoc.com/support/warranty ECUADOR: http://ec.aoc.com/support/warranty EL SALVADOR: http://sv.aoc.com/support/warranty GUATEMALA: http://gt.aoc.com/support/warranty HONDURAS: http://hn.aoc.com/support/warranty NICARAGUA: http://ni.aoc.com/support/warranty PANAMA: http://pa.aoc.com/support/warranty PARAGUAY: http://py.aoc.com/support/warranty PERU: http://pe.aoc.com/support/warranty URUGUAY: http://pe.aoc.com/warranty VENEZUELA: http://ve.aoc.com/support/warranty IF COUNTRY NOT LISTED: http://latin.aoc.com/warranty...
- Page 62 *AOC will need to obtain a credit card number if you would like to get a new AOC monitor advanced shipped to your location, prior to the defective unit arriving at AOC’s service center. If you do not wish to supply a credit card, AOC will only ship the new monitor, once the defective unit arrives at the AOC service center.
