Page 2: Table Of Contents
Manual heating and air conditioning Dual automatic temperature control Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Moon roof 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 3 Reverse sensing system Rear-view camera system Roadside Emergencies Getting roadside assistance Hazard flasher control Fuel pump shut-off switch Fuses and relays Changing tires Wheel lug nut torque Jump starting Wrecker towing 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 5: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 6 Drive your new vehicle at least 1,000 miles (1,600 km) before towing a trailer. For more detailed information about towing a trailer, refer to Trailer towing in the Tires, Wheels and Loading chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 7 Your vehicle is not equipped with a snowplowing package. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. 2011 Escape (204) Owners Guide, 2nd Printing...
Page 8 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 9 EDR. Ford Motor Company and Ford of Canada do not access event data recorder...
Page 10 Introduction Ford or its vendors to receive this information, do not activate the service. Ford Motor Company and the vendors it uses to provide you with this information do not store your vehicle travel information. For more information, see Traffic, Directions and Information, Terms and Conditions.
Page 11 Brake Fluid - Parking Aid System Non-Petroleum Based Stability Control System Speed Control Master Lighting Switch Hazard Warning Flasher Fog Lamps-Front Fuse Compartment Fuel Pump Reset Windshield Wash/Wipe Windshield Rear Window Defrost/Demist Defrost/Demist 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 12 Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Service Engine Soon Engine Air Filter Passenger Compartment Jack Air Filter Low Tire Pressure Check Fuel Cap Warning 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 13: Instrument Cluster
Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 14: Check Fuel Cap
Easy Fuel “no cap” fuel system in the Maintenance and Specification chapter. If CHECK FUEL FILL INLET is displayed in the message center, refer to Message center in the Instrument cluster chapter for more information. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 15 A Belt-Minder chime will also sound to remind you to fasten your safety belt. Refer to the Seating and Safety Restraints chapter to activate/deactivate the Belt-Minder chime feature. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 16 (TPMS) in the Tires, Wheels and Loading chapter. Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 17 Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 18: Gauges
(except PARKING BRAKE ENGAGED while parked) appears in the message center display for the first time. GAUGES Base instrument cluster shown in standard measure. Metric similar. x 1000 km/h 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 19 (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 20 Odometer: Registers the total miles (kilometers) of the vehicle. If equipped with a message center, refer to Message center in this chapter on how to switch the display from Metric to English. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 21: Message Center
Refer to UNITS later in this section to switch the display from Metric to English. MYKEY MILES (km) (if programmed) For more information, refer to MyKey™ in the Locks and Security chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 22 For more information refer to Essentials of good fuel economy in the Maintenance and Specifications chapter. MPG (L/km) This displays instantaneous fuel economy as a bar graph ranging from ↓ poor economy to ↑ excellent economy. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 23 OIL LIFE This displays the remaining oil life. An oil change is required whenever indicated by the message center and according to the recommended maintenance schedule. USE ONLY RECOMMENDED ENGINE OILS. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 24 R (Reverse) gear is selected. Press the RESET button to turn it off or on. CREATE MYKEY / MYKEY SETUP / CLEAR MYKEY For more information refer to MyKey™ in the Locks and Security chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 25 PASSENGER DOOR AJAR — Displayed when the passenger side door is not completely closed. REAR LEFT DOOR AJAR — Displayed when the rear left door is not completely closed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 26 OIL CHANGE REQUIRED — Displayed when the oil life left reaches MYKEY ACTIVE DRIVE SAFELY — Displayed at startup when MyKey™ is in use. Refer to MyKey™ in the Locks and Security chapter for more information. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 27 Refer to Active park assist in the Driving chapter for more information. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 28 REMOVE HANDS PUT IN REVERSE (if equipped) — May display when using the active park assist system. See Active park assist in the Driving chapter for more information. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 29 Driving chapter for more information. ACTIVE PARK DEACTIVATED (if equipped) — Displayed when the active park feature has been turned off. Refer to Active park assist in the Driving chapter for more information. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 30: Entertainment Systems
AM/FM single CD/MP3 satellite compatible sound system WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 31 AM/FM1/FM2. To activate the autoset feature: Press MENU repeatedly until AUTO PRESET ON/OFF appears in the display. Use SEEK/TRACK 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 32 NO DISC will appear in the display. LOAD: This control is not operational. To load a CD, simply insert the disc, label side up, into the CD slot. EJECT: Press EJECT to eject the CD. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 33 Use SEEK/TRACK to switch between ON/OFF. When COMPRESSION is ON, the system will bring the soft and loud CD passages together for a more consistent listening level. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 34 SCAN: Press SCAN for a brief sampling of all available SIRIUS satellite channels. If a specific category is selected, (Jazz, Rock, News, etc.) press SCAN for a brief sampling of all available SIRIUS satellite channels within the selected category. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 35 (If you try to save something other than a song, CANT SAVE will appear in the display.) When the chosen song is playing on any satellite radio channel, the system will alert you with 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 36 LOCK/UNLOCK THIS CHANNEL is displayed and the display will read ENTER PIN. Enter your four-digit PIN number (initial PIN is 1234) and the system will lock/unlock the channel and CHANNEL LOCKED or UNLOCKED will be displayed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 37 Recommended level is 1–3; SPEED OFF turns the feature off and level 7 is the maximum setting. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 38: Auxiliary Input Jack (Line In)
Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 39 6. Press AUX on the vehicle radio repeatedly until LINE, LINE IN or SYNC LINE IN appears in the display. You should hear audio from your portable music player although it may be low. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 40: Usb Port
USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 41 • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 42 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
Page 43 .mp3 file extension) and all folders containing MP3 files, from F001 (folder) T001 (track) to F253 T255. • Creating discs with only one level of folders will help with navigation through the disc files. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 44: Satellite Radio Information
• Antenna obstructions: For optimal reception performance, keep the antenna clear of snow and ice build-up and keep luggage and other material as far away from the antenna as possible. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 45 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 46 The system is working properly. NO TEXT Song title Song title information not information not available at this time on available. this channel. The system is working properly. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 47: Navigation System
Your vehicle may be equipped with SYNC , a hands-free communications and entertainment system with special phone and media features. For more information, please refer to the SYNC supplement or to the SYNC section in the Navigation System supplement (if equipped). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 48: Climate Controls
: Distributes air through the instrument panel vents, demister vents, floor vents and rear seat floor vents (if equipped). : Distributes air through the demister vents, floor vents and rear seat floor vents (if equipped). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 49 • To reduce fog build-up on the windshield during humid weather, select (defrost) or (floor/defrost). • To reduce humidity build-up inside the vehicle, do not drive with the system off or with (recirculated air) engaged and A/C off. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 50 5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 51: Dual Automatic Temperature Control
