EzwatchPro EZDOME-VP User Manual

DIGITAL VIDEO CAMERA

User's Manual
SKU# EZDOME-VP SKU# EZDOME-VP
Vandal-Proof Night Vision Camera w/ Wall Mount
WARNING WARNING
Attention:
reduce the danger of electric shock, please do not open the case (or back cover) of
camera; everything needed for user operation is on the surface of the camera; camera; everything needed for user operation is on the surface of the camera;
please seek help from a qualified professional for repair.
Attention items:
• Do not touch CCD or lens
• Please ensure correct voltage on power supply
• Avoid installation in unstable places • Avoid installation in unstable places
• Do not use camera in the following conditions,
Temperature: -20⁰C/+50⁰C
• Suggested mounting height 8'-12'
• Do not mount camera directly to a metal surface
• Do not point camera directly into light sources
Image Sensor
Effective Pixels
Sensor area
To
Signal system
resolution resolution
illumination
Auto:1/50(1/60)-1/100,000Sec
>48dB
Lens
Video output
Power supply Power supply
Power consumption
Operating Temperature
1/3" SONY EXVIEW HAD CCD
PAL:500(H)x582(V) NTSC:510(H)x492(V)
4.9mmx3.7mm
PAL/NTSC
420TVL 420TVL Minimum Minimum
0.0LUX Electronic shutter
S/N ratio
Gamma
3.6mm Wide Angle
1.0Vp-p, 75Ω
DV 12V±10% DV 12V±10%
150mA Daytime, 500mA Night
-10⁰C-+50⁰C
Horizontal
0.45
