Lightolier Task Lighting F7100 Specification Sheet

Page 1 of 2
Ordering Information
F 7 1 2 3
Style Lamps Length
F71 = Rectangle 2 = Lamps 3 = 3 Foot
Example = F7123712ALF
Features
Housing: High purity extruded aluminum, a portion from recycled material.
F7100: Rectangular shape.
Housing end: Die-cast aluminum, welded to the housing.
Finish: Powder coat baked enamel. Standard colors: white or aluminum.
Shielding: Perforated pierced pattern louver.
Lamp: 2x39 watt T5HO lamps (included).
Ballast: Electronic and meets ANSI starting, end of life protection, THD and
sound rating specifications.
Switching: On/off switch on stem. Optional cord switch available.
Wiring: 3-wire cord with grounded low profile plug. Minimum length 9 feet.
Listing: UL/cUL listed.
6 3/4"
171mm
1
Wattage Voltage Type
7 = 39W 1 = 120V 1 = Solid
8 = 39W 2 = Pattern
Dimming Pierced
1 5/8"
41mm
Color Mounting
AL = Aluminum F = Floor Stand
WH = White P = Panel Bolt-on
E = Expandable Bracket
B = Binder Bin
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • A0107
F7100
Task Lighting
Portable Ambient
6.750
1.932
1.557
1.750
2. Pattern Pierced
Type:
www.lightolier.com