: Distributes air through the windshield defroster vents, demister vents, floor vents and rear seat floor vents. The system will automatically provide outside air to reduce window fogging. Press AUTO to return to full automatic control. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 52 Press the MAX A/C button again for normal A/C operation. 13. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in MAX A/C, (defrost) and (floor/defrost). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 53: Automatic Operation
A/C system. For maximum cooling performance: • Automatic operation: 1. Press AUTO for full automatic operation. 2. Do not override A/C or (recirculated air). 3. Set the temperature to 60°F (16°C). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 54: Rear Window Defroster
This may cause damage to the heated grid lines and will not be covered by your warranty. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 55: Lights
If the windshield wipers are turned on for a brief period of time, the exterior lamps will turn on with the headlamp control in the autolamp position. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 56 The fog lamp indicator light will illuminate. High beams • Push the lever toward the instrument panel to activate. • Pull the lever toward you to deactivate. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 57 • Move the control to the full upright position, past detent, to turn on the interior lamps. • Rotate to full down position (past detent) to prevent interior lamps from illuminating when the doors are opened. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 58 If this edge is not at the horizontal reference line, the beam will need to be adjusted. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 59: Turn Signal Control
• To turn off the dome lamp, rotate the panel dimmer control to the full down position past the detent. Note: When manually in the off position, the dome lamp will not illuminate when the door(s) are opened. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 60 ON position. • the control is in the DOOR position and any door is open. When the control is in the OFF position, it will not illuminate when you open the doors. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 61: Bulb Replacement
Examples of unacceptable moisture (usually caused by a lamp water leak) are: • Water puddle inside the lamp • Large water droplets, drip marks or streaks present on the interior of the lens 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 62 To replace all instrument panel lights - see your authorized dealer Replacing interior bulbs Check the operation of all bulbs frequently. Replacing exterior bulbs Check the operation of all the bulbs frequently. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 63 1. Make sure the headlamp control is in the off position. 2. Open the hood. 3. Reach over the front bolster. 4. Rotate the bulb socket counterclockwise and remove from the lamp assembly. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 64 5. Pull bulb straight out of socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly and rotate clockwise. 7. Carefully install the tail lamp assembly on the vehicle and secure with two screws. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 65 2. Press the lever and carefully pry the license plate lamp assembly (located above the license plate) from the liftgate. 3. Rotate the bulb socket counterclockwise and remove from lamp assembly. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 66 3. Remove the bulb from the lamp assembly by pulling out the bulb while squeezing the upper and lower snap clips at the same time. Install the new bulb in reverse order. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 67: Driver Controls
When the windshield wipers are turned on during daylight, and the headlamp control is in the autolamp position, the exterior lamps will turn on after a brief delay and will remain on until the wipers are turned off. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 68: Steering Wheel Adjustment
3. Push the steering column tilt lever up. This will lock the steering wheel in position. WARNING: Never adjust the steering wheel when the vehicle is moving. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 69 The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 70 5. Continue to press the RESET control until the correct zone appears in the center stack display. 6. The direction will display after the RESET control is released. The zone is now updated. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 71 4. Rear cupholders 5. Small storage trays and (if equipped) an ambient light control switch. WARNING: Use only soft cups in the cupholders. Hard objects can injure you in a collision. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 72 12V DC/180W. If the power point or cigar lighter socket is not working, a fuse may have blown. Refer to Fuses and relays in the Roadside Emergencies chapter for information on checking and replacing fuses. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 73: Power Windows
Allows the driver’s window to open fully without holding the control down. Press the switch completely down to the second detent and release quickly. The window will open fully. Momentarily press the switch to any position to stop the window operation. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 74 Note: A rear center passenger and/or raised rear center headrest (if equipped) may also block the light from reaching the sensor. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 75: Mirrors
Your vehicle is equipped with blind spot mirrors. Refer to Blind spot mirrors in the Driving chapter. Fold-away mirrors Fold the side mirrors in carefully when driving through a narrow space, like an automatic car wash. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 76: Speed Control
SET –: Press to decrease a set speed. RES (Resume): Press to resume a set speed. Setting speed control To set speed control: 1. Press and release ON. 2. Accelerate to the desired speed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 77 SET– to decrease the set speed in 1 mph (1.6 km/h) increments. • Press the brake pedal or the clutch pedal (if equipped) until the desired vehicle speed is reached and press and release SET +. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 78 Press to complete a voice command. For further information on the navigation system, refer to the Navigation System supplement. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 79: Moon Roof
You can move the glass panel of the moon roof back to open or tilt up (from the closed position) to ventilate the vehicle. WARNING: Do not let children play with the moon roof or leave children unattended in the vehicle. They may seriously hurt themselves. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 80 • To close the moon roof from the vent position, press and hold the rear portion of the control until the glass panel stops moving. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 81 Car2U system buttons should be erased for security reasons. Refer to Erasing the Car2U Home Automation System buttons later in this section. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 82 LEDs will flash rapidly for a few seconds then turn off. Any settings should remain as previously set. Rolling code programming Note: Programming the rolling code garage door opener involves time-sensitive actions. Read the entire procedure prior to beginning so 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 83 Immediately (within 1 second) release the button once the garage door moves. When the button is released, the indicator light will begin to blink rapidly until programming is complete. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 84 When a switch is in the up, on, or + position, circle “L.” When a switch is in the middle, neutral, or 0 position, circle “M.” When a switch is in the down, off, or – position, circle “R.” 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 85 6. The indicator light will (begin to) blink rapidly until programming is complete. If your garage door opener does not operate following these steps, repeat Steps 2 through 6. Otherwise, call the toll-free Car2U help line at 1-866-57Car2U (1-866-572-2728). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 86 This device must accept any interference received including interference that may cause undesired operation. Changes and modifications to the Car2U system transmitter by other than an authorized service facility could void authorization to use the equipment. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 87 Do not leave the liftgate or liftgate window open while driving. Doing so could cause serious damage to the liftgate and its components as well as allowing carbon monoxide to enter the vehicle. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 88 Cargo management system (if equipped) The cargo management system consists of two storage compartments located in the floor of the rear cargo area. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 89 Your vehicle may be equipped with factory-installed crossbars. Ford Genuine Accessory crossbars, designed specifically for your vehicle, are also recommended for use with your roof rack system.
Page 90 To remove the cross-bar assembly (if equipped) from the roof rack side rails: 1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable). 2. Slide the cross-bar to the end of the rail. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 91 3. Slide the cross-bar assemblies over the end cap tongue and into the side rails. 4. Tighten thumbwheel at both ends of the cross-bar. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 92: Locks And Security
Note: Your vehicle’s IKTs were issued with a security label that provides important vehicle key cut information. It is recommended that you keep the label in a safe place for future reference. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 93 MyKey™ into the ignition. Turn the ignition on. Use the message center buttons to do the following: 1. Press SETUP until PRESS RESET TO CREATE MYKEY is displayed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 94 4. On any of the menus press RESET to highlight your choice with the <…>. 5. Press SETUP to enter your choice. The next optional setting will be displayed. 6. Repeat Steps 4 and 5 until you are done changing the optional settings. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 95 If you choose to install a remote start system please see your authorized dealer for a Ford approved remote start system. When using a Ford-approved remote start system, the default settings will recognize the remote start system as an additional admin Key with its associated privileges.
Page 96 Refer to Create a MyKey™ section • Vehicle has been started using a remote start system that is programmed as MyKey™. Refer to Using MyKey™ with Remote Start Systems section. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 97 Refer to Using MyKey™ with Remote Start Systems section. • MyKey™ is not being used by the MyKey™ miles does not accumulate intended user. • MyKey™ system has been recently cleared. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 98: Locks
• Through your authorized dealer, or • Performing the power door lock control procedure, or • Performing the keyless entry keypad (if equipped) procedure, or • Performing the message center (if equipped) procedure. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 99 6. Release the 3 • 4. The user should receive a horn chirp to indicate the system has been disabled or a chirp followed by a honk to indicate the system has been enabled. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 100 You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, wait a minimum of 30 seconds before beginning again. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 101 With the key in any ignition position, the driver’s door will automatically unlock if it is locked using the power lock control on the driver’s door panel while the driver’s door is open. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 102 (10 meters). A decrease in operating range could be caused by: • weather conditions, • nearby radio towers, • structures around the vehicle, or • other vehicles parked next to your vehicle. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 103 The turn signal will flash twice to indicate that the vehicle has switched to one step unlocking. Repeat the procedure to switch back to two step unlocking. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 104 Note: The panic alarm will only operate when the ignition is in the off position. Replacing the battery The integrated keyhead transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 105 Illuminated entry The interior lamps, parking lamps and puddle lamps (if equipped) illuminate when the Integrated Keyhead Transmitter or the keyless entry system keypad is used to unlock the door(s). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 106 You can also create your own 5–digit personal entry code. When pressing the controls on the keyless entry keypad, press the middle of the controls to ensure a good activation. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 107 This mode disables the keypad for one minute and the keypad lamp will flash. The anti-scan feature will turn off after: • one minute of keypad inactivity, 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 108: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 109 Replacement of integrated keyhead transmitters (IKT) and coded keys Note: Your vehicle comes equipped with two integrated keyhead transmitters (IKTs). The IKT functions as both a programmed ignition 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 110 • If two previously programmed coded keys are not available, you must take your vehicle to your authorized dealer to have the spare key(s) programmed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 111 To program additional new unprogrammed key(s), wait 20 seconds and then repeat this procedure from Step 1. Note: To program MyKey™ features (if equipped), refer to MyKey™ in this chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 112: Seating And Safety Restraints
• a trimmed energy absorbing foam and structure (1), • two steel stems (2), • a guide sleeve adjust/release button (3), • and a guide sleeve unlock/remove button (4). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 113 For occupants of extremely tall stature, adjust the head restraint to its full up position. WARNING: The adjustable head restraint is a safety device. Whenever possible it should be installed and properly adjusted when the seat is occupied. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 114 For occupants of extremely tall stature, adjust the head restraint to its full up position. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 115 WARNING: Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 116 The control is located on the outboard side of the seat cushion. Press to raise or lower the front portion of the seat cushion. Press to raise or lower the rear portion of the seat cushion. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 117 • Press the button located on the instrument panel to activate. • Press again to deactivate. The heated seats will activate when the ignition is in the on position and the engine is running. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 118 (3), To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 119 Whenever possible it should be installed and properly adjusted when the seat is occupied. To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 120 Folding down second row seats 1. Remove the second row head restraint. See Second row adjustable head restraints in this chapter. Note: Place the head restraint underneath the back of the front seat for storage. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 121 Attach the safety belt web snap button to the quarter trim panel snap button. This will ensure that safety belt does not get caught by staying out of the seat back folding path. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 122 Returning the second row seats to upright position 1. Pull seatback up and into upright position making sure seatback locks into place and the red seat unlatched indicator on release paddle is not visible. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 123 See Second row adjustable head restraints in this chapter. To remove the second row cushion 1. Lift the yellow tab to release the hinges. 2. Pull the cushion to the outboard side of the vehicle. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 124: Safety Restraints
• Restraint system warning light and back-up tone. • The electrical wiring for the airbags, crash sensor(s), safety belt pretensioners, front safety belt usage sensors, driver seat position sensor, front passenger sensing system, and indicator lights. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 125 The system is designed to help protect smaller drivers sitting close to the driver airbag by providing a lower airbag output level. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 126 This information allows your Personal Safety System to tailor the airbag deployment and safety belt pretensioner activation depending upon safety belt usage. Refer to Safety restraints section in this chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 127 If any of these things happen, even intermittently, have the Personal Safety System serviced at an authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 128 3) Never use a single belt for more than one person. WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 129 The shoulder portion of the safety belt should be positioned across the chest. Pregnant women should also follow this practice. See figure below. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 130 In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 131 Failure to replace the belt and retractor assembly could increase the risk of injury in collisions. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 132 Safety belt extension assembly If the safety belt is too short when fully extended, a 9 inch (23 cm) or 12 inch (31 cm) safety belt extension assembly can be added (part 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 133 The Belt-Minder feature uses information from the front passenger sensing system to determine if a front seat passenger is present and therefore potentially in need of a warning. To avoid activating the 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 134 30 seconds, repeating for (5 km/h) and more than approximately five minutes or until 1-2 minutes have elapsed since the safety belts are buckled. the ignition switch has been turned to on... 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 135 I’m not going far 3 of 4 fatal crashes occur within 25 miles (40 km) of home. Belts are uncomfortable Your Ford safety belts are designed to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 136 The driver and front passenger Belt-Minder features can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that: • The parking brake is set • The gearshift is in P (Park) (automatic transmission) 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 137 • After receiving confirmation, the deactivation/activation procedure is complete. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 138: Airbags
