Page 1 of 1
9.4"
(23.8 cm)
Nickel Cadmium Battery
Complete Fixture consists of ballast unit. Select options and accessories below.
Model #
Max. Lumens
FBP750-4P
750
Features
1. Lamp Operation: Operates the following lamp types: T4 Compact Fluorescent
(4-pin base), 13W - 42W twin, quad and triple twin-tube without integral
starter. See Lamp Operation and Performance table for specific lamp perfor-
mance and operation.
2. Illumination: Provides 90 minutes of emergency illumination, and produces a
maximum of 750 lumens initial emergency light output.
3. Housing: Constructed of 20 gauge steel with a high temperature powder
coat finish. Housing allows for frame mounting on most recessed luminaires.
Housing includes 2' lengths of flex conduit attached on each end.
4. Electronics: 120/277 VAC dual voltage input with surge-protected, solid-
state circuitry. Charging system is complete with AC indicator lamp and test
switch.
5. Battery: Maintenance free, sealed nickel cadmium battery has an estimated
service life of 10 years, and an operating temperature range of 32°F (0°C) to
131°F (55°C)
6. Input Power Requirements: 3.5 watts max.
7. Warranty: Electronics: 2 years; Battery: 2 years.
Code Compliance
UL 924 listed. UL damp location listing optional.
Options
EX = Special Input Transformer for 220 VAC/50 Hz, 240 VAC/50Hz. Contact
factory for other input voltages and frequencies.
DL = UL Damp Location Listing
Accessories
CCAPS = Wire bundle cover for mounting external to luminaire.
RT = Remote Test Switch.
Lightolier is a Philips group brand
FBP Series Fluorescent Emergency Ballast
One or Two Lamp Operation 4-Pin Fluorescent Lamps 750 Lumens
1.5"
(3.8 cm)
2.4"
(6.1 cm)
Lamp Operation
One or Two 4-Pin Fluorescent (without integral starter)
Lamp Operation and Performance
Lamp
Type
F13DBX/4P
F18DBX/4P
F26DBX/4P
F18TBX/4P
F26TBX/4P
F32TBX/4P
F42TBX/T4
F18BX
F27/24BX/RS 27
F39/36BX/RS 39
F40/30BX/RS 40
F382D/4P
Notes:
1. Maximum non-emergency lumen output can vary based on lamp manufacturer, ambient operating
2. Maximum emergency lumen output is based on total output of one or two lamps, and can vary
3. Maximum emergency lumen output is supported for a full 90 minutes of operation.
4. Consult factory for compatibility, operation and performance of lamp types not listed.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • D0308
Non-Emer. Emer. Op.
Max.
Base
Lumen
Watt.
Type
Output
13
G24Q-1
900
18
G24Q-2
1150
26
G24Q-3
1710
18
GX24Q-2
1200
26
GX24Q-3
1800
32
GX24Q-3
2200
42
GX24Q-4P
3200
18
2G11 4 Pin
1250
2G11 4 Pin
1800
2G11 4 Pin
2850
2G11 4 Pin
3150
38
GR10Q-4
2850
temperature, and ballast manufacturer.
based on lamp manufacturer and ambient operating temperature.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
FBP750-4P
Max.
Emer
Lumen
Lamp
Output
Operation
425
One or Two
575
One or Two
700
One or Two
525
One or Two
725
One or Two
750
One or Two
750
One
400
One or Two
550
One or Two
750
One or Two
650
One
650
One or Two
Type:
