EZ-EYE User Guide – Setup,
Configuration, Usage
External Configuration -
The EZ-EYE unit has two external dip switches which control
the video mode and recording mode of the unit. These switches should be configured to the
desired settings prior to connecting and powering on the unit.
NTSC – PAL : This switch controls the video format the unit is displaying in. For North American
television sets the 'NTSC' mode is used. PAL mode is used primarily in European and African
sets. If the wrong video mode is used then you may experience poor video quality, loss of color,
off-center images or other similar video issues.
Full Stop – Overwrite : This switch controls the recording mode of the camera. When set to
'Full Stop', the unit will record until the memory is full then stop recording until it is cleared. The
unit will not record until the memory has been erased using the camera menu. When set to
'Overwrite', the camera will record constantly and when the memory is full it will overwrite the
oldest images with new ones.
Once the EZ-EYE unit has been configured using the dip switches , configuration must be done
within the camera menu. To access the menu, you must first connect the camera to a television
set using the provided RCA video cable. Simply run the cable from the Video Out port on the
back of the camera, to the yellow Video In port on your Television. After that, switch your
camera on. If you do not see an image from the camera then you may need to change the input
on your Television (Most commonly done using a 'Input', 'Source', or 'TV/VCR' button on your
remote control) until you do. See your TV's user manual for more information on changing your
TV's input.
Live View Display –
The image that appears on the screen when the camera is
connected to your TV is the Live View. On this screen you can see exactly what the camera
sees. Across the top and bottom of the display are translucent bars which display information
about the system. Across the top the current date and time will be shown. The format that this
date and time appears in can be configured within the camera's menu.
At the bottom of the screen you will see the recording bar. This will have the following items
displayed :
www.ezwatchstore.com
Advertisement
Table of Contents
Related Manuals for EzwatchPro EZ-EYE
Summary of Contents for EzwatchPro EZ-EYE
- Page 1 ‘Overwrite’, the camera will record constantly and when the memory is full it will overwrite the oldest images with new ones. Once the EZ-EYE unit has been configured using the dip switches , configuration must be done within the camera menu. To access the menu, you must first connect the camera to a television set using the provided RCA video cable.
- Page 2 Camera Menu – The EZ-EYE camera menu is used to configure the recording features and control the capabilities of the camera. To access the menu, simply press the ‘Menu’ button on the back of the unit. You can navigate the menu by using the Up (Record) and down (Play) buttons on the back of the unit, and use the + (Fast Forward) button to enter an option.
- Page 3 SET MOTION DETECT – This option allows you to configure the sensitivity of the Motion Detection of the unit. On the screen you will see a white bar with a red line through it – this bar shows you how much ‘energy’ is on the screen. MD Energy represents how much motion is being seen on the screen.
- Page 4 Schedule Record -> Continue Record – This option allows you to enter a schedule for the camera to record constantly and not based on motion. The settings are the same for entering in the date, time, and quality as on the previous menu. Because the camera records constantly, there is no ‘Duration’.
- Page 5 settings and scheduled time is controlled within the ‘Schedule Record -> Continue Record’ section of the camera menu. Whenever the camera is recording, whether by motion, manual, or continuous the ‘Rec’ light on the back of the unit will stay lit. When the camera is not recording (Either the schedules are off and manual recording is off, or if it is on Motion Detection and not currently seeing any motion) then the REC light will be off.
- Page 6 Insert a blank tape, and press ‘Record’ on your VCR. Then play back the recording you wish to make a copy of using the EZ-EYE unit. As the camera plays the recording, the VCR will copy it onto tape. Once you are done, stop the VCR.
-
Page 7: Recording Times
Recording Times – All times based on constant recording. Recording times on Motion Detection may vary depending on conditions. 1-Gig Unit 2-Gig Unit 4-Gig Unit 8-Gig Unit High Resolution ~7 Hours ~ 14 Hours ~ 28 Hours ~56 Hours 640x480 HQ Low Resolution ~28 Hours ~56 Hours...