WARNING: The National Highway Traffic Safety Administration (NHTSA) recommends a minimum distance of at least 10 inches (25 cm) between an occupant’s chest and the driver airbag module. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 139 Do not modify the front end of the vehicle. WARNING: Additional equipment may affect the performance of the airbag sensors increasing the risk of injury. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 140 Front airbags are designed to inflate in frontal and near-frontal collisions, not rollover, side-impact, or rear-impacts unless the collision causes sufficient longitudinal deceleration. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 141 • Front passenger sensing system. Refer to Front passenger sensing system later in this chapter. • “Passenger airbag off” or “pass airbag off” indicator lamp. Refer to Front passenger sensing system later in this chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 142 • a front passenger takes his/her weight off of the seat for a period of time, Note: When the passenger airbag off light is illuminated, the passenger (seat mounted) side airbag may be disabled to avoid the risk of airbag deployment injuries. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 143 • Restart the vehicle and have the person remain in this position for about two minutes. This will allow the system to detect that person and enable the passenger’s frontal airbag. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 144 Even though the passenger airbag is disabled, the pass airbag off lamp may or may not be illuminated according to the table below. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 145 (if equipped). Check the “passenger airbag off” or “pass airbag off” indicator lamp for proper airbag Status. Failure to follow these instructions may interfere with the front passenger seat sensing system. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 146 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance chapter of this Owner’s Guide.
Page 147 SRS, its fuses or the seat cover on a seat containing an airbag. See an authorized dealer. WARNING: All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 148 Side airbags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 149 If any of these things happen, even intermittently, have the SRS serviced at your authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 150 SRS and Safety Canopy System is provided. WARNING: To reduce risk of injury, do not obstruct or place objects in the deployment path of the inflatable Safety Canopy . 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 151 The Safety Canopy system is designed to active when the vehicle sustains lateral deceleration sufficient to cause the RCM to initiate Safety Canopy inflation or when a certain likelihood of a rollover event is detected by the rollover sensor. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 152 The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system. Refer to Warning lights and chimes in the Instrument Cluster chapter. Routine maintenance of the side airbag is not required. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 153 The feature will continue to operate until the vehicle runs out of power. Disposal of airbags and airbag equipped vehicles (including pretensioners) Contact your authorized dealer as soon as possible. Airbags MUST BE disposed of by qualified personnel. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 154: Child Restraints
Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 155 4 ft 9 in. (1.45 meters) tall, or 80 lb (36 kg). Check your local and state or provincial laws for specific requirements regarding the safety of children in your vehicle. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 156 If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 157 All children are shaped differently. The child height, age and weight thresholds provided are recommendations or the minimum requirements of law. The National Highway Traffic Safety Administration (NHTSA) provides education and 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 158 Seating and Safety Restraints training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
Page 159 LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be properly restrained. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 160 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 161 7. Try to pull the belt out of the retractor to make sure the retractor is in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, repeat Steps 5 and 6. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 162 There should be no more than 1 inch (2.5 cm) of movement for proper installation. 11. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) to make certain the child restraint is properly installed.
Page 163 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 164 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 165 1. Route the child safety seat tether strap over the back of the seat. For vehicles with adjustable head restraints, remove the head restraint first, place under the front seat for storage, and then route the tether strap over the top of the seatback. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 166 If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Child booster seats The belt-positioning booster (booster seat) is used to improve the fit of the vehicle safety belt.
Page 167 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that vehicle lap/shoulder safety belts fit better.
Page 168 • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 169 It is generally best to use a booster seat with lap/shoulder belts in the back seat. Move a child to a different seating location if the shoulder belt does not stay positioned on the shoulder during use. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 170 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 171: Tires, Wheels And Loading
The 4WD system is active all the time and requires no input from the operator. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 172 All other things held equal, a shorter wheelbase may make your vehicle quicker to respond to steering inputs than a vehicle with a longer wheelbase. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 173: Tire Information
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 174 WARNING: The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 175 • Tread area of the tire: Area of the perimeter of the tire that contacts the road when mounted on the vehicle. • Rim: The metal support (wheel) for a tire or a tire and tube assembly upon which the tire beads are seated. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 176: Tire Inflation
Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 177 6. Visually inspect the tires to make sure there are no nails or other objects embedded that could poke a hole in the tire and cause an air leak. 7. Check the sidewalls to make sure there are no gouges, cuts or bulges. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 178 If damage is observed or suspected have the tire inspected by a tire professional. Tires can be damaged during off-road use, so inspection after off-road use is also recommended. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 179 This information is used to contact customers if a tire defect requires a recall. Tire replacement requirements Your vehicle is equipped with tires designed to provide a safe ride and handling capability. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 180 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
Page 181 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system.
