- Page 1 TSA 082N VIDEO ALARM SEQUENTIAL SWITCHER Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Safety precautions............................ 2 Preface ..............................3 Features ..............................3 Precautions .............................. 3 Controls and connectors .......................... 4 Connections ............................. 5 Alarm / Remote control connection ......................7 VCR CLOCK connection .......................... 7 Vertical interval switching ......................... 7 Alarm specification ........................... 7 Remote control ............................ -
Page 3: Preface
• Avoid using this unit under the following Standard BNC-type input and output connectors enables the TSA 082N to be used with other conditions: CCTV switchers, cameras, monitors and video -in extremely hot, cold or humid places, tape recorders. -
Page 4: Controls And Connectors
CONTROLS AND CONNECTORS FRONT PANEL (1) CH B - TIME (5) POWER display show sequence Switch to turn the power on / off - lights in the the CHANNEL B or the sequential time of the power on position. CHANNEL A. When the VCR CLOCK is selected the display shows C. - Page 5 REAR PANEL FUSE MODEL No. TSA 082N (1) FUSE T 315 mA (6) ALM Fuse socket. Alarm output connector (terminal block), open collector output. It is suitable to connect the video tape recorder with alarm input. (2) CH A BNC video output connector of the CHANNEL A.
-
Page 6: Connections
• Also refer to the instruction manual of the equipment to be connected. CAM 4 CAM 8 CAM 2 CAM 6 FUSE MODEL No. TSA 082N CAM 1 CAM 5 ALARM SENSORS CAM 3 CAM 7 AC MAINS REMOTE... -
Page 7: Alarm / Remote Control Connection
ALARM SPECIFICATION enhanced operational efficiency, TSA 082N has an multi-language on-screen When only one alarm input is activated, the display function on the CHANNEL A in English, alarmed video input appears on the CHANNEL Italian and German language. The characters A or CHANNEL B. -
Page 8: Set-Up
SET - UP Switch off the unit. Press the key "8" and turn the power on. All LED lamps go off, power switch lights. Language menu is on the screen: > > ENGLISH ITALIANO DEUTSCH Press the keys "∧" and "∨" to move the selector up and down and key "•" as enter. Main menu is on the screen SET - UP >... - Page 9 CH-B SEQ. TIME > > TIME Sec. 12 EXIT Press "∨", then "•": Press "∨", then "•": CH-B INPUTS (number of inputs on CHANNEL B) > > NUMBER EXIT Press "•" and use up/down selectors to select the number. Press "∨", then "•": Press "∨", then "•": CH-B FRAMES >...
- Page 10 ALARM TRIGGER (positive or negative alarm input signal triggering) > > ∗ ∗ POSITIVE NEGATIVE EXIT In main menu select the next menu: REMOTE CONTROL (remote control possibility) > > ∗ ∗ ON EXIT Next menu: LINE - LOCK (line-lock phase from -127 to +127) >...
-
Page 11: Standard Setting
STANDARD SETTING SELF TEST Switch off the unit. Press the key "1" and turn Switch off the unit. Press the key "4" and turn the power on. All settings are as follows: the power on. All video inputs are sequentially switched both output... -
Page 12: Appearance
APPEARANCE One unit Two units SPECIFICATIONS Video inputs 1 Vpp / 75 Ω, BNC Video outputs 1 Vpp / 75 Ω, BNC 10 MHz ± 3 dB Video bandwidth > 60 dB Signal / noise ratio Crosstalk 56 dB (4.5 MHz) Switching interval adjustable, 1 to 90 sec. -
Page 13: Optional Accessory
PIN ASSIGNMENT Alarm input / remote control connector D-9F: PIN No. ALARM REMOTE ALARM 1 ALARM 2 ALARM 3 n.c. ALARM 4 n.c. ALARM 5 n.c. ALARM 6 n.c. ALARM 7 n.c. ALARM 8 n.c. Alarm output / VCR Clock connector: ALARM OUT VCR CLOCK OPTIONAL ACCESSORY...