Page 182 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 183 In general, the larger the number, the wider the tire. 3. 65: Indicates the aspect ratio which gives the tire’s ratio of height to width. 4. R: Indicates a “radial” type tire. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 184 “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 185 The cold inflation pressure should never be set lower than the recommended pressure on the vehicle label. The tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 186 4. Maximum Load Single lb (kg) at psi (kPa) cold: Indicates the maximum load and tire pressure when the tire is used as a single; defined as two tires (total) on the rear axle. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 187 B-Pillar or the edge of the driver’s door. Refer to the payload description and graphic in the Vehicle loading – with and without a trailer section. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 188: Tire Pressure Monitoring System (Tpms)
TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 189 The tire pressure should be checked periodically (at least monthly) using an accurate tire gauge, refer to Inflating your tires in this chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 190 It can also warn you in the event the system is no longer capable of functioning as intended. Please refer to the following chart for information concerning your tire pressure monitoring system: 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 191 TPMS If your tires are properly malfunction inflated and your spare tire is not in use and the light remains on, contact your authorized dealer as soon as possible. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 192 If the low tire pressure warning light is on, visually check each tire to verify that no tire is flat. (If one or more tires are flat, repair as necessary.) Check air pressure in the road tires. If any 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 193: Vehicle Loading
SNOW TIRES AND CABLES WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 194 Once you have reached the maximum payload of your vehicle, do not add more cargo, even if there is space available. Overloading or improperly loading your vehicle can contribute to loss of vehicle control and vehicle rollover. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 195 GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 196 The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The GVW must never exceed the GVWR. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 197 WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 198 GVWR and GAWR limitations. Replacement tires with a higher limit than the original tires do not increase the GVWR and GAWR limitations. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 199 2 years. Measuring the inside of the vehicle with the rear seat folded down, you have room for 12-100 lb. (45 kg) bags of cement. Do you have enough load capacity 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 200: Trailer Towing
Trailer towing puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 201 WARNING: Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 202 Always connect the trailer’s safety chains to the hook retainers on the vehicle. To connect the trailer’s safety chains, cross the chains under the trailer tongue and allow slack for turning corners. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 203 • Use the grade assist feature (automatic transmissions) when towing. This feature provides engine braking and helps eliminate excessive shifting for optimum fuel economy and transmission cooling. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 204: Recreational Towing
(such as behind a motor home or a truck). Note: Put your climate control system in recirculated air mode to prevent exhaust fumes from entering the vehicle. Refer to the Climate Controls chapter for more information. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 205 With the engine running and your foot on the brake, shift into D (Drive) and then into R (Reverse) before shifting back into N (Neutral). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 206: Driving
WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 207 Seating and Safety Restraints chapter. 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: • Make sure the parking brake is set. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 208 • Press and hold the clutch pedal to the floor and put the gearshift lever in N (Neutral). 3. Turn the key to 3 (on) without turning the key to 4 (start). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 209 (-18°C to 0°C), you may experience increased cranking times, rough idle or hesitation until the engine has warmed up. You may experience a decrease in peak performance when the engine is cold when operating on E ethanol. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 210 If your vehicle is equipped with this system, your equipment includes a heater element which is installed in your engine block and a wire harness which allows 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 211 • Be sure that areas where the vehicle is parked are clean and clear of all combustibles such as petroleum products, dust, rags, paper and similar items. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 212: Brakes
Brake dust can be cleaned by weekly washing with soapy water and a soft sponge. Heavier deposits can be removed with Motorcraft Wheel and Tire Cleaner (ZC-37–A). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 213 Turn the engine off, shift to P (Park) and apply the parking brake, and then inspect the accelerator pedal for any interferences. If none are found and the condition persists, have your vehicle towed to the nearest dealer. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 214 Since the parking brake applies only the rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 215: Advancetrac
AdvanceTrac with RSC sensors. Reducing the effectiveness of the AdvanceTrac with RSC system could lead to an increased risk of loss of vehicle control, vehicle rollover, personal injury and death. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 216 Note: If the system cannot be turned off, refer to MyKey™ in the Locks and Security chapter for more information. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 217 See the Switching off traction control section below. Electronic stability control (ESC) Electronic stability control (ESC) may enhance your vehicle’s directional stability during adverse maneuvers, for example when cornering severely 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 218 This will restore full engine power and will enhance momentum through the obstacle. To switch off the traction control, press the traction control off button. Full features of the stability control system 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 219 AdvanceTrac with RSC system to detect and attempt to mitigate trailer sway by applying brake force at individual wheels and, if necessary, by reducing engine power. No driver action is required. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 220 WARNING: Turning off trailer sway control increases the risk of loss of vehicle control, serious injury, or death. Ford does not recommend disabling this feature except in situations where speed reduction may be detrimental (e.g., hill climbing), the driver has significant trailer towing experience, and can control trailer sway and maintain safe operation.
Page 221 Avoid sharp turns, excessive speed or abrupt maneuvers in these vehicles. Failure to drive cautiously could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 222 Note: For some markets, this feature will be disabled. If the fuse is not blown, perform the following procedure: 1. Apply the parking brake, turn the ignition to off, then remove the key. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 223: Transmission Operation
This feature is designed to increase durability and provide consistent shift feel over the life of the vehicle. A new vehicle or transmission may have firm and/or soft shifts. This operation is 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 224 R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 225 To return to normal D (Drive) position (with O/D), press the transmission control switch again. • The grade assist lamp in the instrument cluster will not be illuminated. • The transmission will operate in gears one through six. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 226 Make sure the floor mat is properly positioned so it doesn’t interfere with the full extension of the clutch pedal. Failure to fully press the clutch pedal to the floor may cause increased shift efforts, prematurely wear transmission components or damage the transmission. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 227 R (Reverse) again. Parking your vehicle 1. Apply the brake and shift into the neutral position. 2. Fully apply the parking brake, hold the clutch pedal down, then shift into 1 (First). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 228: Reverse Sensing System
WARNING: Certain add-on devices such as large trailer hitches, bike or surfboard racks and any device that may block the normal detection zone of the RSS system may create false beeps. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 229 RSS. If your vehicle sustains damage to the rear bumper/fascia, leaving it misaligned or bent, the sensing zone may be altered causing inaccurate measurement of obstacles or false alarms. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 230: Rear-View Camera System
5 mph (8 km/h), only if the rear camera delay feature is on, or until any navigation radio button is pressed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 231 If either of the lamps are not operating, stop using the camera, at least in the dark, until the lamp(s) are replaced and functioning. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 232 >> and << in the message center indicate on which side of the vehicle APA will park. If the turn signal is not on, the system will automatically search the passenger side. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 233 You may cancel APA at anytime by grabbing the steering wheel or by pressing the APA control switch. When the vehicle is in R (Reverse), the message center displays BACK UP USE CAUTION. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 234 The system can also be deactivated at any time by the following: • Pressing the APA control switch • Grabbing the steering wheel • Exceeding a vehicle speed of 18 mph (30 km/h) for 30 seconds during active park searching 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 235 • The vehicle is driven too close to the side objects (e.g. less than 16 inches [41 cm] from neighboring parked vehicles). • You may be driving in R (Reverse). APA can only look for a parking space while moving forward. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 236 They are designed to assist the driver by increasing visibility along the side of the vehicle. For more information on your side view mirrors, refer to Exterior mirrors in the Driver Controls chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 237 The 4WD system is always active and requires no driver input. It is capable of handling all road conditions, including street and highway driving as well as off-road and winter driving. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 238 • It often may be less risky to strike small objects, such as highway reflectors, with minor damage to your vehicle rather than attempt a sudden return to the pavement which could cause the vehicle to slide 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 239 See your authorized dealer. WARNING: Do not spin the wheels at over 35 mph (56 km/h). The tires may fail and injure a passenger or bystander. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 240 Remember, you may be able to back out the way you came if you proceed with caution. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 241 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 242 Should you start to slide while driving on snowy or icy roads, turn the steering wheel in the direction of the slide until you regain control. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 243 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 244 Once through the water, always dry the brakes by moving your vehicle slowly while applying light pressure on the brake pedal. Wet brakes do not stop the vehicle as quickly as dry brakes. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 245: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 246: Hazard Flasher Control
Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles (56 km). To obtain reimbursement information, U.S.
Page 247: Fuses And Relays
Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 248: Passenger Compartment Fuse Panel
Remove the panel cover to access the fuse cover. Press the tabs on the top and bottom of the fuse cover to remove. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 249 Turn signals, Stop lamps Low beam headlamps (left) Low beam headlamps (right) Interior lights Backlighting Four wheel drive 7.5A Power mirror switch Not used (spare) FCIM (radio buttons), Front display module, GPS module 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 250 Four wheel drive, Electric power assist steering (EPAS), Park aid module, Active park assist module Passive anti-theft system (PATS) transceiver Climate control Subwoofer/Amp (premium radio) Radio, Radio amplifier (navigation only) Front power point 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 251: Power Distribution Box
WARNING: Always disconnect the battery before servicing high current fuses. WARNING: To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 252 – keep alive power, PCM relay, Canister vent 15A* Alternator 15A* Liftgate latch 20A* Trailer tow parking lamps 50A** Anti-lock brake system (ABS) 30A** Front wipers 30A** Starter 40A** Blower motor 10A* A/C clutch 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 253 Cooling fan main relay — Cooling fan 2 relay — Reverse lamp relay — Not used — Trailer tow left turn relay — Trailer tow right turn relay — Trailer tow park relay 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 254: Changing Tires
(TPMS) and should not be used. However, if you must use a sealant, the TPMS sensor and valve stem on the wheel must be replaced by an authorized Ford dealer. WARNING: Refer to Tire pressure monitoring system (TPMS) in the Tires, Wheels and Loading chapter for important information.
Page 255 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 256 • Driving vehicles equipped with a camper body • Driving vehicles with a load on the cargo rack Drive cautiously when using a full-size dissimilar spare tire/wheel and seek service as soon as possible. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 257 3. Unbuckle the strap and remove the jack and tools by pulling the right side up first. 4. Remove the tools from the jack in order to remove the spare tire from under the vehicle. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 258 3. Slide the retainer through the center of the wheel. If equipped with a tether, perform the following additional steps: 4. Lift the spare tire on end to access tether attachment (1). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 259 (other side and end of the vehicle) to the tire being changed. WARNING: If the vehicle slips off the jack, you or someone else could be seriously injured. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 260 2. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Before placing the jack under the vehicle, NOTE the jack locations: 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 261 View shown from rear of front tire. Position the jack directly below the protruding bolt. • Rear View shown from forward of rear tire. Position the jack directly below the stud on the rear trailing arm. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 262 Reinstall lug nuts until the wheel is snug against the hub. Do not fully tighten the lug nuts until the wheel has been lowered. 6. Lower the wheel by turning the jack handle counterclockwise. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 263 If you are stowing a tire that requires reattaching it to the vehicle with a tether, perform these steps first, then proceed with the steps following. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 264 7. Repeat this tightness check procedure (every six months, per scheduled maintenance information), when servicing the spare tire pressure or at any time that the spare tire is disturbed through service of other components. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 265: Wheel Lug Nut Torque
M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 266: Jump Starting
4. Check all battery terminals and remove any excessive corrosion before you attach the battery cables. Ensure that vent caps are tight and level. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 267: Connecting The Jumper Cables
Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 268: Removing Jumper Cables
After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 269: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. On FWD vehicles, if your vehicle is to be towed from the front, ensure proper wheel lift equipment is used to raise the front wheels off the ground.
Page 270 Roadside Emergencies Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. If the vehicle is towed by other means or incorrectly, vehicle damage may occur.
Page 271: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 272 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 273 You are required to submit your warranty dispute to BBB AUTO LINE before asserting in court any rights or remedies conferred by California Civil Code Section 1793.22(b). You are also required to use BBB AUTO 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 274 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step procedure outlined on the first page of the Customer Assistance section, you may be eligible to participate in the BBB AUTO LINE program.
Page 275 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 276 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 277 If you buy your vehicle in North America and then relocate to any of the above locations, register your vehicle identification number (VIN) and new address with Ford Motor Company Export Operations & Global Growth Initiatives by emailing expcac@ford.com. If you are in another foreign country, contact the nearest authorized dealer.
Page 278: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 279: Cleaning
• Never use abrasive materials such as steel wool or plastic pads as they can scratch the chrome surface. WAXING • Wash the vehicle first. • Use a quality wax that does not contain abrasives. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 280 • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage. • Do not spray a hot engine with cold water to avoid cracking the engine block or other engine components. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 281 • Never wash or rinse any ignition coil, spark plug wire or spark plug well, or the area in and around these locations. 2.5L I4 ENGINE 3.0L V6 ENGINE 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 282 Do not use sharp objects, such as a razor blade, to clean the inside of the rear window or to remove decals, as it may cause damage to the rear window defroster’s heated grid lines. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 283 4. Remove the soaked cloth, and if it is not soiled badly, use this cloth to clean the area by using a rubbing motion for 60 seconds. 5. Following this, wipe area dry with a clean, white, cotton cloth. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 284 • To check for compatibility, first test any cleaner or stain remover on an inconspicuous part of the leather. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 285 Ranch Saddle Shop. Visit the website at www.krsaddleshop.com, or telephone (in the United States) 1–800–282–KING (5464). If you are unable to obtain King Ranch Leather Conditioner, use another premium leather conditioner. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 286 FORD AND LINCOLN CAR CARE PRODUCTS Your Ford or Lincoln authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 287: Maintenance And Specifications
WARNING: To reduce the risk of vehicle damage and/or personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 288: Engine Compartment
2. Engine oil filler cap 7. Battery 3. Automatic transmission dipstick 8. Engine coolant bleed valve (if equipped) 9. Engine oil dipstick 4. Brake/Clutch fluid reservoir 10. Windshield washer fluid 5. Air filter assembly reservoir 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 289 3. Brake fluid reservoir 4. Automatic transmission fluid dipstick 5. Power distribution box 6. Battery 7. Coolant bleed valve 8. Engine oil dipstick 9. Engine oil filler cap 10. Windshield washer fluid reservoir 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 290 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 291 The layer of ice has many sharp edges and can damage the micro edge of the wiper rubber element. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 292: Engine Oil
3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmissions) or 1 (First) (manual transmissions). 4. Open the hood. Protect yourself from engine heat. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 293 • If the oil level is below the lower hole or the lower line, engine oil must be added to raise the level within the normal operating range. • 2.5L I4 engine 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 294 1/4 of a turn until it is seated. To avoid possible oil loss, DO NOT operate the vehicle with the engine oil level dipstick and/or the engine oil filler cap removed. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 295 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine and engine’s warranty, use Motorcraft SAE 5W-20 or an equivalent SAE 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 296: Battery
Lift the battery with a battery carrier or with your hands on opposite corners. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 297 If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 298: Engine Coolant
• The engine coolant should be at the FULL COLD level, or within the COLD FILL or MIN / MAX range as listed on the engine coolant reservoir (depending upon application). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 299 50/50 mixture of engine coolant and distilled water as soon as possible. Water alone (without engine coolant) can cause engine damage from corrosion, overheating or freezing. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 300 Checking engine coolant). If the concentration is not 50/50 (protection to –34°F/–37°C), drain some coolant and adjust the concentration. It may take several drains and additions to obtain a 50/50 coolant concentration. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 301 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
Page 302 Once the engine temperature cools, the engine can be re-started. Take your vehicle to an authorized dealer as soon as possible to minimize engine damage. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 303: Fuel Information
WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions WARNING: Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 304 Repeated or prolonged skin contact with fuel liquid or vapor causes skin irritation. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 305 Never smoke while refueling. Fuel vapor is extremely hazardous under certain conditions. Care should be taken to avoid inhaling excess fumes. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 306 The Easy Fuel™ system is self-sealing and protected against dust, dirt, water and snow/ice. When fueling your vehicle: 1. Turn the engine off. 2. Open the fuel filler door. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 307 If your vehicle is flex fuel capable, it will have a yellow bezel placed over the fuel fill inlet. Choosing the right fuel If your vehicle is a flexible fuel vehicle (FFV), use only UNLEADED FUEL and FUEL ETHANOL (Ed75–Ed85). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 308 5 miles (8 km) to allow the vehicle to adapt to the change in ethanol concentration. If you exclusively use E85 fuel, it is recommended to fill the fuel tank with regular unleaded gasoline at each scheduled oil change. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 309 Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 310 When filling the vehicle’s fuel tank from a portable fuel container, use the funnel included with the vehicle. 1. Locate the white plastic funnel. It is attached to the inside of the rear passenger side cargo compartment access door. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 311 Empty reserve is the small amount of fuel remaining in the fuel tank after the fuel gauge indicates empty. The amount of usable fuel in the empty reserve varies and should not be relied upon to increase driving range. When refueling your 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 312 Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 313 • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed. • Carrying unnecessary weight may reduce fuel economy (approximately 1 mpg [0.4 km/L] is lost for every 400 lb [180 kg] of weight carried). 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 314 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 315 4. Driving through deep water—the electrical system may be wet. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel, properly closing the fuel fill inlet or letting the 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 316 15 minutes of steady driving on an expressway/highway followed by 20 minutes of stop-and-go driving with at least four 30-second idle periods. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 317 30 minutes to allow fluid to cool before checking. 1. Drive the vehicle 20 miles (30 km) or until it reaches normal operating temperature. 2. Park the vehicle on a level surface and engage the parking brake. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 318 DO NOT ADD ADD (CHECK HOT) failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 319 DO NOT ADD ADD (CHECK HOT) level readjusted after recreational flat tow operation. See the Tires, Wheels and Loading chapter for more information on recreational flat towing. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 320: Air Filter(S)
7. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 8. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Maintenance product specifications and capacities section in this chapter. AIR FILTER Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element.
Page 321 Note: Failure to use the correct air filter element may result in severe engine damage. The customer warranty may be void for any damage to the engine if the correct air filter element is not used. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 322 • With your foot on the brake, shift through all the gears while the engine is running. Fuel system • Fill the fuel tank with high-quality fuel until the first automatic shutoff of the fuel pump nozzle. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 323 Note: During extended periods of vehicle storage (30 days or more), fuel may deteriorate due to oxidation. Add Motorcraft Gas Stabilizer or equivalent meeting Ford material specification ESE-M99C112-A to the vehicle fuel system whenever actual or expected storage periods exceed 30 days.
Page 324: Part Numbers
Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
Page 325: Maintenance Product Specifications And Capacities
Maintenance and Specifications 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 326 Maintenance and Specifications 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 327 Maintenance and Specifications 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 328 Maintenance and Specifications 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 329: Engine Data
Ignition system Coil on plug Coil on plug 0.049–0.053 inch 0.045–0.049 inch Spark plug gap (1.25–1.35mm) (1.15–1.25mm) Compression 9.7:1 10.3:1 ratio Engine drivebelt routing • 2.5L I4 Engine • 3.0L V6 Engine 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 330 Vehicle identification number (VIN) The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 331 TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code Five-speed manual Six-speed automatic 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 332: Accessories
FORD CUSTOM ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford Custom Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 333 Ford Motor Company engineering requirements. Contact your Ford dealer for details regarding the manufacturer’s limited warranty and/or a copy of the FLA product limited warranty offered by the accessory manufacturer.
Page 334: Ford Extended Service Plan
BaseCare – Covers 84 components. PowertrainCare – Covers 29 critical components. Ford ESP is honored by all Ford and Lincoln Dealers in the U.S. and Canada It’s the only extended service plan authorized and backed by Ford Motor Company. That means you get: •...
Page 335 Ford ESP Can Quickly Pay for Itself One service bill – the cost of parts and labor – can easily exceed the price of your Ford ESP Service Contract. With Ford ESP, you minimize your risk for unexpected repair bills and rising repair costs.
Page 336 Ford Extended Service Plan 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 337 Ford Motor Company dealers. For more information, visit your local Ford of Canada dealer or www.ford.ca to find the Ford Extended Service Plan that is right for you. NOTE: Repairs performed outside of Canada and the United States are not eligible for Ford ESP coverage.
Page 338: Scheduled Maintenance Guide
Your dealer has factory-trained technicians who can perform the required maintenance using genuine Ford parts. They are committed to meeting your service needs and to assuring your continuing satisfaction. Protecting your investment Maintenance is an investment that will pay dividends in the form of improved reliability, durability and resale value.
Page 339 Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing. Ford Motor Company relies upon this testing to determine the most appropriate mileage for replacement of oils and fluids to protect your vehicle at the lowest overall cost to you and recommends against maintenance schedules that deviate from the scheduled maintenance information.
Page 340 Genuine Ford and Motorcraft replacement parts Dealerships stock Ford and Motorcraft branded replacement parts. These parts meet or exceed Ford Motor Company’s specifications, and we stand behind them. Parts installed at your dealership carry a nationwide, 12 month/12,000 mile (20,000 km) parts and labor limited warranty.
Page 341 In order to keep your vehicle running right, it is important to have the systems on your vehicle checked regularly. This can help identify potential issues and prevent major problems. Ford Motor Company recommends the following multi-point inspection be performed at every scheduled maintenance interval to help ensure your vehicle keeps running great.
Page 342 The multi-point vehicle inspection is one more way to keep your vehicle running great! 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 343 Scheduled Maintenance Guide 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 344: Normal Scheduled Maintenance And Log
If your message center is prematurely reset or becomes inoperative, you should perform the oil change interval at six months or 5,000 miles (8,000 km) from your last oil change. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 345 Scheduled Maintenance Guide 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 346 (2WD vehicles) Every 100,000 miles Change engine coolant (160,000 km) Change manual transmission fluid (except Escape) Change rear axle fluid (Dana axles only) Replace spark plugs Inspect accessory drive belt(s) 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 347 (2WD vehicles) Initial replacement at 100,000 miles (160,000 km) or 72 months; every 50,000 miles (80,000 km) or 36 months thereafter Perform a follow-up inspection at 120,000 miles (192,000 km) 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 348 OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 349 OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 350 OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 351 Example #2: The OIL CHANGE REQUIRED message has not come on but the odometer reads 30,000 miles (48,000 km); perform the engine air filter replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 25,000 miles [40,000 km].) 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 352 Example #2: The OIL CHANGE REQUIRED message has not come on but the odometer reads 30,000 miles (48,000 km); perform the engine air filter replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 25,000 miles [40,000 km].) 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 353 Every 60,000 miles (96,000 km) – Change transfer case fluid (4WD vehicles) Reset your Intelligent Oil Life Monitor™ after each engine oil and filter change; refer to the Instrument Cluster chapter. 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 354 Instrument Cluster chapter. Exclusive use of E85 (Flex Fuel Vehicles only) Every oil change interval – If ran exclusively on E85, fill the fuel tank full with regular unleaded fuel 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 355 OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 356 OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 357 ❑ Rear axles and power take-off (PTO) units containing synthetic fluid and light duty trucks equipped with Ford-design axles are lubricated for life. These fluids are not to be checked or changed unless a leak is suspected, service is required or the axle assembly has been submerged in water.
Page 358: Engine Coolant Change Log
OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 359: Index
Audio system (see Radio) ..29 Cargo area shade ......87 Automatic transmission ....222 driving an automatic Cargo management system ..87 overdrive .........223 CD ..........29 fluid, refill capacities ....324 Cell phone use ......9 fluid, specification ....324 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 360 ..264, 308 steering column ......77 Emergency Flashers ....245 Coolant Emission control system ..313 checking and adding ....297 refill capacities ....300, 324 Engine ........328 specifications ......324 cleaning ........279 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 361 ...........305 system ........50 capacity ........324 manual heating and air choosing the right fuel ...306 conditioning system ....47 detergent in fuel .....308 filler funnel ......308 Hood ..........287 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 362 (power) ..74 specifications chart ....61 daytime running light ....56 Moon roof ........78 fog lamps ........55 Motorcraft parts ....285, 323 headlamps .........54 headlamps, flash to pass ..56 MyKey ..........92 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 363 Preparing to drive your Safety restraints - LATCH vehicle ........220 anchors ........161 Safety seats for children ..157 Safety Compliance Radio ..........29 Certification Label ....329 Rear-view camera system ..229 Satellite Radio Information ..43 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 364 ..324 controls ........77 manual operation ....225 tilting .........67 Trunk ...........88 Stereo CD-MP3 ........29 Turn signal ........58 SYNC ..........46 Universal garage door opener ..80 USB port ........39 Tilt steering wheel ......67 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)
Page 365 Windshield washer fluid and Ventilating your vehicle ...209 wipers ..........66 checking and adding fluid ..289 liftgate reservoir .....289 replacing wiper blades ...290–291 Warning lights (see Lights) ..12 Wrecker towing ......268 Washer fluid ......289 2011 Escape (204) Owners Guide, 2nd Printing USA (fus)

Ford 2011 Escape Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Ford Extended Service Plan

Scheduled Maintenance Guide

Index

Quick Links

Related Manuals for Ford 2011 Escape

Summary of Contents for Ford 2011 Escape

Table of Contents
